Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| HT15A | For: SBI15 | HT length: 6.5 mm | ||
| HT20A | For: SBI20 | HT length: 8 mm | ||
| HT25A | For: SBI25 | HT length: 8 mm | ||
| HT30A | For: SBI30 | HT length: 10 mm | ||
| HT35A | For: SBI35 | HT length: 11 mm | ||
| HT45A | For: SBI45 | HT length: 13 mm | ||
| HT55A | For: SBI55 | HT length: 16 mm | ||
| HT65A | For: SBI65 | HT length: 20 mm | ||
| HT15 | For: SBG(S)15 | HT length: 8 mm | ||
| HT20 | For: SBG(S)20 | HT length: 10 mm | ||
| HT25 | For: SBG(S)25 | HT length: 10.5 mm | ||
| HT30 | For: SBG(S)30 | HT length: 11.5 mm | ||
| HT35 | For: SBG(S)35 | HT length: 12 mm | ||
| HT45 | For: SBG(S)45 | HT length: 16 mm | ||
| HT55 | For: SBG(S)55 | HT length: 18 mm | ||
| HT65 | For: SBG(S)65 | HT length: 18 mm |
Need a different model, or a part not listed here? Send us your parts list →
