• Omron E6C3-A Absolute Rotary Encoder (Gray, PNP, 12~24VDC)
1 1

Omron E6C3-A Absolute Rotary Encoder (Gray, PNP, 12~24VDC)

Omron E6C3-A Absolute Rotary Encoder (Gray, PNP, 12~24VDC)

OMRON E6C3-A 50mm absolute encoder.

Key features

  • Gray code, PNP. 256/360/720/1,024 P/R
  • Pre-wired 1m

Specifications

Encoder Type Absolute
Diameter 50 mm
Power Supply 12~24 VDC
Output PNP open-collector
Code Gray
Connection Pre-wired 1 m
E6C3-AG5B 256P/R 1M E6C3-A Gray PNP 256P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 256P/R | Connection: Pre-wired 1 m
E6C3-AG5B 360P/R 1M E6C3-A Gray PNP 360P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 360P/R | Connection: Pre-wired 1 m
E6C3-AG5B 720P/R 1M E6C3-A Gray PNP 720P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 720P/R | Connection: Pre-wired 1 m
E6C3-AG5B 1,024P/R 1M E6C3-A Gray PNP 1,024P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 1,024P/R | Connection: Pre-wired 1 m
Rotary EncoderOmron
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E6C3-A Absolute Rotary Encoder (Gray, PNP, 12~24VDC)

Brand Omron·Rotary Encoder

Available part numbers (4)

E6C3-AG5B 256P/R 1M, E6C3-AG5B 360P/R 1M, E6C3-AG5B 720P/R 1M, E6C3-AG5B 1,024P/R 1M

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E6C3-AG5B 256P/R 1ME6C3-A Gray PNP 256P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 256P/R | Connection: Pre-wired 1 m
E6C3-AG5B 360P/R 1ME6C3-A Gray PNP 360P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 360P/R | Connection: Pre-wired 1 m
E6C3-AG5B 720P/R 1ME6C3-A Gray PNP 720P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 720P/R | Connection: Pre-wired 1 m
E6C3-AG5B 1,024P/R 1ME6C3-A Gray PNP 1,024P/R 1m | Encoder Type: Absolute | Diameter: 50 mm | Power Supply: 12~24 VDC | Output: PNP open-collector | Code: Gray | Resolution: 1,024P/R | Connection: Pre-wired 1 m
