Samchully CTT Hydraulic Milling Chuck

Samchully CTT Hydraulic Milling Chuck

Hydraulic Milling Chuck with CTT (ASME B5.50 CAT taper) shank, inch sizes, available in CTT40, CTT50 sizes.

Key features

  • Vibration dampening extends cutting tool life
  • Cutting tool run-out of 3 microns or better
  • T wrench included for fast set-up
  • Tools can be exchanged directly in the machine spindle

Specifications

Shank standard ASME B5.50
Max speed (rpm) 25,000
Run-out 3 µm
Balancing grade G2.5
CTT40-HM0250-3.54" Shank: CTT40 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 3.54 | L1 (mm): 44
CTT40-HM0250-5.31" Shank: CTT40 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 5.31 | L1 (mm): 44
CTT40-HM0375-3.54" Shank: CTT40 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 3.54 | L1 (mm): 45
CTT40-HM0375-5.31" Shank: CTT40 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 5.31 | L1 (mm): 45
CTT40-HM0500-2.36" Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 2.36 | L1 (mm): 20 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0500-3.54" Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 3.54 | L1 (mm): 45 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0500-5.31" Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 5.31 | L1 (mm): 45 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0625-3.54" Shank: CTT40 | Ød (mm): 15.875 | ØD (mm): 38 | ØD1 (mm): 56 | L (in): 3.54 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0625-5.31" Shank: CTT40 | Ød (mm): 15.875 | ØD (mm): 38 | ØD1 (mm): 56 | L (in): 5.31 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0750-3.54" Shank: CTT40 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 63 | L (in): 3.54 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0750-5.31" Shank: CTT40 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 63 | L (in): 5.31 | L1 (mm): 50
CTT50-HM0250-4.13" Shank: CTT50 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 4.13 | L1 (mm): 44
CTT50-HM0250-6.50" Shank: CTT50 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 6.50'' | L1 (mm): 44
CTT50-HM0375-4.13" Shank: CTT50 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 4.13'' | L1 (mm): 45
CTT50-HM0375-6.50" Shank: CTT50 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 6.50'' | L1 (mm): 45
CTT50-HM0500-4.13" Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 4.13'' | L1 (mm): 52
CTT50-HM0500-5.91" Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 5.91 | L1 (mm): 52
CTT50-HM0500-6.50" Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 6.50 | L1 (mm): 52
CTT50-HM0750-4.13" Shank: CTT50 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 69.8 | L (in): 4.13 | L1 (mm): 69.5
CTT50-HM1000-4.13" Shank: CTT50 | Ød (mm): 25.4 | ØD (mm): 56 | ØD1 (mm): 69.8 | L (in): 4.13 | L1 (mm): 69.5
CTT50-HM1000-5.31" Shank: CTT50 | Ød (mm): 25.4 | ØD (mm): 56 | ØD1 (mm): 69.8 | L (in): 5.31 | L1 (mm): 69.5
CTT50-HM1250-4.13" Shank: CTT50 | Ød (mm): 31.75 | ØD (mm): 69.8 | L (in): 4.13 | L1 (mm): 85.5
CTT50-HM1250-5.31" Shank: CTT50 | Ød (mm): 31.75 | ØD (mm): 69.8 | L (in): 5.31 | L1 (mm): 85.5
Hydraulic ChucksSamchully
23 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samchully CTT Hydraulic Milling Chuck

Brand Samchully·Hydraulic Chucks

Available part numbers (23)

CTT40-HM0250-3.54", CTT40-HM0250-5.31", CTT40-HM0375-3.54", CTT40-HM0375-5.31", CTT40-HM0500-2.36", CTT40-HM0500-3.54", CTT40-HM0500-5.31", CTT40-HM0625-3.54", CTT40-HM0625-5.31", CTT40-HM0750-3.54" + 13 more — see full table ↓

How to order

Send the Samchully part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CTT40-HM0250-3.54"Shank: CTT40 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 3.54 | L1 (mm): 44
CTT40-HM0250-5.31"Shank: CTT40 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 5.31 | L1 (mm): 44
CTT40-HM0375-3.54"Shank: CTT40 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 3.54 | L1 (mm): 45
CTT40-HM0375-5.31"Shank: CTT40 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 5.31 | L1 (mm): 45
CTT40-HM0500-2.36"Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 2.36 | L1 (mm): 20 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0500-3.54"Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 3.54 | L1 (mm): 45 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0500-5.31"Shank: CTT40 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 5.31 | L1 (mm): 45 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0625-3.54"Shank: CTT40 | Ød (mm): 15.875 | ØD (mm): 38 | ØD1 (mm): 56 | L (in): 3.54 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0625-5.31"Shank: CTT40 | Ød (mm): 15.875 | ØD (mm): 38 | ØD1 (mm): 56 | L (in): 5.31 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0750-3.54"Shank: CTT40 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 63 | L (in): 3.54 | L1 (mm): 50 | Note: May be incompatible with some machines depending on flange specification
CTT40-HM0750-5.31"Shank: CTT40 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 63 | L (in): 5.31 | L1 (mm): 50
CTT50-HM0250-4.13"Shank: CTT50 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 4.13 | L1 (mm): 44
CTT50-HM0250-6.50"Shank: CTT50 | Ød (mm): 6.35 | ØD (mm): 26 | ØD1 (mm): 44.3 | L (in): 6.50'' | L1 (mm): 44
CTT50-HM0375-4.13"Shank: CTT50 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 4.13'' | L1 (mm): 45
CTT50-HM0375-6.50"Shank: CTT50 | Ød (mm): 9.525 | ØD (mm): 30 | ØD1 (mm): 44.3 | L (in): 6.50'' | L1 (mm): 45
CTT50-HM0500-4.13"Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 4.13'' | L1 (mm): 52
CTT50-HM0500-5.91"Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 5.91 | L1 (mm): 52
CTT50-HM0500-6.50"Shank: CTT50 | Ød (mm): 12.7 | ØD (mm): 33 | ØD1 (mm): 50 | L (in): 6.50 | L1 (mm): 52
CTT50-HM0750-4.13"Shank: CTT50 | Ød (mm): 19.05 | ØD (mm): 42 | ØD1 (mm): 69.8 | L (in): 4.13 | L1 (mm): 69.5
CTT50-HM1000-4.13"Shank: CTT50 | Ød (mm): 25.4 | ØD (mm): 56 | ØD1 (mm): 69.8 | L (in): 4.13 | L1 (mm): 69.5
CTT50-HM1000-5.31"Shank: CTT50 | Ød (mm): 25.4 | ØD (mm): 56 | ØD1 (mm): 69.8 | L (in): 5.31 | L1 (mm): 69.5
CTT50-HM1250-4.13"Shank: CTT50 | Ød (mm): 31.75 | ØD (mm): 69.8 | L (in): 4.13 | L1 (mm): 85.5
CTT50-HM1250-5.31"Shank: CTT50 | Ød (mm): 31.75 | ØD (mm): 69.8 | L (in): 5.31 | L1 (mm): 85.5
