SKF Oil Injectors 226400 E, Kits 729101 and Sets THKI (300/400 MPa)

SKF Oil Injectors 226400 E, Kits 729101 and Sets THKI (300/400 MPa)

SKF oil injectors, kits and sets supply 300 or 400 MPa oil pressure for the SKF Oil Injection Method on couplings, gears, railway wheels and pressure joints.

Key features

  • Unused oil returns automatically to the reservoir when pressure is released
  • Oil container capacity 200 cm3; volume per stroke 0.23 cm3
  • Kits include injector, high pressure pipe, gauge, adapter block and nipples
  • THKI sets: stand-mounted injector especially suitable for workshop use
  • Adapter block 226402 with floor support for gauge and pipe connection

Specifications

Oil reservoir 200 cm3
Connecting thread G 3/4
Source SKF Maintenance and Lubrication Products, p. 70, 78
226400 E Type: Oil injector | Max. pressure: 300 MPa | Volume/stroke: 0.23 cm3
226400 E/400 Type: Oil injector | Max. pressure: 400 MPa | Volume/stroke: 0.23 cm3
729101/300MPA Type: Oil injection kit | Max. pressure: 300 MPa | Gauge: 1077589
729101/400MPA Type: Oil injection kit | Max. pressure: 400 MPa | Gauge: 1077589/3
THKI 300 Type: Oil injection set | Max. pressure: 300 MPa | Gauge: 1077589
THKI 400 Type: Oil injection set | Max. pressure: 400 MPa | Gauge: 1077589/3
226402 Type: Adapter block | Max. pressure: 400 MPa | Connections: G 1/2 gauge, G 3/4 pipe | Weight: 2.55 kg
Mounting & Dismounting ToolsSKF
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF Oil Injectors 226400 E, Kits 729101 and Sets THKI (300/400 MPa)

Brand SKF·Mounting & Dismounting Tools

Available part numbers (7)

226400 E, 226400 E/400, 729101/300MPA, 729101/400MPA, THKI 300, THKI 400, 226402
