Siemens SIMOCODE M-CP 3UF8 Motor Management System

Siemens SIMOCODE M-CP 3UF8 Motor Management System

SIMOCODE M-CP 3UF8 motor management and control device with Single Pair Ethernet, current/voltage measuring modules, operator panel and function license keys.

Key features

  • Single Pair Ethernet 10BASE-T1L with PROFINET IO, EtherNet/IP and Modbus TCP
  • 6 I/4 Q freely configurable, thermistor input and 3UL23 ground-fault input
  • Current/voltage measuring modules 0.3 ... 630 A, voltage measuring up to 690 V
  • Operator panel with graphical color display and USB-C interface
  • License keys for condition monitoring, dry-running protection, web server and safety functions

Specifications

Brand Siemens
Product line SIMOCODE M-CP 3UF8
Function Motor management and control
Communication SPE: PROFINET, EtherNet/IP, Modbus TCP
Basic unit I/O 6 I / 4 Q
Category Electronic Overload Relays
Source Siemens Catalog IC 10 · 2026, p. 901-902
3UF8011-2AB00-0 Type: SIMOCODE M-CP basic unit | Spec: Us 24 V DC | Terminals: Spring-loaded (push-in)
3UF8011-2AU00-0 Type: SIMOCODE M-CP basic unit | Spec: Us 110 ... 240 V AC/DC | Terminals: Spring-loaded (push-in)
3UF8810-0AA00-0 Type: License key | Spec: Condition monitoring, inst. values | Terminals: -
3UF8820-0AA00-0 Type: License key | Spec: Dry-running protection SIL 1 (Ex) | Terminals: -
3UF8830-0AA00-0 Type: License key | Spec: Web server operation via mobile | Terminals: -
3UF8840-0AA00-0 Type: License key | Spec: 1-wire temp. sensor & memory module | Terminals: -
3UF8841-0AA00-0 Type: License key | Spec: 1-ch. safety-related shutdown SIL 1 | Terminals: -
3UF8110-1AA00-0 Type: Current/voltage measuring module | Spec: 0.3 ... 40 A, straight-through | Terminals: Screw
3UF8111-1AA00-0 Type: Current/voltage measuring module | Spec: 10 ... 115 A, straight-through | Terminals: Screw
3UF8112-1AA00-0 Type: Current/voltage measuring module | Spec: 63 ... 630 A, straight-through | Terminals: Screw
3UF8200-1AA00-0 Type: Operator panel with display | Spec: Color display, 4 buttons, USB-C | Terminals: -
Electronic Overload RelaysSiemens
11 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SIMOCODE M-CP 3UF8 Motor Management System

Brand Siemens·Electronic Overload Relays

Available part numbers (11)

3UF8011-2AB00-0, 3UF8011-2AU00-0, 3UF8810-0AA00-0, 3UF8820-0AA00-0, 3UF8830-0AA00-0, 3UF8840-0AA00-0, 3UF8841-0AA00-0, 3UF8110-1AA00-0, 3UF8111-1AA00-0, 3UF8112-1AA00-0 + 1 more — see full table ↓

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
3UF8011-2AB00-0Type: SIMOCODE M-CP basic unit | Spec: Us 24 V DC | Terminals: Spring-loaded (push-in)
3UF8011-2AU00-0Type: SIMOCODE M-CP basic unit | Spec: Us 110 ... 240 V AC/DC | Terminals: Spring-loaded (push-in)
3UF8810-0AA00-0Type: License key | Spec: Condition monitoring, inst. values | Terminals: -
3UF8820-0AA00-0Type: License key | Spec: Dry-running protection SIL 1 (Ex) | Terminals: -
3UF8830-0AA00-0Type: License key | Spec: Web server operation via mobile | Terminals: -
3UF8840-0AA00-0Type: License key | Spec: 1-wire temp. sensor & memory module | Terminals: -
3UF8841-0AA00-0Type: License key | Spec: 1-ch. safety-related shutdown SIL 1 | Terminals: -
3UF8110-1AA00-0Type: Current/voltage measuring module | Spec: 0.3 ... 40 A, straight-through | Terminals: Screw
3UF8111-1AA00-0Type: Current/voltage measuring module | Spec: 10 ... 115 A, straight-through | Terminals: Screw
3UF8112-1AA00-0Type: Current/voltage measuring module | Spec: 63 ... 630 A, straight-through | Terminals: Screw
3UF8200-1AA00-0Type: Operator panel with display | Spec: Color display, 4 buttons, USB-C | Terminals: -
