OMRON ZW-SQ Series ultra-compact square right-angle confocal fiber displacement sensor heads.

Key features

  • Compatible with ZW-5000T controller
  • Static resolution 0.25 μm
  • ZW-SQR5007 (18μm spot), ZW-SQR5020 (40μm), ZW-SQR5040 (80μm)
  • Cable 2 m and 0.3 m
  • Extension fiber cables ZW-XF50xxR sold separately

Specifications

Shape Square right-angle
Measuring Range Refer to datasheet
Required Controller ZW-5000T (EtherCAT, 24VDC, NPN/PNP)
Static Resolution 0.25 μm (with ZW-5000T)
Extension Cable ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included)
Note Ultra-compact and ultra-lightweight design
ZW-SQR5007 2M ZW-SQ square right-angle 18 μm dia. 2m | Shape: Square right-angle | Spot Diameter: 18 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m
ZW-SQR5007 0.3M ZW-SQ square right-angle 18 μm dia. 0.3m | Shape: Square right-angle | Spot Diameter: 18 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m
ZW-SQR5020 2M ZW-SQ square right-angle 40 μm dia. 2m | Shape: Square right-angle | Spot Diameter: 40 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m
ZW-SQR5020 0.3M ZW-SQ square right-angle 40 μm dia. 0.3m | Shape: Square right-angle | Spot Diameter: 40 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m
ZW-SQR5040 2M ZW-SQ square right-angle 80 μm dia. 2m | Shape: Square right-angle | Spot Diameter: 80 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 2 m
ZW-SQR5040 0.3M ZW-SQ square right-angle 80 μm dia. 0.3m | Shape: Square right-angle | Spot Diameter: 80 μm dia. | Measuring Range: Refer to datasheet | Required Controller: ZW-5000T (EtherCAT, 24VDC, NPN/PNP) | Static Resolution: 0.25 μm (with ZW-5000T) | Extension Cable: ZW-XF5002R~30R (sold separately, Fiber Adapter ZW-XFC2 included) | Note: Ultra-compact and ultra-lightweight design | Cable Length: 0.3 m
