SMC AR20-D Modular Regulator

SMC AR20-D Modular Regulator

SMC modular pneumatic regulator (clean/low-particle spec).

Key features

  • Body size 20, port size: 1/8, 1/4
  • Setting pressure 0.05–0.85 MPa, max working pressure 1.0 MPa
  • Mass: 0.14 kg
  • Threads: Rc / NPT / G
  • Options: bracket, square embedded gauge, round gauge
  • Other options (set nut H, light-angle gauge J, color zone M, digital pressure switch E1–E4, low-pressure spec, non-relief, reverse flow direction, psi units) available on request

Specifications

Body size 20
Reverse flow No
Setting pressure 0.05–0.85 MPa
Max working pressure 1.0 MPa
Construction Relief type
Spec Clean/Low-particle (-D)
AR20-01-D Rc 1/8, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01E-D Rc 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01G-D Rc 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01B-D Rc 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01BE-D Rc 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01BG-D Rc 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02-D Rc 1/4, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02E-D Rc 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02G-D Rc 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02B-D Rc 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02BE-D Rc 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02BG-D Rc 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01-D NPT 1/8, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01E-D NPT 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01G-D NPT 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01B-D NPT 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01BE-D NPT 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01BG-D NPT 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02-D NPT 1/4, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02E-D NPT 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02G-D NPT 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02B-D NPT 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02BE-D NPT 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02BG-D NPT 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01-D G 1/8, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01E-D G 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01G-D G 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01B-D G 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01BE-D G 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01BG-D G 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02-D G 1/4, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02E-D G 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02G-D G 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02B-D G 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02BE-D G 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02BG-D G 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
RegulatorsSMC
36 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AR20-D Modular Regulator

Brand SMC·Regulators

Available part numbers (36)

AR20-01-D, AR20-01E-D, AR20-01G-D, AR20-01B-D, AR20-01BE-D, AR20-01BG-D, AR20-02-D, AR20-02E-D, AR20-02G-D, AR20-02B-D + 26 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AR20-01-DRc 1/8, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01E-DRc 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01G-DRc 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01B-DRc 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01BE-DRc 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-01BG-DRc 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02-DRc 1/4, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02E-DRc 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02G-DRc 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02B-DRc 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02BE-DRc 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-02BG-DRc 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: Rc | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01-DNPT 1/8, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01E-DNPT 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01G-DNPT 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01B-DNPT 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01BE-DNPT 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N01BG-DNPT 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02-DNPT 1/4, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02E-DNPT 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02G-DNPT 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02B-DNPT 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02BE-DNPT 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-N02BG-DNPT 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: NPT | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01-DG 1/8, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01E-DG 1/8, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01G-DG 1/8, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01B-DG 1/8, Bracket, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01BE-DG 1/8, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F01BG-DG 1/8, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/8 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02-DG 1/4, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02E-DG 1/4, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02G-DG 1/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02B-DG 1/4, Bracket, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02BE-DG 1/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR20-F02BG-DG 1/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 20 | Thread: G | Port size: 1/4 | Reverse flow: No | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
