SKF TMMR F/XL Reversible Jaw Pullers, Sets and Accessories

SKF TMMR F/XL Reversible Jaw Pullers, Sets and Accessories

SKF TMMR reversible jaw pullers are versatile two-arm pullers for internal and external pulling of bearings and other components; the four largest sizes are also available with extra long arms (XL).

Key features

  • Suitable for both external and internal pulling applications
  • Self-locking arms for easy adjustment of grip width
  • Hexagonal head on beam allows rotation of puller and bearing
  • Usable up to full rated load without permanently deforming the arms
  • Zinc passivated arms and beam; sets supplied with a workshop stand

Specifications

Arms 2
Source SKF Maintenance and Lubrication Products, p. 28-29
TMMR 40F External grip: 23-48 mm | Internal grip: 59-67 mm | Arm length: 67 mm | Max. force: 17 kN
TMMR 60F External grip: 23-68 mm | Internal grip: 62-87 mm | Arm length: 82 mm | Max. force: 17 kN
TMMR 80F External grip: 41-83 mm | Internal grip: 95-97 mm | Arm length: 98 mm | Max. force: 40 kN
TMMR 120F External grip: 41-124 mm | Internal grip: 95-139 mm | Arm length: 124 mm | Max. force: 40 kN
TMMR 160F External grip: 68-164 mm | Internal grip: 114-163 mm | Arm length: 143 mm | Max. force: 50 kN
TMMR 200F External grip: 65-204 mm | Internal grip: 114-204 mm | Arm length: 169 mm | Max. force: 50 kN
TMMR 250F External grip: 74-254 mm | Internal grip: 132-254 mm | Arm length: 183 mm | Max. force: 60 kN
TMMR 350F External grip: 74-354 mm | Internal grip: 135-354 mm | Arm length: 238 mm | Max. force: 60 kN
TMMR 160XL External grip: 42-140 mm | Internal grip: 121-188 mm | Arm length: 221 mm | Max. force: 50 kN
TMMR 200XL External grip: 42-180 mm | Internal grip: 121-228 mm | Arm length: 221 mm | Max. force: 50 kN
TMMR 250XL External grip: 44-236 mm | Internal grip: 123-284 mm | Arm length: 221 mm | Max. force: 60 kN
TMMR 350XL External grip: 44-336 mm | Internal grip: 123-384 mm | Arm length: 221 mm | Max. force: 60 kN
TMMR 4F/SET Content: TMMR 60F, 120F, 160F, 250F | Stand: Workshop stand | Pullers: 4
TMMR 8F/SET Content: TMMR 40F-350F + nose piece | Stand: Workshop stand | Pullers: 8
TMMR 8XL/SET Content: 8F/SET + XL arm sets | Stand: Workshop stand | Pullers: 8
TMMR 16/20XL-1 Content: XL arm set (2 pcs) + nose piece | Converts: TMMR 160F, 200F to XL | Type: Accessory
TMMR 25/35XL-1 Content: XL arm set (2 pcs) + nose piece | Converts: TMMR 250F, 350F to XL | Type: Accessory
TMMR 16/35XL-4 Content: Extension arm set (2 pcs) | Length: 125 mm | Type: Accessory
TMMR 16/35XL-5 Content: Spring-loaded nose piece | For: TMMR .. XL | Type: Accessory
Mounting & Dismounting ToolsSKF
19 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF TMMR F/XL Reversible Jaw Pullers, Sets and Accessories

Brand SKF·Mounting & Dismounting Tools

Available part numbers (19)

TMMR 40F, TMMR 60F, TMMR 80F, TMMR 120F, TMMR 160F, TMMR 200F, TMMR 250F, TMMR 350F, TMMR 160XL, TMMR 200XL + 9 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TMMR 40FExternal grip: 23-48 mm | Internal grip: 59-67 mm | Arm length: 67 mm | Max. force: 17 kN
TMMR 60FExternal grip: 23-68 mm | Internal grip: 62-87 mm | Arm length: 82 mm | Max. force: 17 kN
TMMR 80FExternal grip: 41-83 mm | Internal grip: 95-97 mm | Arm length: 98 mm | Max. force: 40 kN
TMMR 120FExternal grip: 41-124 mm | Internal grip: 95-139 mm | Arm length: 124 mm | Max. force: 40 kN
TMMR 160FExternal grip: 68-164 mm | Internal grip: 114-163 mm | Arm length: 143 mm | Max. force: 50 kN
TMMR 200FExternal grip: 65-204 mm | Internal grip: 114-204 mm | Arm length: 169 mm | Max. force: 50 kN
TMMR 250FExternal grip: 74-254 mm | Internal grip: 132-254 mm | Arm length: 183 mm | Max. force: 60 kN
TMMR 350FExternal grip: 74-354 mm | Internal grip: 135-354 mm | Arm length: 238 mm | Max. force: 60 kN
TMMR 160XLExternal grip: 42-140 mm | Internal grip: 121-188 mm | Arm length: 221 mm | Max. force: 50 kN
TMMR 200XLExternal grip: 42-180 mm | Internal grip: 121-228 mm | Arm length: 221 mm | Max. force: 50 kN
TMMR 250XLExternal grip: 44-236 mm | Internal grip: 123-284 mm | Arm length: 221 mm | Max. force: 60 kN
TMMR 350XLExternal grip: 44-336 mm | Internal grip: 123-384 mm | Arm length: 221 mm | Max. force: 60 kN
TMMR 4F/SETContent: TMMR 60F, 120F, 160F, 250F | Stand: Workshop stand | Pullers: 4
TMMR 8F/SETContent: TMMR 40F-350F + nose piece | Stand: Workshop stand | Pullers: 8
TMMR 8XL/SETContent: 8F/SET + XL arm sets | Stand: Workshop stand | Pullers: 8
TMMR 16/20XL-1Content: XL arm set (2 pcs) + nose piece | Converts: TMMR 160F, 200F to XL | Type: Accessory
TMMR 25/35XL-1Content: XL arm set (2 pcs) + nose piece | Converts: TMMR 250F, 350F to XL | Type: Accessory
TMMR 16/35XL-4Content: Extension arm set (2 pcs) | Length: 125 mm | Type: Accessory
TMMR 16/35XL-5Content: Spring-loaded nose piece | For: TMMR .. XL | Type: Accessory
