Omron TL-W Flat Inductive Proximity Sensor (Unshielded/Shielded, DC 2-Wire/3-Wire)

Omron TL-W Flat Inductive Proximity Sensor (Unshielded/Shielded, DC 2-Wire/3-Wire)

OMRON TL-W Series standard flat inductive proximity sensor.

Key features

  • Unshielded: DC 2-wire 5mm (NO/NC), DC 3-wire NPN/PNP 1.5mm/3mm/5mm/20mm
  • Shielded: DC 3-wire NPN/PNP 5mm
  • Pre-wired 2m
  • Frequency variant models available (add '5' before output code, e.g
  • TL-W5MD15)

Specifications

Connection Pre-wired 2 m
Note Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MD1 2M TL-W Unshielded 5 mm DC 2-wire --- NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MD2 2M TL-W Unshielded 5 mm DC 2-wire --- NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W1R5MC1 2M TL-W Unshielded 1.5 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W1R5MB1 2M TL-W Unshielded 1.5 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MC1 2M TL-W Unshielded 3 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MC2 2M TL-W Unshielded 3 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MB1 2M TL-W Unshielded 3 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MB2 2M TL-W Unshielded 3 mm DC 3-wire PNP NC 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MC1 2M TL-W Unshielded 5 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MC2 2M TL-W Unshielded 5 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MB1 2M TL-W Unshielded 5 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MB2 2M TL-W Unshielded 5 mm DC 3-wire PNP NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W20ME1 2M TL-W Unshielded 20 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W20ME2 2M TL-W Unshielded 20 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5E1 2M TL-W Shielded 5 mm DC 3-wire NPN NO 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5E2 2M TL-W Shielded 5 mm DC 3-wire NPN NC 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5F1 2M TL-W Shielded 5 mm DC 3-wire PNP NO 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5F2 2M TL-W Shielded 5 mm DC 3-wire PNP NC 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
ProximityOmron
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron TL-W Flat Inductive Proximity Sensor (Unshielded/Shielded, DC 2-Wire/3-Wire)

Brand Omron·Proximity

Available part numbers (18)

TL-W5MD1 2M, TL-W5MD2 2M, TL-W1R5MC1 2M, TL-W1R5MB1 2M, TL-W3MC1 2M, TL-W3MC2 2M, TL-W3MB1 2M, TL-W3MB2 2M, TL-W5MC1 2M, TL-W5MC2 2M + 8 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TL-W5MD1 2MTL-W Unshielded 5 mm DC 2-wire --- NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MD2 2MTL-W Unshielded 5 mm DC 2-wire --- NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 2-wire | Output: --- | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W1R5MC1 2MTL-W Unshielded 1.5 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W1R5MB1 2MTL-W Unshielded 1.5 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 1.5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MC1 2MTL-W Unshielded 3 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MC2 2MTL-W Unshielded 3 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MB1 2MTL-W Unshielded 3 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W3MB2 2MTL-W Unshielded 3 mm DC 3-wire PNP NC 2m | Shield: Unshielded | Sensing Distance: 3 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MC1 2MTL-W Unshielded 5 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MC2 2MTL-W Unshielded 5 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MB1 2MTL-W Unshielded 5 mm DC 3-wire PNP NO 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5MB2 2MTL-W Unshielded 5 mm DC 3-wire PNP NC 2m | Shield: Unshielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W20ME1 2MTL-W Unshielded 20 mm DC 3-wire NPN NO 2m | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W20ME2 2MTL-W Unshielded 20 mm DC 3-wire NPN NC 2m | Shield: Unshielded | Sensing Distance: 20 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5E1 2MTL-W Shielded 5 mm DC 3-wire NPN NO 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5E2 2MTL-W Shielded 5 mm DC 3-wire NPN NC 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: NPN | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5F1 2MTL-W Shielded 5 mm DC 3-wire PNP NO 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NO | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
TL-W5F2 2MTL-W Shielded 5 mm DC 3-wire PNP NC 2m | Shield: Shielded | Sensing Distance: 5 mm | Wire: DC 3-wire | Output: PNP | Operation Mode: NC | Connection: Pre-wired 2 m | Note: Frequency variant available (e.g. TL-W5MD15 2M)
