SKF INSOCOAT NU Cylindrical Roller Bearings (VL0241)

SKF INSOCOAT electrically insulated NU design cylindrical roller bearings with an aluminium oxide coating on the outer ring, for electric motors and generators.

Key features

Plasma-sprayed aluminium oxide coating prevents damage from passing electric current
Dimensionally interchangeable with standard NU bearings
VL0241 coating on the outside surfaces of the outer ring
Suitable for electric motors, generators and traction motors

Specifications

Bearing type	Single row cylindrical roller bearing, NU
Insulation	Aluminium oxide coated outer ring
Bore range d	75-120 mm
Load ratings	C dynamic / C0 static, kN
Design suffix	VL0241
Source	SKF General Catalogue 6000, p. 918

NU 315 ECP/VL0241		d: 75 mm \| D: 160 mm \| B: 37 mm \| C: 280 kN \| C0: 265 kN \| Limiting speed: 5300 r/min
NU 317 ECM/C3VL0241		d: 85 mm \| D: 180 mm \| B: 41 mm \| C: 340 kN \| C0: 335 kN \| Limiting speed: 4800 r/min
NU 218 ECM/C3VL0241		d: 90 mm \| D: 160 mm \| B: 30 mm \| C: 208 kN \| C0: 220 kN \| Limiting speed: 5000 r/min
NU 319 ECM/C3VL0241		d: 95 mm \| D: 200 mm \| B: 45 mm \| C: 390 kN \| C0: 390 kN \| Limiting speed: 4300 r/min
NU 322 ECM/C3VL0241		d: 110 mm \| D: 240 mm \| B: 50 mm \| C: 530 kN \| C0: 540 kN \| Limiting speed: 3400 r/min
NU 324 ECM/C3VL0241		d: 120 mm \| D: 260 mm \| B: 55 mm \| C: 610 kN \| C0: 620 kN \| Limiting speed: 3200 r/min

Cylindrical Roller BearingsSKF

6 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF INSOCOAT NU Cylindrical Roller Bearings (VL0241)

Brand SKF·Cylindrical Roller Bearings

Available part numbers (6)

NU 315 ECP/VL0241, NU 317 ECM/C3VL0241, NU 218 ECM/C3VL0241, NU 319 ECM/C3VL0241, NU 322 ECM/C3VL0241, NU 324 ECM/C3VL0241

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	NU 315 ECP/VL0241	d: 75 mm \| D: 160 mm \| B: 37 mm \| C: 280 kN \| C0: 265 kN \| Limiting speed: 5300 r/min
	NU 317 ECM/C3VL0241	d: 85 mm \| D: 180 mm \| B: 41 mm \| C: 340 kN \| C0: 335 kN \| Limiting speed: 4800 r/min
	NU 218 ECM/C3VL0241	d: 90 mm \| D: 160 mm \| B: 30 mm \| C: 208 kN \| C0: 220 kN \| Limiting speed: 5000 r/min
	NU 319 ECM/C3VL0241	d: 95 mm \| D: 200 mm \| B: 45 mm \| C: 390 kN \| C0: 390 kN \| Limiting speed: 4300 r/min
	NU 322 ECM/C3VL0241	d: 110 mm \| D: 240 mm \| B: 50 mm \| C: 530 kN \| C0: 540 kN \| Limiting speed: 3400 r/min
	NU 324 ECM/C3VL0241	d: 120 mm \| D: 260 mm \| B: 55 mm \| C: 610 kN \| C0: 620 kN \| Limiting speed: 3200 r/min
