SKF FSYE Four-Bolt Pillow Block Roller Bearing Units (Inch)

SKF FSYE Four-Bolt Pillow Block Roller Bearing Units (Inch)

SKF FSYE Four-Bolt Pillow Block inch roller bearing units with spherical roller bearings; N suffix denotes SKF ConCentra (sleeve-mounted) units.

Key features

  • Ready-to-mount units for inch shafts
  • Spherical roller bearing for high load capacity and misalignment
  • N suffix: SKF ConCentra mounting; other units collar-mounted
  • Choice of TriGard, labyrinth and radial shaft seals
  • Interchangeable with common North American mounted units

Specifications

Housing FSYE Four-Bolt Pillow Block
Dimensions Inch
Bearing type Spherical roller
Suffix N SKF ConCentra
Brand SKF
Source SKF Bearing housings and roller bearing units, p. 714-715
FSYE 2 7/16 Shaft: 2 7/16 in. | C: 33300 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 19 lb
FSYE 2 7/16 N Shaft: 2 7/16 in. | C: 43400 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 19 lb
FSYE 2 1/2 Shaft: 2 1/2 in. | C: 33300 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 18.5 lb
FSYE 2 1/2 N Shaft: 2 1/2 in. | C: 43400 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 18.5 lb
FSYE 2 11/16 Shaft: 2 11/16 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 11/16 N Shaft: 2 11/16 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 3/4 Shaft: 2 3/4 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 3/4 N Shaft: 2 3/4 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 15/16 Shaft: 2 15/16 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 2 15/16 N Shaft: 2 15/16 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3 Shaft: 3 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3 N Shaft: 3 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3 7/16 Shaft: 3 7/16 in. | C: 56900 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 7/16 N Shaft: 3 7/16 in. | C: 73100 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 1/2 Shaft: 3 1/2 in. | C: 56900 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 1/2 N Shaft: 3 1/2 in. | C: 73100 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 11/16 Shaft: 3 11/16 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 50.5 lb
FSYE 3 11/16 N Shaft: 3 11/16 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 50.5 lb
FSYE 3 15/16 Shaft: 3 15/16 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 3 15/16 N Shaft: 3 15/16 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4 Shaft: 4 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4 N Shaft: 4 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4 7/16 Shaft: 4 7/16 in. | C: 91700 lbf | Centre height H1: 4 3/4 in. | Length L: 16 5/8 in. | Mass: 71 lb
FSYE 4 1/2 Shaft: 4 1/2 in. | C: 91700 lbf | Centre height H1: 4 3/4 in. | Length L: 16 5/8 in. | Mass: 71 lb
FSYE 4 15/16 Shaft: 4 15/16 in. | C: 123000 lbf | Centre height H1: 5 1/2 in. | Length L: 18 1/2 in. | Mass: 100 lb
Mounted Bearing UnitsSKF
25 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF FSYE Four-Bolt Pillow Block Roller Bearing Units (Inch)

Brand SKF·Mounted Bearing Units

Available part numbers (25)

FSYE 2 7/16, FSYE 2 7/16 N, FSYE 2 1/2, FSYE 2 1/2 N, FSYE 2 11/16, FSYE 2 11/16 N, FSYE 2 3/4, FSYE 2 3/4 N, FSYE 2 15/16, FSYE 2 15/16 N + 15 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FSYE 2 7/16Shaft: 2 7/16 in. | C: 33300 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 19 lb
FSYE 2 7/16 NShaft: 2 7/16 in. | C: 43400 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 19 lb
FSYE 2 1/2Shaft: 2 1/2 in. | C: 33300 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 18.5 lb
FSYE 2 1/2 NShaft: 2 1/2 in. | C: 43400 lbf | Centre height H1: 2 3/4 in. | Length L: 10 1/2 in. | Mass: 18.5 lb
FSYE 2 11/16Shaft: 2 11/16 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 11/16 NShaft: 2 11/16 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 3/4Shaft: 2 3/4 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 3/4 NShaft: 2 3/4 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 25.5 lb
FSYE 2 15/16Shaft: 2 15/16 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 2 15/16 NShaft: 2 15/16 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3Shaft: 3 in. | C: 35500 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3 NShaft: 3 in. | C: 47700 lbf | Centre height H1: 3 1/8 in. | Length L: 12 in. | Mass: 24 lb
FSYE 3 7/16Shaft: 3 7/16 in. | C: 56900 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 7/16 NShaft: 3 7/16 in. | C: 73100 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 1/2Shaft: 3 1/2 in. | C: 56900 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 1/2 NShaft: 3 1/2 in. | C: 73100 lbf | Centre height H1: 3 3/4 in. | Length L: 14 in. | Mass: 36.5 lb
FSYE 3 11/16Shaft: 3 11/16 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 50.5 lb
FSYE 3 11/16 NShaft: 3 11/16 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 50.5 lb
FSYE 3 15/16Shaft: 3 15/16 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 3 15/16 NShaft: 3 15/16 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4Shaft: 4 in. | C: 69900 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4 NShaft: 4 in. | C: 95700 lbf | Centre height H1: 4 1/4 in. | Length L: 15 1/4 in. | Mass: 49.5 lb
FSYE 4 7/16Shaft: 4 7/16 in. | C: 91700 lbf | Centre height H1: 4 3/4 in. | Length L: 16 5/8 in. | Mass: 71 lb
FSYE 4 1/2Shaft: 4 1/2 in. | C: 91700 lbf | Centre height H1: 4 3/4 in. | Length L: 16 5/8 in. | Mass: 71 lb
FSYE 4 15/16Shaft: 4 15/16 in. | C: 123000 lbf | Centre height H1: 5 1/2 in. | Length L: 18 1/2 in. | Mass: 100 lb
