SKF VJ-PD Shafts for PD Two-Bearing Housings

SKF VJ-PD Shafts for PD Two-Bearing Housings

Ready-machined SKF VJ shafts for PDN 2, PDN 3, PDP and PDR two-bearing housings, supplied with keyways to ISO 773.

Key features

  • Precision-ground shafts matched to PD two-bearing housings
  • VJ-PDNB for PDN 2 and PDN 3, VJ-PDPF for PDP, VJ-PDRJ for PDR housings
  • Keyways for shaft keys to ISO 773
  • Spare part for complete PD units

Specifications

Series VJ-PDNB, VJ-PDPF, VJ-PDRJ
Product Shaft for two-bearing housing
Key standard ISO 773
Brand SKF
Category Bearing Accessories
Source SKF Bearing housings and roller bearing units, p. 580-587
VJ-PDNB 206 Shaft da: 30 mm | Length Bd: 210 mm | Shaft key: 8x7x40 mm | Mass: 1.8 kg
VJ-PDNB 207 Shaft da: 35 mm | Length Bd: 240 mm | Shaft key: 8x7x40 mm | Mass: 2.85 kg
VJ-PDNB 208 Shaft da: 40 mm | Length Bd: 274 mm | Shaft key: 10x8x63 mm | Mass: 4.25 kg
VJ-PDNB 210 Shaft da: 50 mm | Length Bd: 329 mm | Shaft key: 12x8x80 mm | Mass: 7.65 kg
VJ-PDNB 211 Shaft da: 55 mm | Length Bd: 371 mm | Shaft key: 14x9x80 mm | Mass: 10.5 kg
VJ-PDNB 212 Shaft da: 60 mm | Length Bd: 391 mm | Shaft key: 14x9x80 mm | Mass: 13 kg
VJ-PDNB 214 Shaft da: 70 mm | Length Bd: 478 mm | Shaft key: 18x11x100 mm | Mass: 23 kg
VJ-PDNB 215 Shaft da: 75 mm | Length Bd: 478 mm | Shaft key: 18x11x100 mm | Mass: 26.5 kg
VJ-PDNB 216 Shaft da: 80 mm | Length Bd: 512 mm | Shaft key: 20x12x100 mm | Mass: 31.5 kg
VJ-PDNB 218 Shaft da: 90 mm | Length Bd: 562 mm | Shaft key: 22x14x140 mm | Mass: 47.5 kg
VJ-PDNB 220 Shaft da: 100 mm | Length Bd: 607 mm | Shaft key: 25x14x140 mm | Mass: 61 kg
VJ-PDNB 222 Shaft da: 110 mm | Length Bd: 656 mm | Shaft key: 28x16x180 mm | Mass: 83 kg
VJ-PDNB 224 Shaft da: 120 mm | Length Bd: 694 mm | Shaft key: 28x16x180 mm | Mass: 102 kg
VJ-PDNB 305 Shaft da: 25 mm | Length Bd: 216 mm | Shaft key: 6x6x32 mm | Mass: 1.4 kg
VJ-PDNB 306 Shaft da: 30 mm | Length Bd: 240 mm | Shaft key: 8x7x40 mm | Mass: 2.2 kg
VJ-PDNB 307 Shaft da: 35 mm | Length Bd: 274 mm | Shaft key: 8x7x40 mm | Mass: 3.35 kg
VJ-PDNB 308 Shaft da: 40 mm | Length Bd: 331 mm | Shaft key: 10x8x63 mm | Mass: 5.25 kg
VJ-PDNB 309 Shaft da: 45 mm | Length Bd: 376 mm | Shaft key: 10x8x63 mm | Mass: 7.3 kg
VJ-PDNB 310 Shaft da: 50 mm | Length Bd: 393 mm | Shaft key: 12x8x80 mm | Mass: 9.85 kg
VJ-PDNB 311 Shaft da: 55 mm | Length Bd: 438 mm | Shaft key: 14x9x80 mm | Mass: 13 kg
VJ-PDNB 312 Shaft da: 60 mm | Length Bd: 476 mm | Shaft key: 14x9x80 mm | Mass: 15.5 kg
VJ-PDNB 313 Shaft da: 65 mm | Length Bd: 508 mm | Shaft key: 16x10x80 mm | Mass: 19.5 kg
VJ-PDNB 314 Shaft da: 70 mm | Length Bd: 532 mm | Shaft key: 18x11x100 mm | Mass: 25 kg
VJ-PDNB 315 Shaft da: 75 mm | Length Bd: 567 mm | Shaft key: 18x11x100 mm | Mass: 30 kg
VJ-PDNB 316 Shaft da: 80 mm | Length Bd: 576 mm | Shaft key: 20x12x100 mm | Mass: 34.5 kg
VJ-PDNB 317 Shaft da: 85 mm | Length Bd: 610 mm | Shaft key: 20x12x100 mm | Mass: 43 kg
VJ-PDNB 318 Shaft da: 90 mm | Length Bd: 625 mm | Shaft key: 22x14x140 mm | Mass: 51 kg
VJ-PDNB 319 Shaft da: 95 mm | Length Bd: 668 mm | Shaft key: 22x14x140 mm | Mass: 59.5 kg
VJ-PDNB 320 Shaft da: 100 mm | Length Bd: 693 mm | Shaft key: 25x14x140 mm | Mass: 67.5 kg
VJ-PDNB 322 Shaft da: 110 mm | Length Bd: 709 mm | Shaft key: 28x16x180 mm | Mass: 87.5 kg
VJ-PDNB 324 Shaft da: 120 mm | Length Bd: 730 mm | Shaft key: 28x16x180 mm | Mass: 106 kg
VJ-PDPF 2214 Shaft da: 70 mm | Length Bd: 474 mm | Shaft key: 18x11x100 mm | Mass: 23 kg
VJ-PDPF 2216 Shaft da: 80 mm | Length Bd: 508 mm | Shaft key: 20x12x100 mm | Mass: 32.5 kg
VJ-PDPF 2218 Shaft da: 90 mm | Length Bd: 558 mm | Shaft key: 22x14x140 mm | Mass: 46.5 kg
VJ-PDPF 2220 Shaft da: 100 mm | Length Bd: 603 mm | Shaft key: 25x14x140 mm | Mass: 60.5 kg
VJ-PDPF 2222 Shaft da: 110 mm | Length Bd: 652 mm | Shaft key: 28x16x180 mm | Mass: 82 kg
VJ-PDPF 2224 Shaft da: 120 mm | Length Bd: 690 mm | Shaft key: 28x16x180 mm | Mass: 101 kg
VJ-PDRJ 315 Shaft da: 75 mm | Length Bd: 547 mm | Shaft key: 18x11x100 mm | Mass: 29 kg
VJ-PDRJ 316 Shaft da: 80 mm | Length Bd: 568 mm | Shaft key: 20x12x100 mm | Mass: 34 kg
VJ-PDRJ 317 Shaft da: 85 mm | Length Bd: 601 mm | Shaft key: 20x12x100 mm | Mass: 42 kg
VJ-PDRJ 318 Shaft da: 90 mm | Length Bd: 619 mm | Shaft key: 22x14x140 mm | Mass: 50.5 kg
VJ-PDRJ 319 Shaft da: 95 mm | Length Bd: 651 mm | Shaft key: 22x14x140 mm | Mass: 58 kg
VJ-PDRJ 320 Shaft da: 100 mm | Length Bd: 690 mm | Shaft key: 25x14x140 mm | Mass: 67 kg
VJ-PDRJ 322 Shaft da: 110 mm | Length Bd: 703 mm | Shaft key: 28x16x180 mm | Mass: 86.5 kg
VJ-PDRJ 324 Shaft da: 120 mm | Length Bd: 724 mm | Shaft key: 28x16x180 mm | Mass: 104 kg
Bearing AccessoriesSKF
45 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SKF VJ-PD Shafts for PD Two-Bearing Housings

Brand SKF·Bearing Accessories

Available part numbers (45)

VJ-PDNB 206, VJ-PDNB 207, VJ-PDNB 208, VJ-PDNB 210, VJ-PDNB 211, VJ-PDNB 212, VJ-PDNB 214, VJ-PDNB 215, VJ-PDNB 216, VJ-PDNB 218 + 35 more — see full table ↓

How to order

Send the SKF part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
VJ-PDNB 206Shaft da: 30 mm | Length Bd: 210 mm | Shaft key: 8x7x40 mm | Mass: 1.8 kg
VJ-PDNB 207Shaft da: 35 mm | Length Bd: 240 mm | Shaft key: 8x7x40 mm | Mass: 2.85 kg
VJ-PDNB 208Shaft da: 40 mm | Length Bd: 274 mm | Shaft key: 10x8x63 mm | Mass: 4.25 kg
VJ-PDNB 210Shaft da: 50 mm | Length Bd: 329 mm | Shaft key: 12x8x80 mm | Mass: 7.65 kg
VJ-PDNB 211Shaft da: 55 mm | Length Bd: 371 mm | Shaft key: 14x9x80 mm | Mass: 10.5 kg
VJ-PDNB 212Shaft da: 60 mm | Length Bd: 391 mm | Shaft key: 14x9x80 mm | Mass: 13 kg
VJ-PDNB 214Shaft da: 70 mm | Length Bd: 478 mm | Shaft key: 18x11x100 mm | Mass: 23 kg
VJ-PDNB 215Shaft da: 75 mm | Length Bd: 478 mm | Shaft key: 18x11x100 mm | Mass: 26.5 kg
VJ-PDNB 216Shaft da: 80 mm | Length Bd: 512 mm | Shaft key: 20x12x100 mm | Mass: 31.5 kg
VJ-PDNB 218Shaft da: 90 mm | Length Bd: 562 mm | Shaft key: 22x14x140 mm | Mass: 47.5 kg
VJ-PDNB 220Shaft da: 100 mm | Length Bd: 607 mm | Shaft key: 25x14x140 mm | Mass: 61 kg
VJ-PDNB 222Shaft da: 110 mm | Length Bd: 656 mm | Shaft key: 28x16x180 mm | Mass: 83 kg
VJ-PDNB 224Shaft da: 120 mm | Length Bd: 694 mm | Shaft key: 28x16x180 mm | Mass: 102 kg
VJ-PDNB 305Shaft da: 25 mm | Length Bd: 216 mm | Shaft key: 6x6x32 mm | Mass: 1.4 kg
VJ-PDNB 306Shaft da: 30 mm | Length Bd: 240 mm | Shaft key: 8x7x40 mm | Mass: 2.2 kg
VJ-PDNB 307Shaft da: 35 mm | Length Bd: 274 mm | Shaft key: 8x7x40 mm | Mass: 3.35 kg
VJ-PDNB 308Shaft da: 40 mm | Length Bd: 331 mm | Shaft key: 10x8x63 mm | Mass: 5.25 kg
VJ-PDNB 309Shaft da: 45 mm | Length Bd: 376 mm | Shaft key: 10x8x63 mm | Mass: 7.3 kg
VJ-PDNB 310Shaft da: 50 mm | Length Bd: 393 mm | Shaft key: 12x8x80 mm | Mass: 9.85 kg
VJ-PDNB 311Shaft da: 55 mm | Length Bd: 438 mm | Shaft key: 14x9x80 mm | Mass: 13 kg
VJ-PDNB 312Shaft da: 60 mm | Length Bd: 476 mm | Shaft key: 14x9x80 mm | Mass: 15.5 kg
VJ-PDNB 313Shaft da: 65 mm | Length Bd: 508 mm | Shaft key: 16x10x80 mm | Mass: 19.5 kg
VJ-PDNB 314Shaft da: 70 mm | Length Bd: 532 mm | Shaft key: 18x11x100 mm | Mass: 25 kg
VJ-PDNB 315Shaft da: 75 mm | Length Bd: 567 mm | Shaft key: 18x11x100 mm | Mass: 30 kg
VJ-PDNB 316Shaft da: 80 mm | Length Bd: 576 mm | Shaft key: 20x12x100 mm | Mass: 34.5 kg
VJ-PDNB 317Shaft da: 85 mm | Length Bd: 610 mm | Shaft key: 20x12x100 mm | Mass: 43 kg
VJ-PDNB 318Shaft da: 90 mm | Length Bd: 625 mm | Shaft key: 22x14x140 mm | Mass: 51 kg
VJ-PDNB 319Shaft da: 95 mm | Length Bd: 668 mm | Shaft key: 22x14x140 mm | Mass: 59.5 kg
VJ-PDNB 320Shaft da: 100 mm | Length Bd: 693 mm | Shaft key: 25x14x140 mm | Mass: 67.5 kg
VJ-PDNB 322Shaft da: 110 mm | Length Bd: 709 mm | Shaft key: 28x16x180 mm | Mass: 87.5 kg
VJ-PDNB 324Shaft da: 120 mm | Length Bd: 730 mm | Shaft key: 28x16x180 mm | Mass: 106 kg
VJ-PDPF 2214Shaft da: 70 mm | Length Bd: 474 mm | Shaft key: 18x11x100 mm | Mass: 23 kg
VJ-PDPF 2216Shaft da: 80 mm | Length Bd: 508 mm | Shaft key: 20x12x100 mm | Mass: 32.5 kg
VJ-PDPF 2218Shaft da: 90 mm | Length Bd: 558 mm | Shaft key: 22x14x140 mm | Mass: 46.5 kg
VJ-PDPF 2220Shaft da: 100 mm | Length Bd: 603 mm | Shaft key: 25x14x140 mm | Mass: 60.5 kg
VJ-PDPF 2222Shaft da: 110 mm | Length Bd: 652 mm | Shaft key: 28x16x180 mm | Mass: 82 kg
VJ-PDPF 2224Shaft da: 120 mm | Length Bd: 690 mm | Shaft key: 28x16x180 mm | Mass: 101 kg
VJ-PDRJ 315Shaft da: 75 mm | Length Bd: 547 mm | Shaft key: 18x11x100 mm | Mass: 29 kg
VJ-PDRJ 316Shaft da: 80 mm | Length Bd: 568 mm | Shaft key: 20x12x100 mm | Mass: 34 kg
VJ-PDRJ 317Shaft da: 85 mm | Length Bd: 601 mm | Shaft key: 20x12x100 mm | Mass: 42 kg
VJ-PDRJ 318Shaft da: 90 mm | Length Bd: 619 mm | Shaft key: 22x14x140 mm | Mass: 50.5 kg
VJ-PDRJ 319Shaft da: 95 mm | Length Bd: 651 mm | Shaft key: 22x14x140 mm | Mass: 58 kg
VJ-PDRJ 320Shaft da: 100 mm | Length Bd: 690 mm | Shaft key: 25x14x140 mm | Mass: 67 kg
VJ-PDRJ 322Shaft da: 110 mm | Length Bd: 703 mm | Shaft key: 28x16x180 mm | Mass: 86.5 kg
VJ-PDRJ 324Shaft da: 120 mm | Length Bd: 724 mm | Shaft key: 28x16x180 mm | Mass: 104 kg
