Omron E8FC IoT Flow Sensor (Flow Rate + Temperature, IO-Link, PNP/NPN, COM2/COM3)

Omron E8FC IoT Flow Sensor (Flow Rate + Temperature, IO-Link, PNP/NPN, COM2/COM3)

OMRON E8FC Series IoT flow sensor for simultaneous measurement of flow rate and temperature.

Key features

  • Detects cooling water, water-soluble coolant, and water-insoluble oil abnormalities
  • Liquid
  • PNP/NPN selectable
  • IO-Link Analog
  • E8FC-25SD: COM2
  • E8FC-25ST: COM3
E8FC-25SD E8FC Flow+Temp IoT sensor IO-Link COM2 (38.4 kbps) | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM2 (38.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative
E8FC-25ST E8FC Flow+Temp IoT sensor IO-Link COM3 (230.4 kbps) | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM3 (230.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative
E8FC-YA-R10A E8FC Adapter 10 A 3/8" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N10A E8FC Adapter 10 A 3/8" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R15A E8FC Adapter 15 A 1/2" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N15A E8FC Adapter 15 A 1/2" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R20A E8FC Adapter 20 A 3/4" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N20A E8FC Adapter 20 A 3/4" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R25A E8FC Adapter 25 A 1" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N25A E8FC Adapter 25 A 1" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
Flow SensorsOmron
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron E8FC IoT Flow Sensor (Flow Rate + Temperature, IO-Link, PNP/NPN, COM2/COM3)

Brand Omron·Flow Sensors

Available part numbers (10)

E8FC-25SD, E8FC-25ST, E8FC-YA-R10A, E8FC-YA-N10A, E8FC-YA-R15A, E8FC-YA-N15A, E8FC-YA-R20A, E8FC-YA-N20A, E8FC-YA-R25A, E8FC-YA-N25A

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E8FC-25SDE8FC Flow+Temp IoT sensor IO-Link COM2 (38.4 kbps) | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM2 (38.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative
E8FC-25STE8FC Flow+Temp IoT sensor IO-Link COM3 (230.4 kbps) | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM3 (230.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative
E8FC-YA-R10AE8FC Adapter 10 A 3/8" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N10AE8FC Adapter 10 A 3/8" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R15AE8FC Adapter 15 A 1/2" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N15AE8FC Adapter 15 A 1/2" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R20AE8FC Adapter 20 A 3/4" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N20AE8FC Adapter 20 A 3/4" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-R25AE8FC Adapter 25 A 1" R (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
E8FC-YA-N25AE8FC Adapter 25 A 1" NPT (taper thread) | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides
