• Omron G2R-[]-S Relay Sockets and Accessories (Track+Back Sockets, Short Bars, DIN Track)
1 1

Omron G2R-[]-S Relay Sockets and Accessories (Track+Back Sockets, Short Bars, DIN Track)

Omron G2R-[]-S Relay Sockets and Accessories (Track+Back Sockets, Short Bars, DIN Track)

Slim and Space-saving Power Plug-in Relay.

P2RF-05-PU G2R-S Socket G2R-1-S Push-In | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Push-In Plus | Mounting: DIN Track or screw
P2RFZ-05-E G2R-S Socket G2R-1-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Screw M3 finger-protect | Mounting: DIN Track or screw
P2RFZ-05 G2R-S Socket G2R-1-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Screw M3.5 | Mounting: DIN Track or screw
P2RF-08-PU G2R-S Socket G2R-2-S Push-In | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Push-In Plus | Mounting: DIN Track or screw
P2RFZ-08-E G2R-S Socket G2R-2-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Screw M3 finger-protect | Mounting: DIN Track or screw
P2RFZ-08 G2R-S Socket G2R-2-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Screw M3.5 | Mounting: DIN Track or screw
P2R-05P G2R-S Back Socket G2R-1-S PCB | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: PCB
P2R-057P G2R-S Back Socket G2R-1-S PCB (alt) | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: PCB (alt)
P2R-05A G2R-S Back Socket G2R-1-S Solder | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: Solder
P2R-08P G2R-S Back Socket G2R-2-S PCB | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: PCB
P2R-087P G2R-S Back Socket G2R-2-S PCB (alt) | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: PCB (alt)
P2R-08A G2R-S Back Socket G2R-2-S Solder | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: Solder
PYDN-7.75-020[] G2R-S Short Bar 2p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 2 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-030[] G2R-S Short Bar 3p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 3 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-040[] G2R-S Short Bar 4p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 4 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-200[] G2R-S Short Bar 20p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 20 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-15.5-080[] G2R-S Short Bar 8 coilp PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 8 coil | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
P2DN-6.8-100S G2R-S Short Bar Screw 20p contact COM | Type: G2R-S Short Bar (Screw) | Description: 20p contact COM | Applicable: P2RFZ-08-E | Note: 10 short bars + 20 caps per set
P2DN-15.7-100S G2R-S Short Bar Screw 10p | Type: G2R-S Short Bar (Screw) | Description: 10p | Applicable: P2RFZ-05/08-E | Note: 10 short bars + 20 caps per set
P2DN-8.5-100S G2R-S Short Bar Screw 20p contact COM | Type: G2R-S Short Bar (Screw) | Description: 20p contact COM | Applicable: P2RFZ-08 | Note: 10 short bars + 20 caps per set
P2DN-19.4-100S G2R-S Short Bar Screw 10p | Type: G2R-S Short Bar (Screw) | Description: 10p | Applicable: P2RFZ-05/08 | Note: 10 short bars + 20 caps per set
P2DN-CP100 G2R-S Short Bar Cap | Type: G2R-S Accessory | Description: Short Bar Cap
P2CZ-C G2R-S Terminal Cover for P2RFZ-05/08 | Type: G2R-S Accessory | Description: Terminal Cover for P2RFZ-05/08
XW5Z-P4.0LB1 G2R-S Label for P2RF-PU (1 sheet/60 pcs) | Type: G2R-S Accessory | Description: Label for P2RF-PU (1 sheet/60 pcs)
XW5Z-P2.5LB1 G2R-S Label for P2RFZ-E (1 sheet/72 pcs) | Type: G2R-S Accessory | Description: Label for P2RFZ-E (1 sheet/72 pcs)
PFP-50N G2R-S DIN Track 0.5m | Type: G2R-S Accessory | Description: DIN Track 0.5m
PFP-100N G2R-S DIN Track 1m | Type: G2R-S Accessory | Description: DIN Track 1m
PFP-100N2 G2R-S DIN Track Deep 1m | Type: G2R-S Accessory | Description: DIN Track Deep 1m
PFP-M G2R-S End Plate | Type: G2R-S Accessory | Description: End Plate
PFP-S G2R-S Spacer | Type: G2R-S Accessory | Description: Spacer
P2R-P G2R-S Back Socket Mounting Plate | Type: G2R-S Accessory | Description: Back Socket Mounting Plate
RelaysOmron
31 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron G2R-[]-S Relay Sockets and Accessories (Track+Back Sockets, Short Bars, DIN Track)

Brand Omron·Relays

Available part numbers (31)

P2RF-05-PU, P2RFZ-05-E, P2RFZ-05, P2RF-08-PU, P2RFZ-08-E, P2RFZ-08, P2R-05P, P2R-057P, P2R-05A, P2R-08P + 21 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
P2RF-05-PUG2R-S Socket G2R-1-S Push-In | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Push-In Plus | Mounting: DIN Track or screw
P2RFZ-05-EG2R-S Socket G2R-1-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Screw M3 finger-protect | Mounting: DIN Track or screw
P2RFZ-05G2R-S Socket G2R-1-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-1-S | Terminal: Screw M3.5 | Mounting: DIN Track or screw
P2RF-08-PUG2R-S Socket G2R-2-S Push-In | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Push-In Plus | Mounting: DIN Track or screw
P2RFZ-08-EG2R-S Socket G2R-2-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Screw M3 finger-protect | Mounting: DIN Track or screw
P2RFZ-08G2R-S Socket G2R-2-S Screw M3 | Type: G2R-S Track/Surface-mounting Socket | Applicable: G2R-2-S | Terminal: Screw M3.5 | Mounting: DIN Track or screw
P2R-05PG2R-S Back Socket G2R-1-S PCB | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: PCB
P2R-057PG2R-S Back Socket G2R-1-S PCB (alt) | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: PCB (alt)
P2R-05AG2R-S Back Socket G2R-1-S Solder | Type: G2R-S Back-mounting Socket | Applicable: G2R-1-S | Terminal: Solder
P2R-08PG2R-S Back Socket G2R-2-S PCB | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: PCB
P2R-087PG2R-S Back Socket G2R-2-S PCB (alt) | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: PCB (alt)
P2R-08AG2R-S Back Socket G2R-2-S Solder | Type: G2R-S Back-mounting Socket | Applicable: G2R-2-S | Terminal: Solder
PYDN-7.75-020[]G2R-S Short Bar 2p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 2 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-030[]G2R-S Short Bar 3p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 3 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-040[]G2R-S Short Bar 4p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 4 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-7.75-200[]G2R-S Short Bar 20p PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 20 | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
PYDN-15.5-080[]G2R-S Short Bar 8 coilp PushIn | Type: G2R-S Short Bar (Push-In Plus) | Poles: 8 coil | Applicable: P2RF-05/08-PU | Colors: R=Red / S=Blue / Y=Yellow | Note: Replace [] with color code
P2DN-6.8-100SG2R-S Short Bar Screw 20p contact COM | Type: G2R-S Short Bar (Screw) | Description: 20p contact COM | Applicable: P2RFZ-08-E | Note: 10 short bars + 20 caps per set
P2DN-15.7-100SG2R-S Short Bar Screw 10p | Type: G2R-S Short Bar (Screw) | Description: 10p | Applicable: P2RFZ-05/08-E | Note: 10 short bars + 20 caps per set
P2DN-8.5-100SG2R-S Short Bar Screw 20p contact COM | Type: G2R-S Short Bar (Screw) | Description: 20p contact COM | Applicable: P2RFZ-08 | Note: 10 short bars + 20 caps per set
P2DN-19.4-100SG2R-S Short Bar Screw 10p | Type: G2R-S Short Bar (Screw) | Description: 10p | Applicable: P2RFZ-05/08 | Note: 10 short bars + 20 caps per set
P2DN-CP100G2R-S Short Bar Cap | Type: G2R-S Accessory | Description: Short Bar Cap
P2CZ-CG2R-S Terminal Cover for P2RFZ-05/08 | Type: G2R-S Accessory | Description: Terminal Cover for P2RFZ-05/08
XW5Z-P4.0LB1G2R-S Label for P2RF-PU (1 sheet/60 pcs) | Type: G2R-S Accessory | Description: Label for P2RF-PU (1 sheet/60 pcs)
XW5Z-P2.5LB1G2R-S Label for P2RFZ-E (1 sheet/72 pcs) | Type: G2R-S Accessory | Description: Label for P2RFZ-E (1 sheet/72 pcs)
PFP-50NG2R-S DIN Track 0.5m | Type: G2R-S Accessory | Description: DIN Track 0.5m
PFP-100NG2R-S DIN Track 1m | Type: G2R-S Accessory | Description: DIN Track 1m
PFP-100N2G2R-S DIN Track Deep 1m | Type: G2R-S Accessory | Description: DIN Track Deep 1m
PFP-MG2R-S End Plate | Type: G2R-S Accessory | Description: End Plate
PFP-SG2R-S Spacer | Type: G2R-S Accessory | Description: Spacer
P2R-PG2R-S Back Socket Mounting Plate | Type: G2R-S Accessory | Description: Back Socket Mounting Plate
