Samchully PSC SPEEDIA High-Speed SK Collet Chuck

Samchully PSC SPEEDIA High-Speed SK Collet Chuck

SPEEDIA High-Speed SK Collet Chuck with PSC polygonal taper (ISO 26623-1) shank, available in PSC63 sizes.

Key features

  • SK collets give double the gripping strength of ER collets
  • Run-out within 0.003 mm at 4D
  • Balanced for high-speed machining

Specifications

Shank standard ISO 26623-1
Balancing grade G2.5
Max speed (rpm) 25,000
Run-out 3 µm
PSC63-SK06-60S Shank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 60 | H (mm): 35 | Weight (kg): 1.2
PSC63-SK06-90S Shank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 90 | H (mm): 35 | Weight (kg): 1.2
PSC63-SK06-120S Shank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 120 | H (mm): 35 | Weight (kg): 1.3
PSC63-SK06-150S Shank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 150 | H (mm): 35 | Weight (kg): 1.4
PSC63-SK08-60S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 60 | H (mm): 42 | Weight (kg): 1.3
PSC63-SK08-75S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 75 | H (mm): 42 | Weight (kg): 1.4
PSC63-SK08-90S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 90 | H (mm): 42 | Weight (kg): 1.5
PSC63-SK08-120S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 120 | H (mm): 42 | Weight (kg): 1.6
PSC63-SK08-150S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 150 | H (mm): 42 | Weight (kg): 1.7
PSC63-SK08-180S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 180 | H (mm): 42 | Weight (kg): 1.9
PSC63-SK08-200S Shank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 200 | H (mm): 42 | Weight (kg): 2.0
PSC63-SK10-60S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 60 | H (mm): 50 | Weight (kg): 1.3
PSC63-SK10-75S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 75 | H (mm): 50 | Weight (kg): 1.4
PSC63-SK10-90S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 90 | H (mm): 50 | Weight (kg): 1.5
PSC63-SK10-120S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 120 | H (mm): 50 | Weight (kg): 1.6
PSC63-SK10-150S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 150 | H (mm): 50 | Weight (kg): 1.7
PSC63-SK10-180S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 180 | H (mm): 50 | Weight (kg): 1.9
PSC63-SK10-200S Shank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 200 | H (mm): 50 | Weight (kg): 2.0
PSC63-SK13-60S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 60 | H (mm): 65 | Weight (kg): 1.3
PSC63-SK13-75S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 75 | H (mm): 65 | Weight (kg): 1.4
PSC63-SK13-90S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 90 | H (mm): 65 | Weight (kg): 1.5
PSC63-SK13-120S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 120 | H (mm): 65 | Weight (kg): 1.8
PSC63-SK13-150S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 150 | H (mm): 65 | Weight (kg): 1.9
PSC63-SK13-180S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 180 | H (mm): 65 | Weight (kg): 2.1
PSC63-SK13-200S Shank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 200 | H (mm): 65 | Weight (kg): 2.2
PSC63-SK16-60S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 60 | H (mm): 65 | Weight (kg): 1.5
PSC63-SK16-75S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 75 | H (mm): 67 | Weight (kg): 1.6
PSC63-SK16-90S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 90 | H (mm): 70 | Weight (kg): 1.7
PSC63-SK16-120S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 120 | H (mm): 70 | Weight (kg): 2.0
PSC63-SK16-150S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 150 | H (mm): 70 | Weight (kg): 2.3
PSC63-SK16-180S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 180 | H (mm): 70 | Weight (kg): 2.6
PSC63-SK16-200S Shank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 200 | H (mm): 70 | Weight (kg): 2.7
PSC63-SK20-60S Shank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 60 | H (mm): 60 | Weight (kg): 1.5
PSC63-SK20-75S Shank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 75 | H (mm): 70 | Weight (kg): 1.6
PSC63-SK20-90S Shank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 90 | H (mm): 80 | Weight (kg): 1.8
PSC63-SK20-120S Shank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 120 | H (mm): 80 | Weight (kg): 2.2
PSC63-SK25-75S Shank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 75 | H (mm): 75 | Weight (kg): 1.6
PSC63-SK25-90S Shank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 90 | H (mm): 75 | Weight (kg): 1.9
PSC63-SK25-120S Shank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 120 | H (mm): 85 | Weight (kg): 2.2
Collet ChucksSamchully
39 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samchully PSC SPEEDIA High-Speed SK Collet Chuck

Brand Samchully·Collet Chucks

Available part numbers (39)

PSC63-SK06-60S, PSC63-SK06-90S, PSC63-SK06-120S, PSC63-SK06-150S, PSC63-SK08-60S, PSC63-SK08-75S, PSC63-SK08-90S, PSC63-SK08-120S, PSC63-SK08-150S, PSC63-SK08-180S + 29 more — see full table ↓

How to order

Send the Samchully part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PSC63-SK06-60SShank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 60 | H (mm): 35 | Weight (kg): 1.2
PSC63-SK06-90SShank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 90 | H (mm): 35 | Weight (kg): 1.2
PSC63-SK06-120SShank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 120 | H (mm): 35 | Weight (kg): 1.3
PSC63-SK06-150SShank: PSC63 | Ød (mm): 1.8~6.0 | ØD (mm): 19.5 | ØD1 (mm): 19.5 | L (mm): 150 | H (mm): 35 | Weight (kg): 1.4
PSC63-SK08-60SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 60 | H (mm): 42 | Weight (kg): 1.3
PSC63-SK08-75SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 75 | H (mm): 42 | Weight (kg): 1.4
PSC63-SK08-90SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 90 | H (mm): 42 | Weight (kg): 1.5
PSC63-SK08-120SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 120 | H (mm): 42 | Weight (kg): 1.6
PSC63-SK08-150SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 150 | H (mm): 42 | Weight (kg): 1.7
PSC63-SK08-180SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 180 | H (mm): 42 | Weight (kg): 1.9
PSC63-SK08-200SShank: PSC63 | Ød (mm): 1.75~8.0 | ØD (mm): 25 | ØD1 (mm): 25 | L (mm): 200 | H (mm): 42 | Weight (kg): 2.0
PSC63-SK10-60SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 60 | H (mm): 50 | Weight (kg): 1.3
PSC63-SK10-75SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 75 | H (mm): 50 | Weight (kg): 1.4
PSC63-SK10-90SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 90 | H (mm): 50 | Weight (kg): 1.5
PSC63-SK10-120SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 120 | H (mm): 50 | Weight (kg): 1.6
PSC63-SK10-150SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 150 | H (mm): 50 | Weight (kg): 1.7
PSC63-SK10-180SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 180 | H (mm): 50 | Weight (kg): 1.9
PSC63-SK10-200SShank: PSC63 | Ød (mm): 1.75~10.0 | ØD (mm): 27.5 | ØD1 (mm): 27.5 | L (mm): 200 | H (mm): 50 | Weight (kg): 2.0
PSC63-SK13-60SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 60 | H (mm): 65 | Weight (kg): 1.3
PSC63-SK13-75SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 75 | H (mm): 65 | Weight (kg): 1.4
PSC63-SK13-90SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 90 | H (mm): 65 | Weight (kg): 1.5
PSC63-SK13-120SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 120 | H (mm): 65 | Weight (kg): 1.8
PSC63-SK13-150SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 150 | H (mm): 65 | Weight (kg): 1.9
PSC63-SK13-180SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 180 | H (mm): 65 | Weight (kg): 2.1
PSC63-SK13-200SShank: PSC63 | Ød (mm): 2.75~13.0 | ØD (mm): 33 | ØD1 (mm): 33 | L (mm): 200 | H (mm): 65 | Weight (kg): 2.2
PSC63-SK16-60SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 60 | H (mm): 65 | Weight (kg): 1.5
PSC63-SK16-75SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 75 | H (mm): 67 | Weight (kg): 1.6
PSC63-SK16-90SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 90 | H (mm): 70 | Weight (kg): 1.7
PSC63-SK16-120SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 120 | H (mm): 70 | Weight (kg): 2.0
PSC63-SK16-150SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 150 | H (mm): 70 | Weight (kg): 2.3
PSC63-SK16-180SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 180 | H (mm): 70 | Weight (kg): 2.6
PSC63-SK16-200SShank: PSC63 | Ød (mm): 2.75~16.0 | ØD (mm): 40 | ØD1 (mm): 40 | L (mm): 200 | H (mm): 70 | Weight (kg): 2.7
PSC63-SK20-60SShank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 60 | H (mm): 60 | Weight (kg): 1.5
PSC63-SK20-75SShank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 75 | H (mm): 70 | Weight (kg): 1.6
PSC63-SK20-90SShank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 90 | H (mm): 80 | Weight (kg): 1.8
PSC63-SK20-120SShank: PSC63 | Ød (mm): 3.6~20.0 | ØD (mm): 48 | ØD1 (mm): 48 | L (mm): 120 | H (mm): 80 | Weight (kg): 2.2
PSC63-SK25-75SShank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 75 | H (mm): 75 | Weight (kg): 1.6
PSC63-SK25-90SShank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 90 | H (mm): 75 | Weight (kg): 1.9
PSC63-SK25-120SShank: PSC63 | Ød (mm): 7.6~25.4 | ØD (mm): 55 | ØD1 (mm): 55 | L (mm): 120 | H (mm): 85 | Weight (kg): 2.2
