SMC KS/KX Rotary One-touch Fitting (Standard / High-speed)

SMC KS/KX Rotary One-touch Fitting (Standard / High-speed)

SMC KS (standard) and KX (high-speed) rotary one-touch fittings with ball bearings and a low-friction rotary seal for tube connections on rotating and swinging robot parts.

Key features

  • Ball bearing and special rotary seal give low rotating torque (0.006 to 0.022 N·m at 0.5 MPa)
  • KS standard type with oil-impregnated plain bearing: allowable speed 4.2 to 8.4 rps
  • KX high-speed type with FKM X-ring seal, scraper and SUS440C bearings: allowable speed 16.7 to 25 rps
  • Male connector (KSH/KXH, with tube anti-rotation) and male elbow (KSL/KXL) types
  • Brass parts electroless nickel plated; sealant on R threads as standard

Specifications

Fluid Air
Operating pressure range -100 kPa to 1 MPa
Proof pressure 3 MPa
Ambient and fluid temperature -5 to 60°C (no freezing)
Applicable tube material FEP, PFA, nylon, soft nylon, polyurethane
Thread R (JIS B0203), M5/M6 (JIS B0205)
Body material PBT
Brass parts surface Electroless nickel plated
Source SMC Korea catalog KS/KX Series (SMCKR_KS_KX.pdf), p. 160-163
KSH04-M5 Series: KS (standard) | Type: Rotary male connector | Tube OD: ø4 | Thread: M5x0.8
KSH04-M6 Series: KS (standard) | Type: Rotary male connector | Tube OD: ø4 | Thread: M6x1
KSH04-01S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø4 | Thread: R1/8
KSH06-M5 Series: KS (standard) | Type: Rotary male connector | Tube OD: ø6 | Thread: M5x0.8
KSH06-M6 Series: KS (standard) | Type: Rotary male connector | Tube OD: ø6 | Thread: M6x1
KSH06-01S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø6 | Thread: R1/8
KSH06-02S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø6 | Thread: R1/4
KSH08-01S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø8 | Thread: R1/8
KSH08-02S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø8 | Thread: R1/4
KSH08-03S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø8 | Thread: R3/8
KSH10-02S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø10 | Thread: R1/4
KSH10-03S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø10 | Thread: R3/8
KSH10-04S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø10 | Thread: R1/2
KSH12-03S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø12 | Thread: R3/8
KSH12-04S Series: KS (standard) | Type: Rotary male connector | Tube OD: ø12 | Thread: R1/2
KXH04-M5 Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø4 | Thread: M5x0.8
KXH04-M6 Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø4 | Thread: M6x1
KXH04-01S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø4 | Thread: R1/8
KXH06-M5 Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø6 | Thread: M5x0.8
KXH06-M6 Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø6 | Thread: M6x1
KXH06-01S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø6 | Thread: R1/8
KXH06-02S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø6 | Thread: R1/4
KXH08-01S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø8 | Thread: R1/8
KXH08-02S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø8 | Thread: R1/4
KXH08-03S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø8 | Thread: R3/8
KXH10-02S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø10 | Thread: R1/4
KXH10-03S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø10 | Thread: R3/8
KXH10-04S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø10 | Thread: R1/2
KXH12-03S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø12 | Thread: R3/8
KXH12-04S Series: KX (high-speed) | Type: Rotary male connector | Tube OD: ø12 | Thread: R1/2
KSL04-M5 Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø4 | Thread: M5x0.8
KSL04-M6 Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø4 | Thread: M6x1
KSL04-01S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø4 | Thread: R1/8
KSL06-M5 Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø6 | Thread: M5x0.8
KSL06-M6 Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø6 | Thread: M6x1
KSL06-01S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø6 | Thread: R1/8
KSL06-02S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø6 | Thread: R1/4
KSL08-01S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R1/8
KSL08-02S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R1/4
KSL08-03S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R3/8
KSL10-02S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R1/4
KSL10-03S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R3/8
KSL10-04S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R1/2
KSL12-03S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø12 | Thread: R3/8
KSL12-04S Series: KS (standard) | Type: Rotary male elbow | Tube OD: ø12 | Thread: R1/2
KXL04-M5 Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø4 | Thread: M5x0.8
KXL04-M6 Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø4 | Thread: M6x1
KXL04-01S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø4 | Thread: R1/8
KXL06-M5 Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø6 | Thread: M5x0.8
KXL06-M6 Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø6 | Thread: M6x1
KXL06-01S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø6 | Thread: R1/8
KXL06-02S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø6 | Thread: R1/4
KXL08-01S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R1/8
KXL08-02S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R1/4
KXL08-03S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø8 | Thread: R3/8
KXL10-02S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R1/4
KXL10-03S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R3/8
KXL10-04S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø10 | Thread: R1/2
KXL12-03S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø12 | Thread: R3/8
KXL12-04S Series: KX (high-speed) | Type: Rotary male elbow | Tube OD: ø12 | Thread: R1/2
