Siemens SIRIUS 3SE5 Position Switches, Metal, 40 mm (EN 50041)

Siemens SIRIUS 3SE5 Position Switches, Metal, 40 mm (EN 50041)

SIRIUS 3SE51 mechanical position switches in a 40 mm metal enclosure to EN 50041, as complete units and basic switches.

Key features

  • Modular system: enclosure, contact block and actuator head can be replaced individually
  • Positive opening NC contacts according to IEC 60947-5-1, Annex K for safety circuits
  • Slow-action or snap-action contact blocks with 2 or 3 contacts
  • Optional 2 LEDs (yellow/green) for 24 V DC or 230 V AC switching-state display
  • Actuator heads can be rotated in 90° steps

Specifications

Brand Siemens
Product line SIRIUS 3SE51 (3SE511)
Enclosure Metal, width 40 mm
Standard EN 50041
Degree of protection IP66 / IP67
Cable entry 1 x M20 x 1.5
Category Position Switches
Source Siemens Catalog IC 10 · 2026, p. 1104-1107
3SE5112-0BB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LB01 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0LB01-1AE3 Actuator: Plain plunger | Lever/plunger: Stainless steel plunger 8.5 mm | Roller: - | Contacts: 2 NC, snap-action | Variant: ET 200 pin assignment | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5112-0BC02 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KC02 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CC02 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LC02 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CC02-1AA7 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Increased operation/restoring force | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0CC02-1AC4 Actuator: Rounded plunger, type B | Lever/plunger: Stainless plunger 10 mm, 3 mm overtravel | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 4-pole (125 V, 4 A)
3SE5112-0BD02 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KD02 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0PD02-1AA7 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 2 NO + 1 NC, slow-action | Variant: Increased operation/restoring force | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CD02 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LD02 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CD02-1AA7 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: Increased operation/restoring force | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LD02-1AA7 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 2 NC, snap-action | Variant: Increased operation/restoring force | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0CD02-1AC5 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0CD02-1AL0 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: Increased operation/restoring force | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-1CD02-1AF3 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-1CD02-1AF5 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0LD02-1AE3 Actuator: Roller plunger, type C | Lever/plunger: - | Roller: Stainless roller 13 mm, 3 mm overtravel | Contacts: 2 NC, snap-action | Variant: ET 200 pin assignment | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5112-0BE01 Actuator: Roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KE01 Actuator: Roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CE01 Actuator: Roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LE01 Actuator: Roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0BF01 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CF01 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LF01 Actuator: Angular roller lever | Lever/plunger: Metal lever | Roller: Plastic roller 22 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CR01 Actuator: Spring rod | Lever/plunger: Plastic plunger 50 mm, length 142.5 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0BH01 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KH01 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH01 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LH01 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0CH01-1AC5 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-1CH01-1AF3 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0LH01-1AE3 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Plastic roller 19 mm | Contacts: 2 NC, snap-action | Variant: ET 200 pin assignment | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5112-0BH02 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Stainless steel roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH02 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Stainless steel roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5114-1CH02-1AF3 Actuator: Twist lever, type A | Lever/plunger: Metal lever 27 mm | Roller: Stainless steel roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5112-0CH24 Actuator: Twist lever, type A | Lever/plunger: Metal lever 30 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0BH60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LH60 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5114-1CH60-1AF3 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid holes | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0CH61-1AC5 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm, with grid hole | Roller: Stainless steel roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5112-0BH50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LH50 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Plastic roller 19 mm | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH51 Actuator: Twist lever, adjustable length | Lever/plunger: Metal lever 100 mm | Roller: Stainless steel roller 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CT11 Actuator: Fork lever, latching | Lever/plunger: Metal lever | Roller: 2 plastic rollers 19 mm | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CH80 Actuator: Rod lever, type D | Lever/plunger: Aluminum rod 200 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0NH82-1AM2 Actuator: Rod lever, type D | Lever/plunger: Aluminum rod 200 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action, short-stroke | Variant: Standard | Connection: Nagara switch, M12 5-pole (125 V, 4 A)
3SE5112-0CH82 Actuator: Rod lever, type D | Lever/plunger: Plastic rod 200 mm | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0BA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0PA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0MA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CA00-1AC1 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Gold-plated contacts | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0BA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0KA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0PA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 2 NO + 1 NC, slow-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0MA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Make-before-break; Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0CA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-0LA00-1CA0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Corrosion-protected | Connection: Cable entry 1 x M20 x 1.5
3SE5112-1KA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5112-3KA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5112-1LA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: Cable entry 1 x M20 x 1.5
3SE5112-3LA00 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: 2 LEDs 230 V AC | Connection: Cable entry 1 x M20 x 1.5
3SE5114-0BA00-1AC5 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0KA00-1AE1 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 2 NC, slow-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0CA00-1AC5 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0LA00-1AE1 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 2 NC, snap-action | Variant: Standard | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-1BA00-1AF3 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, slow-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-1CA00-1AF3 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: 2 LEDs 24 V DC | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5114-0LA00-1AE3 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: ET 200 pin assignment | Connection: M12 plug, 5-pole (125 V, 4 A)
3SE5115-0KA00-1AD1 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, slow-action | Variant: Standard | Connection: Device plug, 6-pole + PE (250 V, 10 A)
3SE5115-0LA00-1AD1 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 2 NC, snap-action | Variant: Standard | Connection: Device plug, 6-pole + PE (250 V, 10 A)
3SE5115-0CA00-1AD0 Actuator: Rounded plunger (basic switch) | Lever/plunger: - | Roller: - | Contacts: 1 NO + 1 NC, snap-action | Variant: Quick-release device | Connection: Device plug, 6-pole + PE (250 V, 10 A)
