Siemens SIMOTICS M-1FE2 Synchronous Built-in Motors (High Torque)

Siemens SIMOTICS M-1FE2 Synchronous Built-in Motors (High Torque)

SIMOTICS M-1FE2 High Torque synchronous built-in motors (1FE218x), water-cooled, delivered as stator and rotor for SINAMICS S120.

Key features

  • High Torque series with rated torque up to 1530 Nm
  • Rated speeds 500 to 1000 rpm, maximum speed up to 4200 rpm
  • Stator with or without cooling jacket, standard rotor sleeve
  • Winding protection standard, full or universal
  • Free cable ends 0.5 m or 1.5 m

Specifications

Motor type Synchronous built-in motor (stator + rotor)
Series High Torque
Cooling Water cooling
Temperature rise 100 K
Rotor Standard rotor sleeve
Line voltage 400 V 3 AC, Active Line Module
Source Siemens Catalog D 21.4 · 2026, p. 858-859
1FE2182-8LH10-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH10-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH11-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH11-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH12-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH12-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH13-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH13-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH30-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH30-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH31-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH31-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH32-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH32-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH33-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH33-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH50-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH50-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH51-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH51-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH52-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH52-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH53-1AC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH53-1CC1 Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN10-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN10-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN11-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN11-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN12-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN12-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN13-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN13-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN30-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN30-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN31-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN31-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN32-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN32-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN33-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN33-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN50-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN50-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN51-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN51-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN52-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN52-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN53-1AC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN53-1CC1 Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH10-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH10-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH11-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH11-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH12-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH12-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH13-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH13-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH30-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH30-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH31-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH31-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH32-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH32-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH33-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH33-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH50-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH50-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH51-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH51-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH52-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH52-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH53-1AC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH53-1CC1 Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN10-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN10-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN11-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN11-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN12-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN12-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN13-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN13-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN30-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN30-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN31-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN31-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN32-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN32-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN33-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN33-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN50-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN50-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN51-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN51-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN52-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN52-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN53-1AC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN53-1CC1 Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH10-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH10-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH11-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH11-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH12-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH12-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH13-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH13-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH30-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH30-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH31-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH31-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH32-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH32-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH33-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH33-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH50-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH50-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH51-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH51-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH52-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH52-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH53-1AC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH53-1CC1 Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK10-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK10-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK11-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK11-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK12-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK12-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK13-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK13-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK30-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK30-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK31-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK31-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK32-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK32-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK33-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK33-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK50-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK50-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK51-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK51-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK52-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK52-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK53-1AC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK53-1CC1 Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN10-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN10-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN11-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN11-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN12-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN12-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN13-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN13-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN30-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN30-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN31-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN31-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN32-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN32-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN33-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN33-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN50-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN50-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN51-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN51-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN52-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN52-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN53-1AC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN53-1CC1 Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH10-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH10-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH11-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH11-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH12-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH12-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH13-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH13-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH30-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH30-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH31-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH31-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH32-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH32-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH33-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH33-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH50-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH50-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH51-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH51-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH52-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH52-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH53-1AC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH53-1CC1 Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL10-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL10-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL11-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL11-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL12-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL12-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL13-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL13-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL30-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL30-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL31-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL31-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL32-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL32-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL33-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL33-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL50-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL50-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL51-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL51-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL52-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL52-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL53-1AC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL53-1CC1 Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN10-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN10-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN11-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN11-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN12-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN12-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN13-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN13-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN30-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN30-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN31-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN31-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN32-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN32-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN33-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN33-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN50-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN50-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN51-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN51-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN52-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN52-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN53-1AC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN53-1CC1 Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH10-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH10-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH11-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH11-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH12-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH12-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH13-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH13-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH30-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH30-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH31-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH31-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH32-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH32-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH33-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH33-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH50-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH50-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH51-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH51-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH52-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH52-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH53-1AC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH53-1CC1 Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM10-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM10-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM11-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM11-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM12-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM12-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM13-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM13-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM30-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM30-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM31-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM31-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM32-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM32-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM33-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM33-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM50-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM50-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM51-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM51-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM52-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM52-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM53-1AC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM53-1CC1 Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN10-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN10-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN11-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN11-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN12-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN12-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN13-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN13-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN30-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN30-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN31-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN31-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN32-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN32-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN33-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN33-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN50-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN50-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN51-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN51-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN52-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN52-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN53-1AC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN53-1CC1 Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH10-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH10-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH11-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH11-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH12-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH12-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH13-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH13-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH30-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH30-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH31-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH31-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH32-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH32-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH33-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH33-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH50-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH50-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH51-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH51-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH52-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH52-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH53-1AC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH53-1CC1 Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN10-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN10-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN11-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN11-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN12-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN12-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN13-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN13-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN30-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN30-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN31-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN31-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN32-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN32-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN33-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN33-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN50-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN50-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN51-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN51-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN52-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN52-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN53-1AC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN53-1CC1 Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
Servo MotorsSiemens
360 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SIMOTICS M-1FE2 Synchronous Built-in Motors (High Torque)

Brand Siemens·Servo Motors

Available part numbers (360)

1FE2182-8LH10-1AC1, 1FE2182-8LH10-1CC1, 1FE2182-8LH11-1AC1, 1FE2182-8LH11-1CC1, 1FE2182-8LH12-1AC1, 1FE2182-8LH12-1CC1, 1FE2182-8LH13-1AC1, 1FE2182-8LH13-1CC1, 1FE2182-8LH30-1AC1, 1FE2182-8LH30-1CC1 + 350 more — see full table ↓

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
1FE2182-8LH10-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH10-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH11-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH11-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH12-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH12-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH13-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH13-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH30-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH30-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH31-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH31-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH32-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH32-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH33-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH33-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH50-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH50-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH51-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH51-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LH52-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LH52-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LH53-1AC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LH53-1CC1Rating: 68 kW / 640 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN10-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN10-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN11-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN11-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN12-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN12-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN13-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN13-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN30-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN30-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN31-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN31-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN32-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN32-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN33-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN33-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN50-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN50-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN51-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN51-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2182-8LN52-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2182-8LN52-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2182-8LN53-1AC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2182-8LN53-1CC1Rating: 34 kW / 650 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH10-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH10-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH11-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH11-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH12-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH12-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH13-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH13-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH30-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH30-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH31-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH31-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH32-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH32-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH33-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH33-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH50-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH50-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH51-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH51-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LH52-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LH52-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LH53-1AC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LH53-1CC1Rating: 88 kW / 840 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN10-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN10-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN11-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN11-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN12-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN12-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN13-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN13-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN30-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN30-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN31-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN31-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN32-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN32-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN33-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN33-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN50-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN50-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN51-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN51-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2183-8LN52-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2183-8LN52-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2183-8LN53-1AC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2183-8LN53-1CC1Rating: 44.5 kW / 840 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH10-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH10-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH11-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH11-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH12-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH12-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH13-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH13-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH30-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH30-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH31-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH31-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH32-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH32-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH33-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH33-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH50-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH50-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH51-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH51-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LH52-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LH52-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LH53-1AC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LH53-1CC1Rating: 105 kW / 1000 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK10-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK10-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK11-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK11-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK12-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK12-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK13-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK13-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK30-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK30-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK31-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK31-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK32-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK32-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK33-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK33-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK50-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK50-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK51-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK51-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LK52-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LK52-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LK53-1AC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LK53-1CC1Rating: 85 kW / 1010 Nm / 800 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN10-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN10-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN11-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN11-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN12-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN12-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN13-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN13-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN30-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN30-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN31-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN31-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN32-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN32-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN33-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN33-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN50-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN50-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN51-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN51-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2184-8LN52-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2184-8LN52-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2184-8LN53-1AC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2184-8LN53-1CC1Rating: 53 kW / 1010 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH10-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH10-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH11-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH11-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH12-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH12-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH13-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH13-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH30-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH30-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH31-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH31-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH32-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH32-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH33-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH33-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH50-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH50-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH51-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH51-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LH52-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LH52-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LH53-1AC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LH53-1CC1Rating: 122 kW / 1160 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL10-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL10-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL11-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL11-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL12-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL12-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL13-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL13-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL30-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL30-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL31-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL31-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL32-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL32-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL33-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL33-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL50-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL50-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL51-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL51-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LL52-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LL52-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LL53-1AC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LL53-1CC1Rating: 87 kW / 1180 Nm / 700 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN10-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN10-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN11-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN11-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN12-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN12-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN13-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN13-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN30-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN30-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN31-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN31-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN32-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN32-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN33-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN33-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN50-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN50-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN51-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN51-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2185-8LN52-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2185-8LN52-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2185-8LN53-1AC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2185-8LN53-1CC1Rating: 62 kW / 1180 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH10-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH10-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH11-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH11-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH12-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH12-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH13-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH13-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH30-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH30-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH31-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH31-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH32-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH32-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH33-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH33-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH50-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH50-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH51-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH51-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LH52-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LH52-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LH53-1AC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LH53-1CC1Rating: 142 kW / 1350 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM10-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM10-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM11-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM11-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM12-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM12-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM13-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM13-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM30-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM30-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM31-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM31-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM32-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM32-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM33-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM33-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM50-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM50-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM51-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM51-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LM52-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LM52-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LM53-1AC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LM53-1CC1Rating: 86 kW / 1370 Nm / 600 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN10-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN10-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN11-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN11-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN12-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN12-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN13-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN13-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN30-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN30-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN31-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN31-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN32-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN32-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN33-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN33-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN50-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN50-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN51-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN51-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2186-8LN52-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2186-8LN52-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2186-8LN53-1AC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2186-8LN53-1CC1Rating: 72 kW / 1370 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH10-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH10-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH11-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH11-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH12-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH12-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH13-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH13-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH30-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH30-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH31-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH31-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH32-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH32-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH33-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH33-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH50-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH50-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH51-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH51-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LH52-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LH52-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LH53-1AC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LH53-1CC1Rating: 159 kW / 1510 Nm / 1000 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN10-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN10-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN11-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN11-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN12-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN12-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN13-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN13-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Standard, 2x Pt1000 | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN30-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN30-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN31-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN31-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN32-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN32-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN33-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN33-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Full, 2x Pt1000 + 3x PTC | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN50-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN50-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN51-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN51-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 0.5 m, small outer diameter | Stator: With cooling jacket
1FE2187-8LN52-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: Without cooling jacket
1FE2187-8LN52-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, large OD or no jacket | Stator: With cooling jacket
1FE2187-8LN53-1AC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: Without cooling jacket
1FE2187-8LN53-1CC1Rating: 80 kW / 1530 Nm / 500 rpm | Winding protection: Universal protection | Cable: 1.5 m, small outer diameter | Stator: With cooling jacket

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Relays & Switches →
