Omron ZW-7000 Confocal Fiber Displacement Sensor Head (Square / Pen-straight / Pen-right-angle)

OMRON ZW-7000 Series confocal fiber displacement sensor heads.

Key features

Static resolution 0.25 μm (with ZW-7000T controller)
Square straight: ZW-S7010/20/30/40 (50/70/100/120 μm spot)
Pen straight: ZW-SP7007/7010 (130/170 μm spot)
Pen right-angle: ZW-SPR7007/7010 (150/190 μm spot)
Cable 2 m and 0.3 m
Extension fiber cables sold separately

Specifications

Series	ZW-7000
Sensing Method	Confocal fiber displacement
Static Resolution	0.25 μm
Measuring Range	Refer to datasheet
Required Controller	ZW-7000T

ZW-S7010 2M		ZW-7000 Square straight 50 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 50 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-S7010 0.3M		ZW-7000 Square straight 50 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 50 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-S7020 2M		ZW-7000 Square straight 70 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 70 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-S7020 0.3M		ZW-7000 Square straight 70 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 70 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-S7030 2M		ZW-7000 Square straight 100 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 100 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-S7030 0.3M		ZW-7000 Square straight 100 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 100 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-S7040 2M		ZW-7000 Square straight 120 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 120 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-S7040 0.3M		ZW-7000 Square straight 120 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Square straight \| Spot Diameter: 120 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-SP7007 2M		ZW-7000 Pen straight 130 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen straight \| Spot Diameter: 130 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-SP7007 0.3M		ZW-7000 Pen straight 130 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen straight \| Spot Diameter: 130 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-SP7010 2M		ZW-7000 Pen straight 170 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen straight \| Spot Diameter: 170 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-SP7010 0.3M		ZW-7000 Pen straight 170 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen straight \| Spot Diameter: 170 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-SPR7007 2M		ZW-7000 Pen right-angle 150 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen right-angle \| Spot Diameter: 150 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-SPR7007 0.3M		ZW-7000 Pen right-angle 150 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen right-angle \| Spot Diameter: 150 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
ZW-SPR7010 2M		ZW-7000 Pen right-angle 190 μm dia. sensor head 2m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen right-angle \| Spot Diameter: 190 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 2 m
ZW-SPR7010 0.3M		ZW-7000 Pen right-angle 190 μm dia. sensor head 0.3m \| Series: ZW-7000 \| Sensing Method: Confocal fiber displacement \| Shape: Pen right-angle \| Spot Diameter: 190 μm dia. \| Static Resolution: 0.25 μm \| Measuring Range: Refer to datasheet \| Required Controller: ZW-7000T \| Cable Length: 0.3 m \| Note: Use Extension Fiber Cable ZW-XF[][]R for longer reach
