• Omron E5AN-H Advanced Digital Temperature Controller (96x96mm, High Resolution, Logic Operations)
1 1

Omron E5AN-H Advanced Digital Temperature Controller (96x96mm, High Resolution, Logic Operations)

Omron E5AN-H Advanced Digital Temperature Controller (96x96mm, High Resolution, Logic Operations)

A New High-performance Controller: High Resolution, High Speed, and High Input Accuracy.

Key features

  • Logic Operations and Preventive Maintenance Function. 1/4 DIN 96x96x78mm
  • Basic and Valve control methods
  • Requires Control Output Unit (E53-RN/QN/Q3/Q4/C3N/C3DN/V34N/V35N, sold separately)
E5AN-HAA2HBM-500 Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA2HHBFM-500 Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA3BFM-500 Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA2HBMD-500 Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA2HHBFMD-500 Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA3BFMD-500 Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA2HBM-W-500 Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver
E5AN-HAA2HHBFM-W-500 Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver
E5AN-HAA2HBMD-W-500 Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Silver
E53-RN Output Unit: Relay output, SPST-NO, 250VAC 5A | Type: Output Unit | Output: Relay (SPST-NO) | Rating: 250VAC 5A resistive | Electrical Life: 100,000 ops
E53-QN Output Unit: Voltage output (SSR), 12VDC PNP, 40mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 12VDC (PNP) | Max Load Current: 40mA
E53-Q3 Output Unit: Voltage output (SSR), 24VDC NPN, 20mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (NPN) | Max Load Current: 20mA
E53-Q4 Output Unit: Voltage output (SSR), 24VDC PNP, 20mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (PNP) | Max Load Current: 20mA
E53-C3N Output Unit: Current output, 4~20mA DC, 600Ω max | Type: Output Unit | Output: Current | Range: 4~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000
E53-C3DN Output Unit: Current output, 0~20mA DC, 600Ω max | Type: Output Unit | Output: Current | Range: 0~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000
E53-V34N Output Unit: Linear voltage output, 0~10VDC, 1kΩ min | Type: Output Unit | Output: Linear Voltage | Range: 0~10VDC | Min Load: 1 kOhm | Resolution: approx. 10,000
E53-V35N Output Unit: Linear voltage output, 0~5VDC, 1kΩ min | Type: Output Unit | Output: Linear Voltage | Range: 0~5VDC | Min Load: 1 kOhm | Resolution: approx. 10,000
Temperature ControllerOmron
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E5AN-H Advanced Digital Temperature Controller (96x96mm, High Resolution, Logic Operations)

Brand Omron·Temperature Controller

Available part numbers (17)

E5AN-HAA2HBM-500, E5AN-HAA2HHBFM-500, E5AN-HAA3BFM-500, E5AN-HAA2HBMD-500, E5AN-HAA2HHBFMD-500, E5AN-HAA3BFMD-500, E5AN-HAA2HBM-W-500, E5AN-HAA2HHBFM-W-500, E5AN-HAA2HBMD-W-500, E53-RN + 7 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E5AN-HAA2HBM-500Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA2HHBFM-500Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA3BFM-500Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Black
E5AN-HAA2HBMD-500Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA2HHBFMD-500Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA3BFMD-500Basic, 3 aux, Control Output ×2, 2 event inputs, Transfer output, RSP:4~20mA, 24VAC/VDC, Black | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 3 | Control Output: Unit×2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Black
E5AN-HAA2HBM-W-500Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 100~240VAC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver
E5AN-HAA2HHBFM-W-500Basic, 2 aux, Control Output ×2, HB:2, 2 event inputs, Transfer output, RSP:4~20mA, 100~240VAC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 2 | Event Inputs: 2 | Transfer Output: 4~20mA | RSP: 4~20mA input | Power Supply: 100~240VAC | Case: Silver
E5AN-HAA2HBMD-W-500Basic, 2 aux, Control Output ×2, HB:1, 2 event inputs, RSP:4~20mA, 24VAC/VDC, Silver | Type: Main Unit | Size: 96x96x78mm | Control Method: Basic | Aux Outputs: 2 | Control Output: Unit×2 | Heater Burnout: 1 | Event Inputs: 2 | RSP: 4~20mA input | Power Supply: 24VAC/VDC | Case: Silver
E53-RNOutput Unit: Relay output, SPST-NO, 250VAC 5A | Type: Output Unit | Output: Relay (SPST-NO) | Rating: 250VAC 5A resistive | Electrical Life: 100,000 ops
E53-QNOutput Unit: Voltage output (SSR), 12VDC PNP, 40mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 12VDC (PNP) | Max Load Current: 40mA
E53-Q3Output Unit: Voltage output (SSR), 24VDC NPN, 20mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (NPN) | Max Load Current: 20mA
E53-Q4Output Unit: Voltage output (SSR), 24VDC PNP, 20mA | Type: Output Unit | Output: Voltage (for driving SSR) | Voltage: 24VDC (PNP) | Max Load Current: 20mA
E53-C3NOutput Unit: Current output, 4~20mA DC, 600Ω max | Type: Output Unit | Output: Current | Range: 4~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000
E53-C3DNOutput Unit: Current output, 0~20mA DC, 600Ω max | Type: Output Unit | Output: Current | Range: 0~20mA DC | Max Load: 600 Ohm | Resolution: approx. 10,000
E53-V34NOutput Unit: Linear voltage output, 0~10VDC, 1kΩ min | Type: Output Unit | Output: Linear Voltage | Range: 0~10VDC | Min Load: 1 kOhm | Resolution: approx. 10,000
E53-V35NOutput Unit: Linear voltage output, 0~5VDC, 1kΩ min | Type: Output Unit | Output: Linear Voltage | Range: 0~5VDC | Min Load: 1 kOhm | Resolution: approx. 10,000
