• SMC CM2L25 Standard Air Cylinder
1 1

SMC CM2L25 Standard Air Cylinder

SMC CM2L25 Standard Air Cylinder

SMC CM2 Series standard air cylinder, double-acting single-rod, rubber cushion.

Key features

  • Bore ø25 mm, axial foot mount
  • Standard strokes 25–200 mm
  • Port thread Rc 1/8
  • Rod end male thread M10×1.25

Specifications

Bore ø25 mm
Mount Axial foot
Action Double-acting, Single-rod
Cushion Rubber
Magnet No
Rod thread M10×1.25 (male)
Port Rc 1/8
CM2L25-25Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 25 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 25 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-50Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 50 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 50 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-75Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 75 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 75 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-100Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 100 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 100 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-125Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 125 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 125 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-150Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 150 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 150 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-200Z1 CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 200 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 200 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
Cylinders | Round Body CylindersSMC
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC CM2L25 Standard Air Cylinder

Brand SMC·Cylinders | Round Body Cylinders

Available part numbers (7)

CM2L25-25Z1, CM2L25-50Z1, CM2L25-75Z1, CM2L25-100Z1, CM2L25-125Z1, CM2L25-150Z1, CM2L25-200Z1

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CM2L25-25Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 25 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 25 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-50Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 50 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 50 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-75Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 75 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 75 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-100Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 100 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 100 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-125Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 125 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 125 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-150Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 150 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 150 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
CM2L25-200Z1CM2 series standard air cylinder, double-acting single-rod, rubber cushion, ø25 mm bore, 200 mm stroke, axial foot mount | Bore: ø25 mm | Stroke: 200 mm | Mount: Axial foot | Action: Double-acting, Single-rod | Cushion: Rubber | Magnet: No | Rod thread: M10×1.25 (male) | Port: Rc 1/8
