• SKF FYTJ Oval Flanged Units with Adapter Sleeve (KF)
1 1

SKF FYTJ Oval Flanged Units with Adapter Sleeve (KF)

SKF FYTJ Oval Flanged Units with Adapter Sleeve (KF)

SKF FYTJ Oval Flanged Units with Adapter Sleeve (KF): ready-to-mount Y-bearing units with a cast iron oval-flanged housing; adapter sleeve mounting, for metric and/or inch shafts as listed.

Key features

  • Complete unit: housing plus sealed, greased Y-bearing
  • Self-aligning fit of the sphered bearing in the housing
  • Unit, housing and bearing designations listed for ordering
  • Relubrication or end cover options where listed
  • Metric and inch shaft sizes as listed in the catalogue

Specifications

Product Y-bearing unit
Housing cast iron oval-flanged housing
Brand SKF
Category Mounted Bearing Units
Example designation FYTJ 25 KF
Source SKF Y-bearings and Y-bearing units, p. 214-217
FYTJ 25 KF Shaft: 20 mm | C: 14 kN | C0: 7.8 kN | Bolt spacing J: 99 mm
FYTJ 30 KF Shaft: 25 mm | C: 19.5 kN | C0: 11.2 kN | Bolt spacing J: 117 mm
FYTJ 35 KF Shaft: 30 mm | C: 25.5 kN | C0: 15.3 kN | Bolt spacing J: 130 mm
FYTJ 40 KF Shaft: 35 mm | C: 30.7 kN | C0: 19 kN | Bolt spacing J: 144 mm
FYTJ 45 KF Shaft: 40 mm | C: 33.2 kN | C0: 21.6 kN | Bolt spacing J: 148 mm
FYTJ 50 KF Shaft: 45 mm | C: 35.1 kN | C0: 23.2 kN | Bolt spacing J: 157 mm
Mounted Bearing UnitsSKF
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF FYTJ Oval Flanged Units with Adapter Sleeve (KF)

Brand SKF·Mounted Bearing Units

Available part numbers (6)

FYTJ 25 KF, FYTJ 30 KF, FYTJ 35 KF, FYTJ 40 KF, FYTJ 45 KF, FYTJ 50 KF

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FYTJ 25 KFShaft: 20 mm | C: 14 kN | C0: 7.8 kN | Bolt spacing J: 99 mm
FYTJ 30 KFShaft: 25 mm | C: 19.5 kN | C0: 11.2 kN | Bolt spacing J: 117 mm
FYTJ 35 KFShaft: 30 mm | C: 25.5 kN | C0: 15.3 kN | Bolt spacing J: 130 mm
FYTJ 40 KFShaft: 35 mm | C: 30.7 kN | C0: 19 kN | Bolt spacing J: 144 mm
FYTJ 45 KFShaft: 40 mm | C: 33.2 kN | C0: 21.6 kN | Bolt spacing J: 148 mm
FYTJ 50 KFShaft: 45 mm | C: 35.1 kN | C0: 23.2 kN | Bolt spacing J: 157 mm
