SKF FYE Square Flanged Roller Bearing Units (Inch)

SKF FYE Square Flanged Roller Bearing Units (Inch)

SKF FYE Square Flanged inch roller bearing units with spherical roller bearings; N suffix denotes SKF ConCentra (sleeve-mounted) units.

Key features

  • Ready-to-mount units for inch shafts
  • Spherical roller bearing for high load capacity and misalignment
  • N suffix: SKF ConCentra mounting; other units collar-mounted
  • Choice of TriGard, labyrinth and radial shaft seals
  • Interchangeable with common North American mounted units

Specifications

Housing FYE Square Flanged
Dimensions Inch
Bearing type Spherical roller
Suffix N SKF ConCentra
Brand SKF
Source SKF Bearing housings and roller bearing units, p. 716-717
FYE 1 7/16 Shaft: 1 7/16 in. | C: 16600 lbf | Bolt spacing J: 3 1/2 in. | Length L: 4 5/8 in. | Mass: 7.2 lb
FYE 1 1/2 Shaft: 1 1/2 in. | C: 16600 lbf | Bolt spacing J: 4 1/8 in. | Length L: 5 3/8 in. | Mass: 10 lb
FYE 1 11/16 Shaft: 1 11/16 in. | C: 17300 lbf | Bolt spacing J: 4 1/8 in. | Length L: 5 3/8 in. | Mass: 10 lb
FYE 1 3/4 Shaft: 1 3/4 in. | C: 17300 lbf | Bolt spacing J: 4 1/4 in. | Length L: 5 1/2 in. | Mass: 11 lb
FYE 1 15/16 Shaft: 1 15/16 in. | C: 19000 lbf | Bolt spacing J: 4 1/4 in. | Length L: 5 1/2 in. | Mass: 11 lb
FYE 2 Shaft: 2 in. | C: 19000 lbf | Bolt spacing J: 4 1/4 in. | Length L: 5 1/2 in. | Mass: 11 lb
FYE 2 3/16 Shaft: 2 3/16 in. | C: 22400 lbf | Bolt spacing J: 4 3/4 in. | Length L: 6 1/4 in. | Mass: 13.5 lb
FYE 2 7/16 Shaft: 2 7/16 in. | C: 33300 lbf | Bolt spacing J: 5 3/8 in. | Length L: 6 7/8 in. | Mass: 17.5 lb
FYE 2 1/2 Shaft: 2 1/2 in. | C: 33300 lbf | Bolt spacing J: 5 3/8 in. | Length L: 6 7/8 in. | Mass: 17 lb
FYE 2 11/16 Shaft: 2 11/16 in. | C: 35500 lbf | Bolt spacing J: 6 in. | Length L: 7 5/8 in. | Mass: 28.5 lb
FYE 2 3/4 Shaft: 2 3/4 in. | C: 35500 lbf | Bolt spacing J: 6 in. | Length L: 7 5/8 in. | Mass: 28.5 lb
FYE 2 15/16 Shaft: 2 15/16 in. | C: 35500 lbf | Bolt spacing J: 6 in. | Length L: 7 5/8 in. | Mass: 27 lb
FYE 3 Shaft: 3 in. | C: 35500 lbf | Bolt spacing J: 6 in. | Length L: 7 5/8 in. | Mass: 27 lb
FYE 3 7/16 Shaft: 3 7/16 in. | C: 56900 lbf | Bolt spacing J: 7 in. | Length L: 8 3/4 in. | Mass: 40.5 lb
FYE 3 1/2 Shaft: 3 1/2 in. | C: 56900 lbf | Bolt spacing J: 7 in. | Length L: 8 3/4 in. | Mass: 40 lb
FYE 3 11/16 Shaft: 3 11/16 in. | C: 69900 lbf | Bolt spacing J: 7 3/4 in. | Length L: 9 3/4 in. | Mass: 64 lb
FYE 3 15/16 Shaft: 3 15/16 in. | C: 69900 lbf | Bolt spacing J: 7 3/4 in. | Length L: 9 3/4 in. | Mass: 69 lb
FYE 4 Shaft: 4 in. | C: 69900 lbf | Bolt spacing J: 7 3/4 in. | Length L: 9 3/4 in. | Mass: 68 lb
Mounted Bearing UnitsSKF
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF FYE Square Flanged Roller Bearing Units (Inch)

Brand SKF·Mounted Bearing Units

Available part numbers (18)

FYE 1 7/16, FYE 1 1/2, FYE 1 11/16, FYE 1 3/4, FYE 1 15/16, FYE 2, FYE 2 3/16, FYE 2 7/16, FYE 2 1/2, FYE 2 11/16 + 8 more — see full table ↓
