Omron E6C2-C Incremental Rotary Encoder (PNP Open-collector, 12~24VDC, 100~2000P/R)

Omron E6C2-C Incremental Rotary Encoder (PNP Open-collector, 12~24VDC, 100~2000P/R)

OMRON E6C2-C Series 50mm slim incremental rotary encoder.

Key features

  • PNP open-collector. 12~24 VDC. 100~2000 P/R (7 resolutions)
  • A/B/Z
  • Cable 2m

Specifications

Output Type PNP open-collector
Power Supply 12~24 VDC
Output Phases A, B, Z
Cable 2 m
Encoder Type Incremental
Diameter 50 mm
E6C2-CWZ5B 100P/R 2M E6C2-C 100P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 100P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 200P/R 2M E6C2-C 200P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 200P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 360P/R 2M E6C2-C 360P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 360P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 500P/R 2M E6C2-C 500P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 500P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 600P/R 2M E6C2-C 600P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 600P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 1,000P/R 2M E6C2-C 1,000P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 1,000P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 2,000P/R 2M E6C2-C 2,000P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 2,000P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
Rotary EncoderOmron
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E6C2-C Incremental Rotary Encoder (PNP Open-collector, 12~24VDC, 100~2000P/R)

Brand Omron·Rotary Encoder

Available part numbers (7)

E6C2-CWZ5B 100P/R 2M, E6C2-CWZ5B 200P/R 2M, E6C2-CWZ5B 360P/R 2M, E6C2-CWZ5B 500P/R 2M, E6C2-CWZ5B 600P/R 2M, E6C2-CWZ5B 1,000P/R 2M, E6C2-CWZ5B 2,000P/R 2M

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E6C2-CWZ5B 100P/R 2ME6C2-C 100P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 100P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 200P/R 2ME6C2-C 200P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 200P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 360P/R 2ME6C2-C 360P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 360P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 500P/R 2ME6C2-C 500P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 500P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 600P/R 2ME6C2-C 600P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 600P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 1,000P/R 2ME6C2-C 1,000P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 1,000P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
E6C2-CWZ5B 2,000P/R 2ME6C2-C 2,000P/R PNP open-collector 2m | Output Type: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 2,000P/R | Output Phases: A, B, Z | Cable: 2 m | Encoder Type: Incremental | Diameter: 50 mm
