• SKF TMDT 2 K-type Thermocouple Probes and Extension Cable
1 1

SKF TMDT 2 K-type Thermocouple Probes and Extension Cable

SKF TMDT 2 K-type Thermocouple Probes and Extension Cable

SKF TMDT 2 series K-type thermocouple probes are used with SKF thermometers TKDT 10, TKTL 20, TKTL 30 and TKTL 40 without recalibration.

Key features

  • K-type thermocouple (NiCr/NiAl) to IEC 584 Class 1
  • Accuracy +/-1.5 C up to 375 C, +/-0.4% above
  • 110 mm handle, 1 000 mm spiral cable (most probes)
  • K-type mini-plug connection
  • Surface, pipe, wire, liquid, rotating and foundry versions

Specifications

Probe type K-type thermocouple
Plug K-type mini-plug
Source SKF Maintenance and Lubrication Products, p. 108-109
TMDT 2-30 Type: Standard surface probe | Max. temp: 900 C | Response time: 2.3 s
TMDT 2-43 Type: Heavy duty surface probe | Max. temp: 300 C | Response time: 3.0 s
TMDT 2-32 Type: Insulated surface probe | Max. temp: 200 C | Response time: 2.3 s
TMDT 2-33 Type: Right angle surface probe | Max. temp: 450 C | Response time: 8.0 s
TMDT 2-31 Type: Magnetic surface probe | Max. temp: 240 C | Response time: 7.0 s
TMDT 2-35 Type: Probe with sharp tip | Max. temp: 600 C | Response time: 12.0 s
TMDT 2-36 Type: Pipe clamp probe (to dia. 35 mm) | Max. temp: 200 C | Response time: 8.0 s
TMDT 2-38 Type: Wire probe, fibreglass | Max. temp: 300 C | Response time: 5.0 s
TMDT 2-39 Type: High temperature wire probe | Max. temp: 1 350 C | Response time: 6.0 s
TMDT 2-34 Type: Gas and liquid probe | Max. temp: 1 100 C | Response time: 12.0 s
TMDT 2-34/1.5 Type: Gas and liquid probe, thin shank | Max. temp: 900 C | Response time: 6.0 s
TMDT 2-40 Type: Rotating probe (max. 500 m/min) | Max. temp: 200 C | Response time: 0.6 s
TMDT 2-41 Type: Non-ferrous foundry probe | Max. temp: 1 260 C | Response time: 30.0 s
TMDT 2-42 Type: Ambient temperature probe
TMDT 2-37 Type: Extension cable for K-type probes
Condition MonitoringSKF
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF TMDT 2 K-type Thermocouple Probes and Extension Cable

Brand SKF·Condition Monitoring

Available part numbers (15)

TMDT 2-30, TMDT 2-43, TMDT 2-32, TMDT 2-33, TMDT 2-31, TMDT 2-35, TMDT 2-36, TMDT 2-38, TMDT 2-39, TMDT 2-34 + 5 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TMDT 2-30Type: Standard surface probe | Max. temp: 900 C | Response time: 2.3 s
TMDT 2-43Type: Heavy duty surface probe | Max. temp: 300 C | Response time: 3.0 s
TMDT 2-32Type: Insulated surface probe | Max. temp: 200 C | Response time: 2.3 s
TMDT 2-33Type: Right angle surface probe | Max. temp: 450 C | Response time: 8.0 s
TMDT 2-31Type: Magnetic surface probe | Max. temp: 240 C | Response time: 7.0 s
TMDT 2-35Type: Probe with sharp tip | Max. temp: 600 C | Response time: 12.0 s
TMDT 2-36Type: Pipe clamp probe (to dia. 35 mm) | Max. temp: 200 C | Response time: 8.0 s
TMDT 2-38Type: Wire probe, fibreglass | Max. temp: 300 C | Response time: 5.0 s
TMDT 2-39Type: High temperature wire probe | Max. temp: 1 350 C | Response time: 6.0 s
TMDT 2-34Type: Gas and liquid probe | Max. temp: 1 100 C | Response time: 12.0 s
TMDT 2-34/1.5Type: Gas and liquid probe, thin shank | Max. temp: 900 C | Response time: 6.0 s
TMDT 2-40Type: Rotating probe (max. 500 m/min) | Max. temp: 200 C | Response time: 0.6 s
TMDT 2-41Type: Non-ferrous foundry probe | Max. temp: 1 260 C | Response time: 30.0 s
TMDT 2-42Type: Ambient temperature probe
TMDT 2-37Type: Extension cable for K-type probes
