SMC JXC51/61 Step Motor Controller (Step Data Input, Parallel I/O)

SMC JXC51/61 single-axis step data input controller for step motor (servo DC24V) LE series electric actuators, with NPN (JXC51) or PNP (JXC61) parallel I/O.

Key features

Up to 64 step data points; set with teaching box (LEC-T1/JX-T1) or ACT Controller 2 / JXC-BCW software
Compatible with incremental and battery-less absolute encoder LE actuators (LEFS, LEFB, LEKFS, LEY, LEYG, LES, LER, LEH, etc.)
Screw or DIN rail (35 mm) mounting; DIN rail sold separately
Listed codes are blank controllers (-BC); controllers preset for a specific actuator are ordered with the actuator part number in place of BC (e.g. JXC5171-LEFS25B-100)
Communication terminating resistor-less version (-XZ34) available as a set part number

Specifications

Code type	Blank controller (-BC), data set by customer
Motor	Step motor (servo DC24V)
Power supply	DC24V ±10%
Current consumption	100 mA or less (controller only)
Encoder	Incremental / battery-less absolute
Parallel input / output	11 inputs / 13 outputs (photo-coupler isolated)
Serial communication	RS485 (LEC-T1, JXC-W2 only)
Actuator cable length	20 m or less
Operating temperature	0 to 55°C (no freezing)
Enclosure	IP30 (except connectors)
Mass	150 g (screw), 170 g (DIN rail)
Source	SMC Korea catalog Controllers JXC/LEC (SMCKR_JXC-_LEC-.pdf), p. 1017-1023 (PDF p. 24-30)

JXC517-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: None
JXC5171-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 1.5 m
JXC5173-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 3 m
JXC5175-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 5 m
JXC518-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: None
JXC5181-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 1.5 m
JXC5183-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 3 m
JXC5185-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 5 m
JXC617-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: None
JXC6171-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 1.5 m
JXC6173-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 3 m
JXC6175-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 5 m
JXC618-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: None
JXC6181-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 1.5 m
JXC6183-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 3 m
JXC6185-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 5 m
