SKF HMV ..E Hydraulic Nuts, Metric Thread (HMV 10E - HMV 200E)

SKF HMV ..E Hydraulic Nuts, Metric Thread (HMV 10E - HMV 200E)

SKF HMV ..E hydraulic nuts apply the high drive-up forces needed to mount bearings on tapered seatings and to free adapter and withdrawal sleeves, covering shaft diameters from 50 to 1 000 mm.

Key features

  • Quick connection coupling fits on the face or side of the nut
  • Spare piston seals and maintenance kit supplied as standard
  • Nuts from HMV 54E with tommy bars; from HMV 94E with eyebolts
  • Prepared for dial indicators for the SKF Drive-up Method
  • Metric threads ISO 965 (to HMV 40E) and trapezoidal ISO 2901 (HMV 41E up)

Specifications

Mounting fluid LHMF 300
Quick connection nipple 729832 A (included)
Max. oil pressure 80 MPa (<=60E), 40 MPa (62-100E), 25 MPa (>=102E)
Source SKF Maintenance and Lubrication Products, p. 62-64
HMV 10E Thread G: M50x1.5 | d1: 50.5 mm | d3: 114 mm | B: 38 mm | Piston area: 2 900 mm2 | Weight: 2.70 kg
HMV 11E Thread G: M55x2 | d1: 55.5 mm | d3: 120 mm | B: 38 mm | Piston area: 3 150 mm2 | Weight: 2.75 kg
HMV 12E Thread G: M60x2 | d1: 60.5 mm | d3: 125 mm | B: 38 mm | Piston area: 3 300 mm2 | Weight: 2.80 kg
HMV 13E Thread G: M65x2 | d1: 65.5 mm | d3: 130 mm | B: 38 mm | Piston area: 3 600 mm2 | Weight: 3.00 kg
HMV 14E Thread G: M70x2 | d1: 70.5 mm | d3: 135 mm | B: 38 mm | Piston area: 3 800 mm2 | Weight: 3.20 kg
HMV 15E Thread G: M75x2 | d1: 75.5 mm | d3: 140 mm | B: 38 mm | Piston area: 4 000 mm2 | Weight: 3.40 kg
HMV 16E Thread G: M80x2 | d1: 80.5 mm | d3: 146 mm | B: 38 mm | Piston area: 4 200 mm2 | Weight: 3.70 kg
HMV 17E Thread G: M85x2 | d1: 85.5 mm | d3: 150 mm | B: 38 mm | Piston area: 4 400 mm2 | Weight: 3.75 kg
HMV 18E Thread G: M90x2 | d1: 90.5 mm | d3: 156 mm | B: 38 mm | Piston area: 4 700 mm2 | Weight: 4.00 kg
HMV 19E Thread G: M95x2 | d1: 95.5 mm | d3: 162 mm | B: 38 mm | Piston area: 4 900 mm2 | Weight: 4.30 kg
HMV 20E Thread G: M100x2 | d1: 100.5 mm | d3: 166 mm | B: 38 mm | Piston area: 5 100 mm2 | Weight: 4.40 kg
HMV 21E Thread G: M105x2 | d1: 105.5 mm | d3: 172 mm | B: 38 mm | Piston area: 5 300 mm2 | Weight: 4.65 kg
HMV 22E Thread G: M110x2 | d1: 110.5 mm | d3: 178 mm | B: 38 mm | Piston area: 5 600 mm2 | Weight: 4.95 kg
HMV 23E Thread G: M115x2 | d1: 115.5 mm | d3: 182 mm | B: 38 mm | Piston area: 5 800 mm2 | Weight: 5.00 kg
HMV 24E Thread G: M120x2 | d1: 120.5 mm | d3: 188 mm | B: 38 mm | Piston area: 6 000 mm2 | Weight: 5.25 kg
HMV 25E Thread G: M125x2 | d1: 125.5 mm | d3: 192 mm | B: 38 mm | Piston area: 6 200 mm2 | Weight: 5.35 kg
HMV 26E Thread G: M130x2 | d1: 130.5 mm | d3: 198 mm | B: 38 mm | Piston area: 6 400 mm2 | Weight: 5.65 kg
HMV 27E Thread G: M135x2 | d1: 135.5 mm | d3: 204 mm | B: 38 mm | Piston area: 6 600 mm2 | Weight: 5.90 kg
HMV 28E Thread G: M140x2 | d1: 140.5 mm | d3: 208 mm | B: 38 mm | Piston area: 6 800 mm2 | Weight: 6.00 kg
HMV 29E Thread G: M145x2 | d1: 145.5 mm | d3: 214 mm | B: 39 mm | Piston area: 7 300 mm2 | Weight: 6.50 kg
HMV 30E Thread G: M150x2 | d1: 150.5 mm | d3: 220 mm | B: 39 mm | Piston area: 7 500 mm2 | Weight: 6.60 kg
HMV 31E Thread G: M155x3 | d1: 155.5 mm | d3: 226 mm | B: 39 mm | Piston area: 8 100 mm2 | Weight: 6.95 kg
HMV 32E Thread G: M160x3 | d1: 160.5 mm | d3: 232 mm | B: 40 mm | Piston area: 8 600 mm2 | Weight: 7.60 kg
HMV 33E Thread G: M165x3 | d1: 165.5 mm | d3: 238 mm | B: 40 mm | Piston area: 8 900 mm2 | Weight: 7.90 kg
HMV 34E Thread G: M170x3 | d1: 170.5 mm | d3: 244 mm | B: 41 mm | Piston area: 9 400 mm2 | Weight: 8.40 kg
HMV 36E Thread G: M180x3 | d1: 180.5 mm | d3: 256 mm | B: 41 mm | Piston area: 10 300 mm2 | Weight: 9.15 kg
HMV 38E Thread G: M190x3 | d1: 191 mm | d3: 270 mm | B: 42 mm | Piston area: 11 500 mm2 | Weight: 10.5 kg
HMV 40E Thread G: M200x3 | d1: 201 mm | d3: 282 mm | B: 43 mm | Piston area: 12 500 mm2 | Weight: 11.5 kg
HMV 41E Thread G: Tr205x4 | d1: 207 mm | d3: 288 mm | B: 43 mm | Piston area: 12 800 mm2 | Weight: 12.0 kg
HMV 42E Thread G: Tr210x4 | d1: 212 mm | d3: 294 mm | B: 44 mm | Piston area: 13 400 mm2 | Weight: 12.5 kg
HMV 43E Thread G: Tr215x4 | d1: 217 mm | d3: 300 mm | B: 44 mm | Piston area: 13 700 mm2 | Weight: 13.0 kg
HMV 44E Thread G: Tr220x4 | d1: 222 mm | d3: 306 mm | B: 44 mm | Piston area: 14 400 mm2 | Weight: 13.5 kg
HMV 45E Thread G: Tr225x4 | d1: 227 mm | d3: 312 mm | B: 45 mm | Piston area: 15 200 mm2 | Weight: 14.5 kg
HMV 46E Thread G: Tr230x4 | d1: 232 mm | d3: 318 mm | B: 45 mm | Piston area: 15 500 mm2 | Weight: 14.5 kg
HMV 47E Thread G: Tr235x4 | d1: 237 mm | d3: 326 mm | B: 46 mm | Piston area: 16 200 mm2 | Weight: 16.0 kg
HMV 48E Thread G: Tr240x4 | d1: 242 mm | d3: 330 mm | B: 46 mm | Piston area: 16 500 mm2 | Weight: 16.0 kg
HMV 50E Thread G: Tr250x4 | d1: 252 mm | d3: 342 mm | B: 46 mm | Piston area: 17 600 mm2 | Weight: 17.5 kg
HMV 52E Thread G: Tr260x4 | d1: 262 mm | d3: 356 mm | B: 47 mm | Piston area: 18 800 mm2 | Weight: 19.0 kg
HMV 54E Thread G: Tr270x4 | d1: 272 mm | d3: 368 mm | B: 48 mm | Piston area: 19 800 mm2 | Weight: 20.5 kg
HMV 56E Thread G: Tr280x4 | d1: 282 mm | d3: 380 mm | B: 49 mm | Piston area: 21 100 mm2 | Weight: 22.0 kg
HMV 58E Thread G: Tr290x4 | d1: 292 mm | d3: 390 mm | B: 49 mm | Piston area: 22 400 mm2 | Weight: 22.5 kg
HMV 60E Thread G: Tr300x4 | d1: 302 mm | d3: 404 mm | B: 51 mm | Piston area: 23 600 mm2 | Weight: 25.5 kg
HMV 62E Thread G: Tr310x5 | d1: 312 mm | d3: 416 mm | B: 52 mm | Piston area: 24 900 mm2 | Weight: 27.0 kg
HMV 64E Thread G: Tr320x5 | d1: 322 mm | d3: 428 mm | B: 53 mm | Piston area: 26 300 mm2 | Weight: 29.5 kg
HMV 66E Thread G: Tr330x5 | d1: 332 mm | d3: 438 mm | B: 53 mm | Piston area: 27 000 mm2 | Weight: 30.0 kg
HMV 68E Thread G: Tr340x5 | d1: 342 mm | d3: 450 mm | B: 54 mm | Piston area: 28 400 mm2 | Weight: 31.5 kg
HMV 69E Thread G: Tr345x5 | d1: 347 mm | d3: 456 mm | B: 54 mm | Piston area: 29 400 mm2 | Weight: 32.5 kg
HMV 70E Thread G: Tr350x5 | d1: 352 mm | d3: 464 mm | B: 56 mm | Piston area: 29 900 mm2 | Weight: 35.0 kg
HMV 72E Thread G: Tr360x5 | d1: 362 mm | d3: 472 mm | B: 56 mm | Piston area: 31 300 mm2 | Weight: 35.5 kg
HMV 73E Thread G: Tr365x5 | d1: 367 mm | d3: 482 mm | B: 57 mm | Piston area: 31 700 mm2 | Weight: 38.5 kg
HMV 74E Thread G: Tr370x5 | d1: 372 mm | d3: 486 mm | B: 57 mm | Piston area: 32 800 mm2 | Weight: 39.0 kg
HMV 76E Thread G: Tr380x5 | d1: 382 mm | d3: 498 mm | B: 58 mm | Piston area: 33 500 mm2 | Weight: 40.5 kg
HMV 77E Thread G: Tr385x5 | d1: 387 mm | d3: 504 mm | B: 58 mm | Piston area: 34 700 mm2 | Weight: 41.0 kg
HMV 80E Thread G: Tr400x5 | d1: 402 mm | d3: 522 mm | B: 60 mm | Piston area: 36 700 mm2 | Weight: 45.5 kg
HMV 82E Thread G: Tr410x5 | d1: 412 mm | d3: 534 mm | B: 61 mm | Piston area: 38 300 mm2 | Weight: 48.0 kg
HMV 84E Thread G: Tr420x5 | d1: 422 mm | d3: 546 mm | B: 61 mm | Piston area: 40 000 mm2 | Weight: 50.0 kg
HMV 86E Thread G: Tr430x5 | d1: 432 mm | d3: 556 mm | B: 62 mm | Piston area: 40 800 mm2 | Weight: 52.5 kg
HMV 88E Thread G: Tr440x5 | d1: 442 mm | d3: 566 mm | B: 62 mm | Piston area: 42 500 mm2 | Weight: 54.0 kg
HMV 90E Thread G: Tr450x5 | d1: 452 mm | d3: 580 mm | B: 64 mm | Piston area: 44 100 mm2 | Weight: 57.5 kg
HMV 92E Thread G: Tr460x5 | d1: 462 mm | d3: 590 mm | B: 64 mm | Piston area: 45 100 mm2 | Weight: 60.0 kg
HMV 94E Thread G: Tr470x5 | d1: 472 mm | d3: 602 mm | B: 65 mm | Piston area: 46 900 mm2 | Weight: 62.0 kg
HMV 96E Thread G: Tr480x5 | d1: 482 mm | d3: 612 mm | B: 65 mm | Piston area: 48 600 mm2 | Weight: 63.0 kg
HMV 98E Thread G: Tr490x5 | d1: 492 mm | d3: 624 mm | B: 66 mm | Piston area: 49 500 mm2 | Weight: 66.0 kg
HMV 100E Thread G: Tr500x5 | d1: 502 mm | d3: 636 mm | B: 67 mm | Piston area: 51 500 mm2 | Weight: 70.0 kg
HMV 102E Thread G: Tr510x6 | d1: 512 mm | d3: 648 mm | B: 68 mm | Piston area: 53 300 mm2 | Weight: 74.0 kg
HMV 104E Thread G: Tr520x6 | d1: 522 mm | d3: 658 mm | B: 68 mm | Piston area: 54 300 mm2 | Weight: 75.0 kg
HMV 106E Thread G: Tr530x6 | d1: 532 mm | d3: 670 mm | B: 69 mm | Piston area: 56 200 mm2 | Weight: 79.0 kg
HMV 108E Thread G: Tr540x6 | d1: 542 mm | d3: 682 mm | B: 69 mm | Piston area: 58 200 mm2 | Weight: 81.0 kg
HMV 110E Thread G: Tr550x6 | d1: 552 mm | d3: 693 mm | B: 70 mm | Piston area: 59 200 mm2 | Weight: 84.0 kg
HMV 112E Thread G: Tr560x6 | d1: 562 mm | d3: 704 mm | B: 71 mm | Piston area: 61 200 mm2 | Weight: 88.0 kg
HMV 114E Thread G: Tr570x6 | d1: 572 mm | d3: 716 mm | B: 72 mm | Piston area: 63 200 mm2 | Weight: 91.0 kg
HMV 116E Thread G: Tr580x6 | d1: 582 mm | d3: 726 mm | B: 72 mm | Piston area: 64 200 mm2 | Weight: 94.0 kg
HMV 120E Thread G: Tr600x6 | d1: 602 mm | d3: 748 mm | B: 73 mm | Piston area: 67 300 mm2 | Weight: 100 kg
HMV 126E Thread G: Tr630x6 | d1: 632 mm | d3: 782 mm | B: 74 mm | Piston area: 72 900 mm2 | Weight: 110 kg
HMV 130E Thread G: Tr650x6 | d1: 652 mm | d3: 804 mm | B: 75 mm | Piston area: 76 200 mm2 | Weight: 115 kg
HMV 134E Thread G: Tr670x6 | d1: 672 mm | d3: 826 mm | B: 76 mm | Piston area: 79 500 mm2 | Weight: 120 kg
HMV 138E Thread G: Tr690x6 | d1: 692 mm | d3: 848 mm | B: 77 mm | Piston area: 84 200 mm2 | Weight: 127 kg
HMV 142E Thread G: Tr710x7 | d1: 712 mm | d3: 870 mm | B: 78 mm | Piston area: 87 700 mm2 | Weight: 135 kg
HMV 150E Thread G: Tr750x7 | d1: 752 mm | d3: 912 mm | B: 79 mm | Piston area: 95 200 mm2 | Weight: 146 kg
HMV 160E Thread G: Tr800x7 | d1: 802 mm | d3: 965 mm | B: 80 mm | Piston area: 103 900 mm2 | Weight: 161 kg
HMV 170E Thread G: Tr850x7 | d1: 852 mm | d3: 1 020 mm | B: 83 mm | Piston area: 114 600 mm2 | Weight: 181 kg
HMV 180E Thread G: Tr900x7 | d1: 902 mm | d3: 1 075 mm | B: 86 mm | Piston area: 124 100 mm2 | Weight: 205 kg
HMV 190E Thread G: Tr950x8 | d1: 952 mm | d3: 1 126 mm | B: 86 mm | Piston area: 135 700 mm2 | Weight: 218 kg
HMV 200E Thread G: Tr1000x8 | d1: 1 002 mm | d3: 1 180 mm | B: 88 mm | Piston area: 145 800 mm2 | Weight: 239 kg
