SMC TRB Flame-Resistant Double-Layer Tubing (Nylon/PVC)

SMC TRB Flame-Resistant Double-Layer Tubing (Nylon/PVC)

SMC TRB series flame-resistant double-layer tubing: nylon 12 inner tube with a UL-94 V-0 equivalent PVC outer layer, for spatter environments such as spot welding.

Key features

  • Two-layer construction: black nylon 12 inner tube, flame-resistant PVC outer layer (1 mm)
  • Inner tube sizes 6 to 12 mm OD; six outer layer colors (opaque)
  • 20 m rolls and 100 m reels
  • Outer layer marked with fitting insertion pitch; strip the outer layer before connecting (TKS stripper)
  • Recommended fittings: FR one-touch KR-W2 series

Specifications

Material Inner nylon 12, outer PVC (UL-94 V-0 equivalent)
Fluid Air, water
Max. operating pressure 1.0 MPa at 20C; 0.8 to 1.0 at 40C; 0.6 to 1.0 at 60C
Max. operating vacuum -101.3 kPa
Operating temperature -20 to 60C (water 0 to 60C)
Min. bending radius 15 to 45 mm depending on size
Inner tube color Black
Standards RoHS
Source SMC Korea catalog (SMCKR_TRB.pdf), p. 702-703
TRB0604B-20 Tube size: 6 x 4 mm | Color: Black (B) | Length: 20 m roll
TRB0604B-100 Tube size: 6 x 4 mm | Color: Black (B) | Length: 100 m reel
TRB0604W-20 Tube size: 6 x 4 mm | Color: White (W) | Length: 20 m roll
TRB0604W-100 Tube size: 6 x 4 mm | Color: White (W) | Length: 100 m reel
TRB0604R-20 Tube size: 6 x 4 mm | Color: Red (R) | Length: 20 m roll
TRB0604R-100 Tube size: 6 x 4 mm | Color: Red (R) | Length: 100 m reel
TRB0604BU-20 Tube size: 6 x 4 mm | Color: Blue (BU) | Length: 20 m roll
TRB0604BU-100 Tube size: 6 x 4 mm | Color: Blue (BU) | Length: 100 m reel
TRB0604Y-20 Tube size: 6 x 4 mm | Color: Yellow (Y) | Length: 20 m roll
TRB0604Y-100 Tube size: 6 x 4 mm | Color: Yellow (Y) | Length: 100 m reel
TRB0604G-20 Tube size: 6 x 4 mm | Color: Green (G) | Length: 20 m roll
TRB0604G-100 Tube size: 6 x 4 mm | Color: Green (G) | Length: 100 m reel
TRB0806B-20 Tube size: 8 x 6 mm | Color: Black (B) | Length: 20 m roll
TRB0806B-100 Tube size: 8 x 6 mm | Color: Black (B) | Length: 100 m reel
TRB0806W-20 Tube size: 8 x 6 mm | Color: White (W) | Length: 20 m roll
TRB0806W-100 Tube size: 8 x 6 mm | Color: White (W) | Length: 100 m reel
TRB0806R-20 Tube size: 8 x 6 mm | Color: Red (R) | Length: 20 m roll
TRB0806R-100 Tube size: 8 x 6 mm | Color: Red (R) | Length: 100 m reel
TRB0806BU-20 Tube size: 8 x 6 mm | Color: Blue (BU) | Length: 20 m roll
TRB0806BU-100 Tube size: 8 x 6 mm | Color: Blue (BU) | Length: 100 m reel
TRB0806Y-20 Tube size: 8 x 6 mm | Color: Yellow (Y) | Length: 20 m roll
TRB0806Y-100 Tube size: 8 x 6 mm | Color: Yellow (Y) | Length: 100 m reel
TRB0806G-20 Tube size: 8 x 6 mm | Color: Green (G) | Length: 20 m roll
TRB0806G-100 Tube size: 8 x 6 mm | Color: Green (G) | Length: 100 m reel
TRB1075B-20 Tube size: 10 x 7.5 mm | Color: Black (B) | Length: 20 m roll
TRB1075B-100 Tube size: 10 x 7.5 mm | Color: Black (B) | Length: 100 m reel
TRB1075W-20 Tube size: 10 x 7.5 mm | Color: White (W) | Length: 20 m roll
TRB1075W-100 Tube size: 10 x 7.5 mm | Color: White (W) | Length: 100 m reel
TRB1075R-20 Tube size: 10 x 7.5 mm | Color: Red (R) | Length: 20 m roll
TRB1075R-100 Tube size: 10 x 7.5 mm | Color: Red (R) | Length: 100 m reel
TRB1075BU-20 Tube size: 10 x 7.5 mm | Color: Blue (BU) | Length: 20 m roll
TRB1075BU-100 Tube size: 10 x 7.5 mm | Color: Blue (BU) | Length: 100 m reel
TRB1075Y-20 Tube size: 10 x 7.5 mm | Color: Yellow (Y) | Length: 20 m roll
TRB1075Y-100 Tube size: 10 x 7.5 mm | Color: Yellow (Y) | Length: 100 m reel
TRB1075G-20 Tube size: 10 x 7.5 mm | Color: Green (G) | Length: 20 m roll
TRB1075G-100 Tube size: 10 x 7.5 mm | Color: Green (G) | Length: 100 m reel
TRB1209B-20 Tube size: 12 x 9 mm | Color: Black (B) | Length: 20 m roll
TRB1209B-100 Tube size: 12 x 9 mm | Color: Black (B) | Length: 100 m reel
TRB1209W-20 Tube size: 12 x 9 mm | Color: White (W) | Length: 20 m roll
TRB1209W-100 Tube size: 12 x 9 mm | Color: White (W) | Length: 100 m reel
TRB1209R-20 Tube size: 12 x 9 mm | Color: Red (R) | Length: 20 m roll
TRB1209R-100 Tube size: 12 x 9 mm | Color: Red (R) | Length: 100 m reel
TRB1209BU-20 Tube size: 12 x 9 mm | Color: Blue (BU) | Length: 20 m roll
TRB1209BU-100 Tube size: 12 x 9 mm | Color: Blue (BU) | Length: 100 m reel
TRB1209Y-20 Tube size: 12 x 9 mm | Color: Yellow (Y) | Length: 20 m roll
TRB1209Y-100 Tube size: 12 x 9 mm | Color: Yellow (Y) | Length: 100 m reel
TRB1209G-20 Tube size: 12 x 9 mm | Color: Green (G) | Length: 20 m roll
TRB1209G-100 Tube size: 12 x 9 mm | Color: Green (G) | Length: 100 m reel
TubingSMC
48 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC TRB Flame-Resistant Double-Layer Tubing (Nylon/PVC)

Brand SMC·Tubing

Available part numbers (48)

TRB0604B-20, TRB0604B-100, TRB0604W-20, TRB0604W-100, TRB0604R-20, TRB0604R-100, TRB0604BU-20, TRB0604BU-100, TRB0604Y-20, TRB0604Y-100 + 38 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
