Siemens SENTRON MCB Mechanical & Installation Accessories

Siemens SENTRON MCB Mechanical & Installation Accessories

Mechanical and installation accessories for SENTRON miniature circuit breakers and modular installation devices, including rotary operating mechanisms, locking devices, covers and labels.

Key features

  • Rotary operating mechanisms complete with handle for devices from 2 MW
  • Sealable and lockable handle locking devices and padlocks
  • Lockable terminal covers for screw openings
  • Surface-mounting terminal covers and flush wall enclosures, IP40
  • Device labels, covers, front panel holders and ALPHA SIMBOX intermediate frames

Specifications

Brand Siemens
Product line SENTRON
For 5SY, 5SL, 5SP, 5SJ4 HG, 5TL1, 5TE8 and other devices
Mounting Modular installation devices / 35 mm DIN rail
Width unit 1 MW = 18 mm
Source Siemens Catalog LV 10 · 2026, p. 334-335
5ST3060 Type: Rotary operating mechanism | Version: Handle black
5ST3061 Type: Rotary operating mechanism | Version: Handle red/yellow
5ST3800 Type: Terminal cover | Version: Lockable, per pole (not 5SL30/58/60)
5ST3805-1 Type: Handle coupler | Version: Required for 5SU1 accessory mounting
5ST3801 Type: Handle locking device | Version: 5SY, 5SP, 5TE8, 5SJ4 HG; 3 mm shackle
5ST3806 Type: Handle locking device | Version: 5SL, 5TL1, 5SY17; 3 ... 6 mm shackle
5ST3802 Type: Padlock | Version: For 5ST3801/5ST3806, RCA, 5TY1 COM
5ST3803 Type: Locking device | Version: 5ST3801 + 5ST3802, for 5SY/5SP/5TE8
5ST3807 Type: Locking device | Version: 5ST3806 + 5ST3802, for 5SL/5TL1/5SY17
5TG8240 Type: Spacer | Version: 0.5 MW
8WH8210-0AA35 Type: Device label | Version: 15 x 6 mm, white (WIN 098)
8WH8210-0AA36 Type: Device label | Version: 15 x 6 mm, yellow (WIN 099)
5SW3004 Type: Terminal cover, gray, surface mounting | Version: Up to 2.5 MW, IP40
5SW3005 Type: Terminal cover, gray, surface mounting | Version: Up to 4.5 MW, IP40
5SW3006 Type: Wall enclosure, gray, flush mounting | Version: Up to 2.5 MW, IP40
5SW3007 Type: Wall enclosure, gray, flush mounting | Version: Up to 4.5 MW, IP40
5ST2134 Type: Cover | Version: End plate
5ST2135 Type: Cover | Version: Angled profile
5ST2136 Type: Cover | Version: Flat profile (alternative)
7LF9006 Type: Holder for front panel installation | Version: 1 ... 6 MW, cutout height 45 mm
8GB4561 Type: Intermediate frame (ALPHA SIMBOX) | Version: 1-tier, for 70 mm devices
8GB4562 Type: Intermediate frame (ALPHA SIMBOX) | Version: 2-tier, for 70 mm devices
8GB4563 Type: Intermediate frame (ALPHA SIMBOX) | Version: 3-tier, for 70 mm devices
8GB4564 Type: Intermediate frame (ALPHA SIMBOX) | Version: 4-tier, for 70 mm devices
AccessoriesSiemens
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SENTRON MCB Mechanical & Installation Accessories

Brand Siemens·Accessories

Available part numbers (24)

5ST3060, 5ST3061, 5ST3800, 5ST3805-1, 5ST3801, 5ST3806, 5ST3802, 5ST3803, 5ST3807, 5TG8240 + 14 more — see full table ↓

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
5ST3060Type: Rotary operating mechanism | Version: Handle black
5ST3061Type: Rotary operating mechanism | Version: Handle red/yellow
5ST3800Type: Terminal cover | Version: Lockable, per pole (not 5SL30/58/60)
5ST3805-1Type: Handle coupler | Version: Required for 5SU1 accessory mounting
5ST3801Type: Handle locking device | Version: 5SY, 5SP, 5TE8, 5SJ4 HG; 3 mm shackle
5ST3806Type: Handle locking device | Version: 5SL, 5TL1, 5SY17; 3 ... 6 mm shackle
5ST3802Type: Padlock | Version: For 5ST3801/5ST3806, RCA, 5TY1 COM
5ST3803Type: Locking device | Version: 5ST3801 + 5ST3802, for 5SY/5SP/5TE8
5ST3807Type: Locking device | Version: 5ST3806 + 5ST3802, for 5SL/5TL1/5SY17
5TG8240Type: Spacer | Version: 0.5 MW
8WH8210-0AA35Type: Device label | Version: 15 x 6 mm, white (WIN 098)
8WH8210-0AA36Type: Device label | Version: 15 x 6 mm, yellow (WIN 099)
5SW3004Type: Terminal cover, gray, surface mounting | Version: Up to 2.5 MW, IP40
5SW3005Type: Terminal cover, gray, surface mounting | Version: Up to 4.5 MW, IP40
5SW3006Type: Wall enclosure, gray, flush mounting | Version: Up to 2.5 MW, IP40
5SW3007Type: Wall enclosure, gray, flush mounting | Version: Up to 4.5 MW, IP40
5ST2134Type: Cover | Version: End plate
5ST2135Type: Cover | Version: Angled profile
5ST2136Type: Cover | Version: Flat profile (alternative)
7LF9006Type: Holder for front panel installation | Version: 1 ... 6 MW, cutout height 45 mm
8GB4561Type: Intermediate frame (ALPHA SIMBOX) | Version: 1-tier, for 70 mm devices
8GB4562Type: Intermediate frame (ALPHA SIMBOX) | Version: 2-tier, for 70 mm devices
8GB4563Type: Intermediate frame (ALPHA SIMBOX) | Version: 3-tier, for 70 mm devices
8GB4564Type: Intermediate frame (ALPHA SIMBOX) | Version: 4-tier, for 70 mm devices
