Samchully 2-Axis Manual Tilting NC Rotary Table RTM-250F4

Samchully 2-Axis Manual Tilting NC Rotary Table RTM-250F4

NC rotary table with manually adjustable tilt (0° to 90°) set by wrench, with FANUC servo motor on the rotary axis.

Key features

  • Manual tilt adjustment by wrench
  • Tilting range 0° to 90°
  • No additional tilt controller required
  • Pneumatic clamp
RTM-250F4 Spindle Dia. (mm): Ø164.5 | Center Height (mm): 235(0°), 224(90°) | Spindle Internal Dia. (mm): Ø95H7 | Spindle Through Hole Dia. (mm): Ø70H8 | Clamp Method: Pneumatic 5~7 kgf/cm² | Clamp Torque (N·m): 750 | Max. Spindle Speed (min-1): 33.3 (motor 3000 min-1) | Gear Ratio: 1/72 | Indexing Accuracy (sec): 20 | Repeatability (sec): 4 | Tilting Range: 0°~90° | Servo Motor: FANUC αiF4/5000-B | Weight (kg): 125
NC Rotary TablesSamchully
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samchully 2-Axis Manual Tilting NC Rotary Table RTM-250F4

Brand Samchully·NC Rotary Tables

Available part numbers (1)

RTM-250F4

How to order

Send the Samchully part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
RTM-250F4Spindle Dia. (mm): Ø164.5 | Center Height (mm): 235(0°), 224(90°) | Spindle Internal Dia. (mm): Ø95H7 | Spindle Through Hole Dia. (mm): Ø70H8 | Clamp Method: Pneumatic 5~7 kgf/cm² | Clamp Torque (N·m): 750 | Max. Spindle Speed (min-1): 33.3 (motor 3000 min-1) | Gear Ratio: 1/72 | Indexing Accuracy (sec): 20 | Repeatability (sec): 4 | Tilting Range: 0°~90° | Servo Motor: FANUC αiF4/5000-B | Weight (kg): 125
