Siemens SENTRON 3KD Switch Disconnectors, Basic Units AC & AC/DC

Siemens SENTRON 3KD Switch Disconnectors, Basic Units AC & AC/DC

Siemens SENTRON 3KD and 3KD0 fuseless switch disconnectors as basic units without handles for AC and AC/DC applications, 16 to 2000 A.

Key features

  • Sizes 01, 02 (3KD0, AC) and sizes 1 … 5 (AC/DC), 16 … 2000 A
  • Front operating mechanism left or center, or lateral mechanism left/right
  • 3-pole and 4-pole versions with box or flat terminals
  • For door-coupling rotary operating mechanisms; sizes 1 … 5 can take direct mechanisms
  • Floor mounting; sizes 1 and 2 also DIN-rail mountable

Specifications

Brand Siemens SENTRON
Series 3KD
Version Basic unit without handle
Catalog chapter 8 Switch Disconnectors
Product group Fuseless switch disconnectors
Standard IEC 60947-3
Mounting Floor; sizes 1/2 also DIN rail
Source Siemens Catalog LV 10 · 2026, p. 696-697
3KD0130-2KG20-3 Size: 01 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0140-2KG20-3 Size: 01 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0230-2KG20-3 Size: 01 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0240-2KG20-3 Size: 01 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0330-2KG20-3 Size: 01 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0330-2LG20-3 Size: 02 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0340-2LG20-3 Size: 02 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0430-2LG20-3 Size: 02 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0440-2LG20-3 Size: 02 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0530-2LG20-3 Size: 02 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0540-2LG20-3 Size: 02 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0630-2LG20-3 Size: 02 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0640-2LG20-3 Size: 02 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD1630-2ME10-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD1640-2ME10-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD1630-2ME20-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD1640-2ME20-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD1634-2ME10-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD1644-2ME10-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD1634-2ME40-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD1644-2ME40-0 Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2230-2ME10-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2240-2ME10-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2230-2ME20-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2240-2ME20-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2234-2ME10-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2244-2ME10-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2234-2ME40-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2244-2ME40-0 Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2630-2ME10-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2640-2ME10-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2630-2ME20-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2640-2ME20-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2634-2ME10-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2644-2ME10-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2634-2ME40-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2644-2ME40-0 Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-2ME10-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-2ME10-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-2ME20-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-2ME20-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-2ME10-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-2ME10-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-2ME40-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-2ME40-0 Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-2ME10-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-2ME10-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-2ME20-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-2ME20-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-2ME10-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-2ME10-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-2ME40-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-2ME40-0 Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-2NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-2NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-2NE20-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-2NE20-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-2NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-2NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-2NE40-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-2NE40-0 Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-2NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-2NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-2NE20-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-2NE20-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-2NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-2NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-2NE40-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-2NE40-0 Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3230-2NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3240-2NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3230-2NE20-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3240-2NE20-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3234-2NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3244-2NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3234-2NE40-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3244-2NE40-0 Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3430-2NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3440-2NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3430-2NE20-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3440-2NE20-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3434-2NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3444-2NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3434-2NE40-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3444-2NE40-0 Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-0NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-0NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-0NE20-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-0NE20-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-0NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-0NE10-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-0NE40-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-0NE40-0 Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-0NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-0NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-0NE20-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-0NE20-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-0NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-0NE10-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-0NE40-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-0NE40-0 Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3230-0NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3240-0NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3230-0NE20-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3240-0NE20-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3234-0NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3244-0NE10-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3234-0NE40-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3244-0NE40-0 Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3430-0NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3440-0NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3430-0NE20-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3440-0NE20-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3434-0NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3444-0NE10-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3434-0NE40-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3444-0NE40-0 Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3630-0NE10-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3640-0NE10-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3630-0NE20-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3640-0NE20-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3634-0NE10-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3644-0NE10-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3634-0NE40-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3644-0NE40-0 Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3830-0NE10-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3840-0NE10-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3830-0NE20-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3840-0NE20-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3834-0NE10-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3844-0NE10-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3834-0NE40-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3844-0NE40-0 Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3630-0PE10-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3640-0PE10-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3630-0PE20-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3640-0PE20-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3634-0PE10-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3644-0PE10-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3634-0PE40-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3644-0PE40-0 Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3830-0PE10-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3840-0PE10-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3830-0PE20-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3840-0PE20-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3834-0PE10-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3844-0PE10-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3834-0PE40-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3844-0PE40-0 Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4030-0PE10-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4040-0PE10-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4030-0PE20-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4040-0PE20-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4034-0PE10-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4044-0PE10-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4034-0PE40-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4044-0PE40-0 Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4230-0PE10-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4240-0PE10-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4230-0PE20-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4240-0PE20-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4234-0PE10-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4244-0PE10-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4234-0PE40-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4244-0PE40-0 Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4430-0PE10-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4440-0PE10-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4430-0PE20-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4440-0PE20-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4434-0PE10-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4444-0PE10-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4434-0PE40-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4444-0PE40-0 Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4430-0QE10-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4440-0QE10-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4430-0QE20-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4440-0QE20-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4434-0QE10-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4444-0QE10-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4434-0QE40-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4444-0QE40-0 Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4630-0QE10-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4640-0QE10-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4630-0QE20-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4640-0QE20-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4634-0QE10-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4644-0QE10-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4634-0QE40-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4644-0QE40-0 Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4830-0QE10-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4840-0QE10-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4830-0QE20-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4840-0QE20-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4834-0QE10-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4844-0QE10-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4834-0QE40-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4844-0QE40-0 Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5030-0QE10-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5040-0QE10-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5030-0QE20-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5040-0QE20-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5034-0QE10-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5044-0QE10-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5034-0QE40-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5044-0QE40-0 Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5030-0RE10-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5040-0RE10-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5030-0RE20-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5040-0RE20-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5034-0RE10-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5044-0RE10-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5034-0RE40-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5044-0RE40-0 Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5230-0RE10-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5240-0RE10-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5230-0RE20-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5240-0RE20-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5234-0RE10-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5244-0RE10-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5234-0RE40-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5244-0RE40-0 Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5430-0RE10-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5440-0RE10-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5430-0RE20-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5440-0RE20-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5434-0RE10-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5444-0RE10-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5434-0RE40-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5444-0RE40-0 Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5630-0RE10-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5640-0RE10-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5630-0RE20-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5640-0RE20-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5634-0RE10-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5644-0RE10-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5634-0RE40-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5644-0RE40-0 Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
Switch DisconnectorsSiemens
237 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SENTRON 3KD Switch Disconnectors, Basic Units AC & AC/DC

Brand Siemens·Switch Disconnectors

Available part numbers (237)

3KD0130-2KG20-3, 3KD0140-2KG20-3, 3KD0230-2KG20-3, 3KD0240-2KG20-3, 3KD0330-2KG20-3, 3KD0330-2LG20-3, 3KD0340-2LG20-3, 3KD0430-2LG20-3, 3KD0440-2LG20-3, 3KD0530-2LG20-3 + 227 more — see full table ↓

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
3KD0130-2KG20-3Size: 01 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0140-2KG20-3Size: 01 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0230-2KG20-3Size: 01 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0240-2KG20-3Size: 01 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0330-2KG20-3Size: 01 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0330-2LG20-3Size: 02 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0340-2LG20-3Size: 02 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0430-2LG20-3Size: 02 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0440-2LG20-3Size: 02 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0530-2LG20-3Size: 02 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0540-2LG20-3Size: 02 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD0630-2LG20-3Size: 02 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC | Poles: 3P | Operating mechanism: Front, center
3KD0640-2LG20-3Size: 02 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC | Poles: 4P | Operating mechanism: Front, center
3KD1630-2ME10-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD1640-2ME10-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD1630-2ME20-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD1640-2ME20-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD1634-2ME10-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD1644-2ME10-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD1634-2ME40-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD1644-2ME40-0Size: 1 | Rated current Iu: 16 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2230-2ME10-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2240-2ME10-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2230-2ME20-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2240-2ME20-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2234-2ME10-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2244-2ME10-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2234-2ME40-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2244-2ME40-0Size: 1 | Rated current Iu: 32 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2630-2ME10-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2640-2ME10-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2630-2ME20-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2640-2ME20-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2634-2ME10-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2644-2ME10-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2634-2ME40-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2644-2ME40-0Size: 1 | Rated current Iu: 63 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-2ME10-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-2ME10-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-2ME20-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-2ME20-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-2ME10-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-2ME10-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-2ME40-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-2ME40-0Size: 1 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-2ME10-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-2ME10-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-2ME20-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-2ME20-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-2ME10-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-2ME10-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-2ME40-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-2ME40-0Size: 1 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-2NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-2NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-2NE20-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-2NE20-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-2NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-2NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-2NE40-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-2NE40-0Size: 2 | Rated current Iu: 80 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-2NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-2NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-2NE20-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-2NE20-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-2NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-2NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-2NE40-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-2NE40-0Size: 2 | Rated current Iu: 100 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3230-2NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3240-2NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3230-2NE20-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3240-2NE20-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3234-2NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3244-2NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3234-2NE40-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3244-2NE40-0Size: 2 | Rated current Iu: 125 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3430-2NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3440-2NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3430-2NE20-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3440-2NE20-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3434-2NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3444-2NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3434-2NE40-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3444-2NE40-0Size: 2 | Rated current Iu: 160 A | Terminals: Box terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD2830-0NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD2840-0NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD2830-0NE20-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD2840-0NE20-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD2834-0NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD2844-0NE10-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD2834-0NE40-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD2844-0NE40-0Size: 2 | Rated current Iu: 80 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3030-0NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3040-0NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3030-0NE20-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3040-0NE20-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3034-0NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3044-0NE10-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3034-0NE40-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3044-0NE40-0Size: 2 | Rated current Iu: 100 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3230-0NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3240-0NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3230-0NE20-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3240-0NE20-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3234-0NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3244-0NE10-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3234-0NE40-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3244-0NE40-0Size: 2 | Rated current Iu: 125 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3430-0NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3440-0NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3430-0NE20-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3440-0NE20-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3434-0NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3444-0NE10-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3434-0NE40-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3444-0NE40-0Size: 2 | Rated current Iu: 160 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3630-0NE10-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3640-0NE10-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3630-0NE20-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3640-0NE20-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3634-0NE10-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3644-0NE10-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3634-0NE40-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3644-0NE40-0Size: 2 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3830-0NE10-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3840-0NE10-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3830-0NE20-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3840-0NE20-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3834-0NE10-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3844-0NE10-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3834-0NE40-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3844-0NE40-0Size: 2 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3630-0PE10-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3640-0PE10-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3630-0PE20-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3640-0PE20-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3634-0PE10-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3644-0PE10-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3634-0PE40-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3644-0PE40-0Size: 3 | Rated current Iu: 200 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD3830-0PE10-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD3840-0PE10-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD3830-0PE20-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD3840-0PE20-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD3834-0PE10-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD3844-0PE10-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD3834-0PE40-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD3844-0PE40-0Size: 3 | Rated current Iu: 250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4030-0PE10-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4040-0PE10-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4030-0PE20-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4040-0PE20-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4034-0PE10-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4044-0PE10-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4034-0PE40-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4044-0PE40-0Size: 3 | Rated current Iu: 315 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4230-0PE10-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4240-0PE10-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4230-0PE20-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4240-0PE20-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4234-0PE10-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4244-0PE10-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4234-0PE40-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4244-0PE40-0Size: 3 | Rated current Iu: 400 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4430-0PE10-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4440-0PE10-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4430-0PE20-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4440-0PE20-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4434-0PE10-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4444-0PE10-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4434-0PE40-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4444-0PE40-0Size: 3 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4430-0QE10-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4440-0QE10-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4430-0QE20-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4440-0QE20-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4434-0QE10-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4444-0QE10-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4434-0QE40-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4444-0QE40-0Size: 4 | Rated current Iu: 500 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4630-0QE10-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4640-0QE10-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4630-0QE20-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4640-0QE20-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4634-0QE10-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4644-0QE10-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4634-0QE40-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4644-0QE40-0Size: 4 | Rated current Iu: 630 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD4830-0QE10-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD4840-0QE10-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD4830-0QE20-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD4840-0QE20-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD4834-0QE10-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD4844-0QE10-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD4834-0QE40-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD4844-0QE40-0Size: 4 | Rated current Iu: 800 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5030-0QE10-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5040-0QE10-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5030-0QE20-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5040-0QE20-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5034-0QE10-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5044-0QE10-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5034-0QE40-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5044-0QE40-0Size: 4 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5030-0RE10-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5040-0RE10-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5030-0RE20-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5040-0RE20-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5034-0RE10-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5044-0RE10-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5034-0RE40-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5044-0RE40-0Size: 5 | Rated current Iu: 1000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5230-0RE10-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5240-0RE10-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5230-0RE20-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5240-0RE20-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5234-0RE10-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5244-0RE10-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5234-0RE40-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5244-0RE40-0Size: 5 | Rated current Iu: 1250 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5430-0RE10-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5440-0RE10-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5430-0RE20-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5440-0RE20-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5434-0RE10-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5444-0RE10-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5434-0RE40-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5444-0RE40-0Size: 5 | Rated current Iu: 1600 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right
3KD5630-0RE10-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, left
3KD5640-0RE10-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, left
3KD5630-0RE20-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Front, center
3KD5640-0RE20-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Front, center
3KD5634-0RE10-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, left
3KD5644-0RE10-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, left
3KD5634-0RE40-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 3P | Operating mechanism: Lateral, right
3KD5644-0RE40-0Size: 5 | Rated current Iu: 2000 A | Terminals: Flat terminals | Application: AC/DC | Poles: 4P | Operating mechanism: Lateral, right

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Relays & Switches →
