SMC TUS Soft Polyurethane Flat Tubing (Multi-Core)

SMC TUS Soft Polyurethane Flat Tubing (Multi-Core)

SMC TUS series soft polyurethane flat tubing with 2 to 5 color-coded cores bonded side by side for compact piping.

Key features

  • 2 to 5 cores (X169 to X172 roll specifications)
  • Tube sizes 4 to 12 mm OD; roll lengths 1, 2, 3, 4, 5, 10 and 20 m
  • Core colors from 8: 1 black, 2 white, 3 red, 4 blue, 5 yellow, 6 green, 7 clear, 8 yellow-brown
  • Listed codes use color sequence 1-2-3-...; other sequences can be specified with the digits
  • TJ inner sleeves recommended with one-touch fittings

Specifications

Material Polyurethane (soft)
Fluid Air
Max. operating pressure 0.6 MPa at 20C and 40C, 0.4 MPa at 60C
Max. operating vacuum -101.3 kPa
Operating temperature -20 to 60C
Min. bending radius 8 mm (4 mm OD) to 29 mm (12 mm OD)
Standards RoHS
Source SMC Korea catalog (SMCKR_TUS_p689.pdf), p. 689
TUS0425-12A-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0425-12B-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0425-12C-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0425-12D-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0425-12E-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0425-12F-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0425-12G-X169 Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0604-12A-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0604-12B-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0604-12C-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0604-12D-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0604-12E-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0604-12F-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0604-12G-X169 Tube size: 6 x 4 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0805-12A-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0805-12B-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0805-12C-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0805-12D-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0805-12E-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0805-12F-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0805-12G-X169 Tube size: 8 x 5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS1065-12A-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS1065-12B-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS1065-12C-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS1065-12D-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS1065-12E-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS1065-12F-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS1065-12G-X169 Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS1208-12A-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS1208-12B-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS1208-12C-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS1208-12D-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS1208-12E-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS1208-12F-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS1208-12G-X169 Tube size: 12 x 8 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0425-123A-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0425-123B-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0425-123C-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0425-123D-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0425-123E-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0425-123F-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0425-123G-X170 Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0604-123A-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0604-123B-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0604-123C-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0604-123D-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0604-123E-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0604-123F-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0604-123G-X170 Tube size: 6 x 4 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0805-123A-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0805-123B-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0805-123C-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0805-123D-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0805-123E-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0805-123F-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0805-123G-X170 Tube size: 8 x 5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS1065-123A-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS1065-123B-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS1065-123C-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS1065-123D-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS1065-123E-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS1065-123F-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS1065-123G-X170 Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS1208-123A-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS1208-123B-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS1208-123C-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS1208-123D-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS1208-123E-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS1208-123F-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS1208-123G-X170 Tube size: 12 x 8 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0425-1234A-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234B-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234C-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234D-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234E-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234F-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234G-X171 Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234A-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234B-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234C-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234D-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234E-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234F-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234G-X171 Tube size: 6 x 4 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234A-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234B-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234C-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234D-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234E-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234F-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234G-X171 Tube size: 8 x 5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234A-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234B-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234C-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234D-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234E-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234F-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234G-X171 Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234A-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234B-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234C-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234D-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234E-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234F-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234G-X171 Tube size: 12 x 8 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-12345A-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345B-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345C-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345D-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345E-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345F-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345G-X172 Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345A-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345B-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345C-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345D-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345E-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345F-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345G-X172 Tube size: 6 x 4 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345A-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345B-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345C-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345D-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345E-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345F-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345G-X172 Tube size: 8 x 5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345A-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345B-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345C-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345D-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345E-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345F-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345G-X172 Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345A-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345B-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345C-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345D-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345E-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345F-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345G-X172 Tube size: 12 x 8 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TubingSMC
140 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC TUS Soft Polyurethane Flat Tubing (Multi-Core)

Brand SMC·Tubing

Available part numbers (140)

TUS0425-12A-X169, TUS0425-12B-X169, TUS0425-12C-X169, TUS0425-12D-X169, TUS0425-12E-X169, TUS0425-12F-X169, TUS0425-12G-X169, TUS0604-12A-X169, TUS0604-12B-X169, TUS0604-12C-X169 + 130 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TUS0425-12A-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0425-12B-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0425-12C-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0425-12D-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0425-12E-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0425-12F-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0425-12G-X169Tube size: 4 x 2.5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0604-12A-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0604-12B-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0604-12C-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0604-12D-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0604-12E-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0604-12F-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0604-12G-X169Tube size: 6 x 4 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0805-12A-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS0805-12B-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS0805-12C-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS0805-12D-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS0805-12E-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS0805-12F-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS0805-12G-X169Tube size: 8 x 5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS1065-12A-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS1065-12B-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS1065-12C-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS1065-12D-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS1065-12E-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS1065-12F-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS1065-12G-X169Tube size: 10 x 6.5 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS1208-12A-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 1 m | Color sequence: Bk/Wh
TUS1208-12B-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 2 m | Color sequence: Bk/Wh
TUS1208-12C-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 3 m | Color sequence: Bk/Wh
TUS1208-12D-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 4 m | Color sequence: Bk/Wh
TUS1208-12E-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 5 m | Color sequence: Bk/Wh
TUS1208-12F-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 10 m | Color sequence: Bk/Wh
TUS1208-12G-X169Tube size: 12 x 8 mm | Cores: 2 | Roll length: 20 m | Color sequence: Bk/Wh
TUS0425-123A-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0425-123B-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0425-123C-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0425-123D-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0425-123E-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0425-123F-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0425-123G-X170Tube size: 4 x 2.5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0604-123A-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0604-123B-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0604-123C-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0604-123D-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0604-123E-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0604-123F-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0604-123G-X170Tube size: 6 x 4 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0805-123A-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS0805-123B-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS0805-123C-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS0805-123D-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS0805-123E-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS0805-123F-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS0805-123G-X170Tube size: 8 x 5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS1065-123A-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS1065-123B-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS1065-123C-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS1065-123D-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS1065-123E-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS1065-123F-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS1065-123G-X170Tube size: 10 x 6.5 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS1208-123A-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 1 m | Color sequence: Bk/Wh/Rd
TUS1208-123B-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 2 m | Color sequence: Bk/Wh/Rd
TUS1208-123C-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 3 m | Color sequence: Bk/Wh/Rd
TUS1208-123D-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 4 m | Color sequence: Bk/Wh/Rd
TUS1208-123E-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 5 m | Color sequence: Bk/Wh/Rd
TUS1208-123F-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 10 m | Color sequence: Bk/Wh/Rd
TUS1208-123G-X170Tube size: 12 x 8 mm | Cores: 3 | Roll length: 20 m | Color sequence: Bk/Wh/Rd
TUS0425-1234A-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234B-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234C-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234D-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234E-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234F-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-1234G-X171Tube size: 4 x 2.5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234A-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234B-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234C-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234D-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234E-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234F-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0604-1234G-X171Tube size: 6 x 4 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234A-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234B-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234C-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234D-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234E-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234F-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS0805-1234G-X171Tube size: 8 x 5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234A-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234B-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234C-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234D-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234E-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234F-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS1065-1234G-X171Tube size: 10 x 6.5 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234A-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234B-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234C-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234D-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234E-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234F-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu
TUS1208-1234G-X171Tube size: 12 x 8 mm | Cores: 4 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu
TUS0425-12345A-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345B-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345C-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345D-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345E-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345F-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0425-12345G-X172Tube size: 4 x 2.5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345A-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345B-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345C-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345D-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345E-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345F-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0604-12345G-X172Tube size: 6 x 4 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345A-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345B-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345C-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345D-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345E-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345F-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS0805-12345G-X172Tube size: 8 x 5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345A-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345B-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345C-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345D-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345E-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345F-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1065-12345G-X172Tube size: 10 x 6.5 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345A-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 1 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345B-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 2 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345C-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 3 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345D-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 4 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345E-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 5 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345F-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 10 m | Color sequence: Bk/Wh/Rd/Bu/Ye
TUS1208-12345G-X172Tube size: 12 x 8 mm | Cores: 5 | Roll length: 20 m | Color sequence: Bk/Wh/Rd/Bu/Ye

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Plumbing & Hoses →
