OMRON XS series M12 4-pin Sensor I/O connector cables for connecting M12 connector-type OMRON sensors and amplifiers — including E3S-DC color mark photoelectric sensors and other compatible OMRON M12 4-pin sensors.

Key features

  • Available in two configurations: XS2F single-ended (connector + flying leads, for direct PLC wiring) and XS5W double-ended smart click (connector both sides, for connection to splitter/junction boxes)
  • Each configuration available in straight or L-shaped (right-angle) connector types and 2m or 5m cable lengths
  • PVC-jacketed for general industrial use
  • Pin assignment: Brown (1) +V, White (2) external input or output, Blue (3) 0V, Black (4) C/Q output

Specifications

Connector Size M12 4-pin
Conductors 4-conductor
Cable Type Standard PVC-jacketed
Pin 1 (Brown) +V Power supply
Pin 2 (White) External input or output (depending on sensor)
Pin 3 (Blue) 0V
Pin 4 (Black) C/Q output signal
Compatible With OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS2F-D421-D80-F OMRON XS2F-D421-D80-F M12 sensor cable, single-ended, straight, 4-pin, 2m. | Connector Size: M12 4-pin | Configuration: Single-ended, straight connector | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS2F-D421-G80-F OMRON XS2F-D421-G80-F M12 sensor cable, single-ended, straight, 4-pin, 5m. | Connector Size: M12 4-pin | Configuration: Single-ended, straight connector | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS2F-D422-D80-F OMRON XS2F-D422-D80-F M12 sensor cable, single-ended, L-shaped, 4-pin, 2m. | Connector Size: M12 4-pin | Configuration: Single-ended, L-shaped (right-angle) connector | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS2F-D422-G80-F OMRON XS2F-D422-G80-F M12 sensor cable, single-ended, L-shaped, 4-pin, 5m. | Connector Size: M12 4-pin | Configuration: Single-ended, L-shaped (right-angle) connector | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS5W-D421-D81-F OMRON XS5W-D421-D81-F M12 sensor cable, double-ended smart click, straight/straight, 4-pin, 2m. | Connector Size: M12 4-pin | Configuration: Double-ended smart click, straight/straight | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS5W-D421-G81-F OMRON XS5W-D421-G81-F M12 sensor cable, double-ended smart click, straight/straight, 4-pin, 5m. | Connector Size: M12 4-pin | Configuration: Double-ended smart click, straight/straight | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS5W-D422-D81-F OMRON XS5W-D422-D81-F M12 sensor cable, double-ended smart click, L-shaped/L-shaped, 4-pin, 2m. | Connector Size: M12 4-pin | Configuration: Double-ended smart click, L-shaped/L-shaped | Cable Length: 2m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
XS5W-D422-G81-F OMRON XS5W-D422-D81-F M12 sensor cable, double-ended smart click, L-shaped/L-shaped, 4-pin, 5m. | Connector Size: M12 4-pin | Configuration: Double-ended smart click, L-shaped/L-shaped | Cable Length: 5m | Conductors: 4-conductor | Cable Type: Standard PVC-jacketed | Pin 1 (Brown): +V Power supply | Pin 2 (White): External input or output (depending on sensor) | Pin 3 (Blue): 0V | Pin 4 (Black): C/Q output signal | Compatible With: OMRON E3S-DC color mark sensors and other M12 4-pin sensors
