Siemens SINAMICS S120 Double Motor Modules Booksize (2x3-2x18 A, C/D)

Siemens SINAMICS S120 Double Motor Modules Booksize (2x3-2x18 A, C/D)

Double Motor Modules in booksize format (C and D types) that supply two motors from the SINAMICS S120 common DC link.

Key features

  • Two inverters in one module for two motors
  • D type for high-dynamic servo duty, C type for continuous load
  • Rated output currents 2 x 3 A to 2 x 18 A
  • Controlled by the CU320-2 Control Unit via DRIVE-CLiQ
  • Power connectors X1/X2 with screw or push-in terminals

Specifications

Brand Siemens
Product line SINAMICS S120
DC link voltage 510 ... 720 V DC
Format Booksize
Number of axes 2
Cooling Internal air cooling
Source Siemens Catalog D 21.4 · 2026, p. 170-177
6SL3120-2TE13-0AD0 Rated output current: 2 x 3 A | Type rating: 2 x 1.6 kW (2 x 1.5 hp) | Version: D type | Width: 50 mm
6SL3120-2TE15-0AD0 Rated output current: 2 x 5 A | Type rating: 2 x 2.7 kW (2 x 3 hp) | Version: D type | Width: 50 mm
6SL3120-2TE21-0AD0 Rated output current: 2 x 9 A | Type rating: 2 x 4.8 kW (2 x 5 hp) | Version: D type | Width: 50 mm
6SL3120-2TE21-8AC0 Rated output current: 2 x 18 A | Type rating: 2 x 9.7 kW (2 x 10 hp) | Version: C type | Width: 100 mm
6SL3120-2TE21-8AD0 Rated output current: 2 x 18 A | Type rating: 2 x 9.7 kW (2 x 10 hp) | Version: D type | Width: 100 mm
Servo DrivesSiemens
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SINAMICS S120 Double Motor Modules Booksize (2x3-2x18 A, C/D)

Brand Siemens·Servo Drives

Available part numbers (5)

6SL3120-2TE13-0AD0, 6SL3120-2TE15-0AD0, 6SL3120-2TE21-0AD0, 6SL3120-2TE21-8AC0, 6SL3120-2TE21-8AD0

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
6SL3120-2TE13-0AD0Rated output current: 2 x 3 A | Type rating: 2 x 1.6 kW (2 x 1.5 hp) | Version: D type | Width: 50 mm
6SL3120-2TE15-0AD0Rated output current: 2 x 5 A | Type rating: 2 x 2.7 kW (2 x 3 hp) | Version: D type | Width: 50 mm
6SL3120-2TE21-0AD0Rated output current: 2 x 9 A | Type rating: 2 x 4.8 kW (2 x 5 hp) | Version: D type | Width: 50 mm
6SL3120-2TE21-8AC0Rated output current: 2 x 18 A | Type rating: 2 x 9.7 kW (2 x 10 hp) | Version: C type | Width: 100 mm
6SL3120-2TE21-8AD0Rated output current: 2 x 18 A | Type rating: 2 x 9.7 kW (2 x 10 hp) | Version: D type | Width: 100 mm
