• Schaeffler OPTIME Wireless Vibration Sensors and Gateways
1 1

Schaeffler OPTIME Wireless Vibration Sensors and Gateways

Schaeffler OPTIME Wireless Vibration Sensors and Gateways

Schaeffler OPTIME CM is a scalable wireless condition monitoring system: battery sensors record vibration and temperature, gateways transmit to the cloud, and the Digital Service delivers automatic diagnoses.

Key features

  • Battery-operated sensors with NFC commissioning
  • Wirepas mesh network, up to 100 m line of sight
  • KPIs every 4 h, time waveform every 24 h
  • One gateway covers 50 sensors (LTE, Wi-Fi, Ethernet)
  • Ex versions for ATEX/IECEx hazardous areas

Specifications

Communication Wirepas Mesh 2.4 GHz
Sensor IP IP 69K
Battery life up to 5 years
Source Schaeffler OPTIME Condition Monitoring, p. 6-7
OPTIME 3 Type: Sensor | Bandwidth: 2 Hz-3 kHz | Speed: 120-3 000 rpm | Use: Motors, fans, pillow blocks
OPTIME 5 Type: Sensor | Bandwidth: 2 Hz-5 kHz | Speed: up to 5 000 rpm | Use: Pumps, gearboxes, compressors
OPTIME 5 Ex Type: Sensor, ATEX/IECEx Zone 1/21 | Bandwidth: 2 Hz-5 kHz | Speed: up to 5 000 rpm | Use: Hazardous areas
OPTIME Gateway Type: Gateway, max. 50 sensors | Use: LTE/Wi-Fi/Ethernet, IP 66/67
OPTIME Ex Gateway Type: Gateway, ATEX/IECEx Zone 2/21 | Use: Hazardous areas
Condition MonitoringSchaeffler
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Schaeffler OPTIME Wireless Vibration Sensors and Gateways

Brand Schaeffler·Condition Monitoring

Available part numbers (5)

OPTIME 3, OPTIME 5, OPTIME 5 Ex, OPTIME Gateway, OPTIME Ex Gateway

How to order

Send the Schaeffler part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
OPTIME 3Type: Sensor | Bandwidth: 2 Hz-3 kHz | Speed: 120-3 000 rpm | Use: Motors, fans, pillow blocks
OPTIME 5Type: Sensor | Bandwidth: 2 Hz-5 kHz | Speed: up to 5 000 rpm | Use: Pumps, gearboxes, compressors
OPTIME 5 ExType: Sensor, ATEX/IECEx Zone 1/21 | Bandwidth: 2 Hz-5 kHz | Speed: up to 5 000 rpm | Use: Hazardous areas
OPTIME GatewayType: Gateway, max. 50 sensors | Use: LTE/Wi-Fi/Ethernet, IP 66/67
OPTIME Ex GatewayType: Gateway, ATEX/IECEx Zone 2/21 | Use: Hazardous areas
