SKF 3057(00) C-2Z and 3058(00) C-2Z Double Row Cam Rollers

SKF 3057(00) C-2Z and 3058(00) C-2Z Double Row Cam Rollers

SKF double row cam rollers developed from double row angular contact ball bearings with a 25° contact angle, shielded and greased, with crowned (3058) or cylindrical (3057) runner surface.

Key features

  • Based on double row angular contact ball bearings, 25° contact angle
  • 3058(00) C-2Z with crowned runner surface for misaligned tracks
  • 3057(00) C-2Z with cylindrical (flat) runner surface
  • Pressed steel shields on both sides, greased ready to mount
  • For cam drives and conveyor systems

Specifications

Product type Double row cam roller
Series 3057(00) C-2Z, 3058(00) C-2Z
Contact angle 25°
Shields 2Z, pressed steel
Units mm, kN, r/min
Brand SKF
Source SKF General Catalogue 6000, p. 466-467
305800 C-2Z d: 10 mm | D: 32 mm | B: 14 mm | C: 7.15 kN | C0: 3.8 kN | Limiting speed: 11000 r/min
305801 C-2Z d: 12 mm | D: 35 mm | B: 15.9 mm | C: 9.56 kN | C0: 4.9 kN | Limiting speed: 9500 r/min
305701 C-2Z d: 12 mm | D: 35 mm | B: 15.9 mm | C: 9.56 kN | C0: 4.9 kN | Limiting speed: 9500 r/min
305802 C-2Z d: 15 mm | D: 40 mm | B: 15.9 mm | C: 10.6 kN | C0: 5.85 kN | Limiting speed: 8500 r/min
305702 C-2Z d: 15 mm | D: 40 mm | B: 15.9 mm | C: 10.6 kN | C0: 5.85 kN | Limiting speed: 8500 r/min
305803 C-2Z d: 17 mm | D: 47 mm | B: 17.5 mm | C: 13.5 kN | C0: 7.8 kN | Limiting speed: 8000 r/min
305703 C-2Z d: 17 mm | D: 47 mm | B: 17.5 mm | C: 13.5 kN | C0: 7.8 kN | Limiting speed: 8000 r/min
305804 C-2Z d: 20 mm | D: 52 mm | B: 20.6 mm | C: 17.2 kN | C0: 10 kN | Limiting speed: 7000 r/min
305704 C-2Z d: 20 mm | D: 52 mm | B: 20.6 mm | C: 17.2 kN | C0: 10 kN | Limiting speed: 7000 r/min
305805 C-2Z d: 25 mm | D: 62 mm | B: 20.6 mm | C: 19.5 kN | C0: 12.5 kN | Limiting speed: 6000 r/min
305705 C-2Z d: 25 mm | D: 62 mm | B: 20.6 mm | C: 19.5 kN | C0: 12.5 kN | Limiting speed: 6000 r/min
305806 C-2Z d: 30 mm | D: 72 mm | B: 23.8 mm | C: 27.6 kN | C0: 18.6 kN | Limiting speed: 5000 r/min
305706 C-2Z d: 30 mm | D: 72 mm | B: 23.8 mm | C: 27.6 kN | C0: 18.6 kN | Limiting speed: 5000 r/min
305807 C-2Z d: 35 mm | D: 80 mm | B: 27 mm | C: 33.2 kN | C0: 21.2 kN | Limiting speed: 4300 r/min
305707 C-2Z d: 35 mm | D: 80 mm | B: 27 mm | C: 33.2 kN | C0: 21.2 kN | Limiting speed: 4300 r/min
Track RollersSKF
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF 3057(00) C-2Z and 3058(00) C-2Z Double Row Cam Rollers

Brand SKF·Track Rollers

Available part numbers (15)

305800 C-2Z, 305801 C-2Z, 305701 C-2Z, 305802 C-2Z, 305702 C-2Z, 305803 C-2Z, 305703 C-2Z, 305804 C-2Z, 305704 C-2Z, 305805 C-2Z + 5 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
305800 C-2Zd: 10 mm | D: 32 mm | B: 14 mm | C: 7.15 kN | C0: 3.8 kN | Limiting speed: 11000 r/min
305801 C-2Zd: 12 mm | D: 35 mm | B: 15.9 mm | C: 9.56 kN | C0: 4.9 kN | Limiting speed: 9500 r/min
305701 C-2Zd: 12 mm | D: 35 mm | B: 15.9 mm | C: 9.56 kN | C0: 4.9 kN | Limiting speed: 9500 r/min
305802 C-2Zd: 15 mm | D: 40 mm | B: 15.9 mm | C: 10.6 kN | C0: 5.85 kN | Limiting speed: 8500 r/min
305702 C-2Zd: 15 mm | D: 40 mm | B: 15.9 mm | C: 10.6 kN | C0: 5.85 kN | Limiting speed: 8500 r/min
305803 C-2Zd: 17 mm | D: 47 mm | B: 17.5 mm | C: 13.5 kN | C0: 7.8 kN | Limiting speed: 8000 r/min
305703 C-2Zd: 17 mm | D: 47 mm | B: 17.5 mm | C: 13.5 kN | C0: 7.8 kN | Limiting speed: 8000 r/min
305804 C-2Zd: 20 mm | D: 52 mm | B: 20.6 mm | C: 17.2 kN | C0: 10 kN | Limiting speed: 7000 r/min
305704 C-2Zd: 20 mm | D: 52 mm | B: 20.6 mm | C: 17.2 kN | C0: 10 kN | Limiting speed: 7000 r/min
305805 C-2Zd: 25 mm | D: 62 mm | B: 20.6 mm | C: 19.5 kN | C0: 12.5 kN | Limiting speed: 6000 r/min
305705 C-2Zd: 25 mm | D: 62 mm | B: 20.6 mm | C: 19.5 kN | C0: 12.5 kN | Limiting speed: 6000 r/min
305806 C-2Zd: 30 mm | D: 72 mm | B: 23.8 mm | C: 27.6 kN | C0: 18.6 kN | Limiting speed: 5000 r/min
305706 C-2Zd: 30 mm | D: 72 mm | B: 23.8 mm | C: 27.6 kN | C0: 18.6 kN | Limiting speed: 5000 r/min
305807 C-2Zd: 35 mm | D: 80 mm | B: 27 mm | C: 33.2 kN | C0: 21.2 kN | Limiting speed: 4300 r/min
305707 C-2Zd: 35 mm | D: 80 mm | B: 27 mm | C: 33.2 kN | C0: 21.2 kN | Limiting speed: 4300 r/min
