Samchully Work Spindle WSG-360Y11

Samchully Work Spindle WSG-360Y11

Ø360 mm high-speed work spindle with quadruple worm gear (max. 150 rpm) and YASKAWA motor.

Key features

  • Quadruple worm gear type
  • High speed spindle max. 150 rpm
  • For NeoCon-S controller
WSG-360Y11 Table Dia. (mm): Ø360 | Table Height (mm): 306 | Clamp Method: Pneumatic 5~7 kgf/cm² | Clamp Torque (N·m): 80 | Max. Spindle Speed (min-1): 150 (motor 4000 min-1) | Gear Ratio: 1/20 | Servo Motor: YASKAWA SGM7G-20A7A6S | Weight (kg): 240 | Allowable Work Inertia (kgm2): 3.7
NC Rotary TablesSamchully
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samchully Work Spindle WSG-360Y11

Brand Samchully·NC Rotary Tables

Available part numbers (1)

WSG-360Y11

How to order

Send the Samchully part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WSG-360Y11Table Dia. (mm): Ø360 | Table Height (mm): 306 | Clamp Method: Pneumatic 5~7 kgf/cm² | Clamp Torque (N·m): 80 | Max. Spindle Speed (min-1): 150 (motor 4000 min-1) | Gear Ratio: 1/20 | Servo Motor: YASKAWA SGM7G-20A7A6S | Weight (kg): 240 | Allowable Work Inertia (kgm2): 3.7
