SKF High-pressure Pipes and Flexible Pressure Hoses

SKF High-pressure Pipes and Flexible Pressure Hoses

SKF high-pressure pipes (up to 400 MPa) and flexible pressure hoses (up to 150 MPa) connect SKF oil injection equipment and hydraulic pumps to the workpiece.

Key features

  • Steel pipes with steel balls and swivelling nipples on both ends
  • All pipes pressure tested during production
  • Pipe lengths 1 000-4 000 mm can be ordered (e.g. 227957 S/3000)
  • Flexible hoses for use with quick coupling 729831 A and nipple 729832 A
  • Pipes and hoses hard-marked with service life expiry year

Specifications

Use Oil injection / hydraulic pumps
Source SKF Maintenance and Lubrication Products, p. 74
227957 A/400MP Type: High pressure pipe | Connections: G 1/4 - G 3/4 | Length: 2 000 mm | Max. pressure: 400 MPa | Weight: 0.4 kg
227958 A/400MP Type: High pressure pipe | Connections: G 3/4 - G 3/4 | Length: 2 000 mm | Max. pressure: 400 MPa | Weight: 0.6 kg
1020612 A Type: High pressure pipe | Connections: G 1/4 - G 1/4 | Length: 1 000 mm | Max. pressure: 400 MPa | Weight: 0.5 kg
729126 Type: Flexible hose | Bore: 6.4 mm | Length: 1 500 mm | Max. pressure: 100 MPa | Weight: 0.65 kg
729834 Type: Flexible hose | Bore: 4.8 mm | Length: 3 000 mm | Max. pressure: 150 MPa | Weight: 1.0 kg
Bearing AccessoriesSKF
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF High-pressure Pipes and Flexible Pressure Hoses

Brand SKF·Bearing Accessories

Available part numbers (5)

227957 A/400MP, 227958 A/400MP, 1020612 A, 729126, 729834

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
227957 A/400MPType: High pressure pipe | Connections: G 1/4 - G 3/4 | Length: 2 000 mm | Max. pressure: 400 MPa | Weight: 0.4 kg
227958 A/400MPType: High pressure pipe | Connections: G 3/4 - G 3/4 | Length: 2 000 mm | Max. pressure: 400 MPa | Weight: 0.6 kg
1020612 AType: High pressure pipe | Connections: G 1/4 - G 1/4 | Length: 1 000 mm | Max. pressure: 400 MPa | Weight: 0.5 kg
729126Type: Flexible hose | Bore: 6.4 mm | Length: 1 500 mm | Max. pressure: 100 MPa | Weight: 0.65 kg
729834Type: Flexible hose | Bore: 4.8 mm | Length: 3 000 mm | Max. pressure: 150 MPa | Weight: 1.0 kg
