Omron G3PJ SSR for Heaters (Single-phase, 15/25A, 24-480VAC, Screw+Push-In, 12-24VDC)

Omron G3PJ SSR for Heaters (Single-phase, 15/25A, 24-480VAC, Screw+Push-In, 12-24VDC)

Single-phase SSR for low heat generation enables carrying 25 A even for close mounting of three SSRs.

Specifications

Type G3PJ SSR for Heaters (Single-phase)
Input Voltage 12-24 VDC
Insulation Phototriac coupler
Zero Cross Yes
Indicator Yes (orange)
Note Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-215B DC12-24 G3PJ Screw 24-240 VAC 15A close / 18A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-225B DC12-24 G3PJ Screw 24-240 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-515B DC12-24 G3PJ Screw 100-480 VAC 15A close / 23A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-525B DC12-24 G3PJ Screw 100-480 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-215B-PU DC12-24 G3PJ Push-In Plus 24-240 VAC 15A close / 18A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-225B-PU DC12-24 G3PJ Push-In Plus 24-240 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-515B-PU DC12-24 G3PJ Push-In Plus 100-480 VAC 15A close / 23A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-525B-PU DC12-24 G3PJ Push-In Plus 100-480 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
RelaysOmron
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron G3PJ SSR for Heaters (Single-phase, 15/25A, 24-480VAC, Screw+Push-In, 12-24VDC)

Brand Omron·Relays

Available part numbers (8)

G3PJ-215B DC12-24, G3PJ-225B DC12-24, G3PJ-515B DC12-24, G3PJ-525B DC12-24, G3PJ-215B-PU DC12-24, G3PJ-225B-PU DC12-24, G3PJ-515B-PU DC12-24, G3PJ-525B-PU DC12-24

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
G3PJ-215B DC12-24G3PJ Screw 24-240 VAC 15A close / 18A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-225B DC12-24G3PJ Screw 24-240 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-515B DC12-24G3PJ Screw 100-480 VAC 15A close / 23A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-525B DC12-24G3PJ Screw 100-480 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-215B-PU DC12-24G3PJ Push-In Plus 24-240 VAC 15A close / 18A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-225B-PU DC12-24G3PJ Push-In Plus 24-240 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-515B-PU DC12-24G3PJ Push-In Plus 100-480 VAC 15A close / 23A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
G3PJ-525B-PU DC12-24G3PJ Push-In Plus 100-480 VAC 25A close / 27A separate | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible
