• Siemens SIRIUS 3SE5 Position Switches, Metal, 31 mm (EN 50047)
1 1

Siemens SIRIUS 3SE5 Position Switches, Metal, 31 mm (EN 50047)

Siemens SIRIUS 3SE5 Position Switches, Metal, 31 mm (EN 50047)

SIRIUS 3SE52 mechanical position switches in a 31 mm metal enclosure to EN 50047, as complete units and basic switches.

Key features

  • Modular system: enclosure, contact block and actuator head can be replaced individually
  • Positive opening NC contacts according to IEC 60947-5-1, Annex K for safety circuits
  • Slow-action or snap-action contact blocks with 2 or 3 contacts
  • Optional 2 LEDs (yellow/green) for 24 V DC or 230 V AC switching-state display
  • Actuator heads can be rotated in 90° steps

Specifications

Brand Siemens
Product line SIRIUS 3SE52 (3SE521)
Enclosure Metal, width 31 mm
Standard EN 50047
Degree of protection IP66 / IP67
Cable entry 1 x M20 x 1.5
Category Position Switches
Source Siemens Catalog IC 10 · 2026, p. 1099-1101
3SE5212-0BC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0PC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0MC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0PC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0MC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break; Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LC05-1CA0 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-1KC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-3KC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-1LC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-3LC05 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5214-0BC05-1AC5 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0KC05-1AE1 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0CC05-1AC5 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0LC05-1AE1 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-1BC05-1AF3 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-1CC05-1AF3 Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5212-0BB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BD03 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KD03 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CD03 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LD03 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KD10 Actuator: Roller plunger with central fixing | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BE10 Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KE10 Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CE10 Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LE10 Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BF10 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KF10 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CF10 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LF10 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BK21 Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KK21 Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK21 Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK21 Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KK60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BK50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
Position SwitchesSiemens
49 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SIRIUS 3SE5 Position Switches, Metal, 31 mm (EN 50047)

Brand Siemens·Position Switches

Available part numbers (49)

3SE5212-0BC05, 3SE5212-0KC05, 3SE5212-0PC05, 3SE5212-0MC05, 3SE5212-0CC05, 3SE5212-0LC05, 3SE5212-0BC05-1CA0, 3SE5212-0KC05-1CA0, 3SE5212-0PC05-1CA0, 3SE5212-0MC05-1CA0 + 39 more — see full table ↓

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
3SE5212-0BC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0PC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0MC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0PC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0MC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break; Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LC05-1CA0Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5212-1KC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-3KC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-1LC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5212-3LC05Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5214-0BC05-1AC5Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0KC05-1AE1Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0CC05-1AC5Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-0LC05-1AE1Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 2 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-1BC05-1AF3Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5214-1CC05-1AF3Actuator: Rounded plunger, type B | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5212-0BB01Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KB01Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CB01Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LB01Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BD03Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KD03Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CD03Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LD03Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KD10Actuator: Roller plunger with central fixing | Lever/plunger: - | Roller: Plastic roller 10 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BE10Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KE10Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CE10Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LE10Actuator: Roller lever, type E | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BF10Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KF10Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CF10Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LF10Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 13 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BK21Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KK21Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK21Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK21Actuator: Twist lever, type A | Lever/plunger: Metal lever 21 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0KK60Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK60Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK60Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0BK50Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0CK50Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5212-0LK50Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5

Need a different model, or a part not listed here? Send us your parts list →
