SMC TUZC Wear-Resistant Tubing (Clear Type)

SMC TUZC Wear-Resistant Tubing (Clear Type)

SMC TUZC series wear-resistant polyurethane tubing, clear type, letting fluid and foreign matter be checked inside the tube.

Key features

  • About 1/3 the wear of standard TU polyurethane tubing (SMC comparison)
  • Transparent tube body for visual or camera inspection of the flow
  • Seven colors including translucent natural; 20 m and 100 m rolls for every size
  • Sizes 4 to 12 mm OD
  • Fittings: KQ2 one-touch, KF insert, KFG2 SUS316 insert, M/MS miniature (hose nipple)

Specifications

Material Polyurethane
Fluid Air, water
Max. operating pressure 0.8 MPa at 20C, 0.6 at 40C, 0.4 at 60C
Max. operating vacuum -101.3 kPa
Operating temperature Air -20 to 60C, water 0 to 40C (no freezing)
Min. bending radius 10 mm (4 mm OD) to 35 mm (12 mm OD)
Standards RoHS
Source SMC Korea catalog (SMCKR_TUZC.pdf), p. CAT.KS50-45A, p. 1
TUZC0425B-20 Tube size: 4 x 2.5 mm | Color: Black (B) | Length: 20 m roll
TUZC0425B-100 Tube size: 4 x 2.5 mm | Color: Black (B) | Length: 100 m roll
TUZC0425W-20 Tube size: 4 x 2.5 mm | Color: White (W) | Length: 20 m roll
TUZC0425W-100 Tube size: 4 x 2.5 mm | Color: White (W) | Length: 100 m roll
TUZC0425R-20 Tube size: 4 x 2.5 mm | Color: Red (translucent) (R) | Length: 20 m roll
TUZC0425R-100 Tube size: 4 x 2.5 mm | Color: Red (translucent) (R) | Length: 100 m roll
TUZC0425BU-20 Tube size: 4 x 2.5 mm | Color: Blue (translucent) (BU) | Length: 20 m roll
TUZC0425BU-100 Tube size: 4 x 2.5 mm | Color: Blue (translucent) (BU) | Length: 100 m roll
TUZC0425Y-20 Tube size: 4 x 2.5 mm | Color: Yellow (Y) | Length: 20 m roll
TUZC0425Y-100 Tube size: 4 x 2.5 mm | Color: Yellow (Y) | Length: 100 m roll
TUZC0425G-20 Tube size: 4 x 2.5 mm | Color: Green (G) | Length: 20 m roll
TUZC0425G-100 Tube size: 4 x 2.5 mm | Color: Green (G) | Length: 100 m roll
TUZC0425N-20 Tube size: 4 x 2.5 mm | Color: Translucent (natural) (N) | Length: 20 m roll
TUZC0425N-100 Tube size: 4 x 2.5 mm | Color: Translucent (natural) (N) | Length: 100 m roll
TUZC0604B-20 Tube size: 6 x 4 mm | Color: Black (B) | Length: 20 m roll
TUZC0604B-100 Tube size: 6 x 4 mm | Color: Black (B) | Length: 100 m roll
TUZC0604W-20 Tube size: 6 x 4 mm | Color: White (W) | Length: 20 m roll
TUZC0604W-100 Tube size: 6 x 4 mm | Color: White (W) | Length: 100 m roll
TUZC0604R-20 Tube size: 6 x 4 mm | Color: Red (translucent) (R) | Length: 20 m roll
TUZC0604R-100 Tube size: 6 x 4 mm | Color: Red (translucent) (R) | Length: 100 m roll
TUZC0604BU-20 Tube size: 6 x 4 mm | Color: Blue (translucent) (BU) | Length: 20 m roll
TUZC0604BU-100 Tube size: 6 x 4 mm | Color: Blue (translucent) (BU) | Length: 100 m roll
TUZC0604Y-20 Tube size: 6 x 4 mm | Color: Yellow (Y) | Length: 20 m roll
TUZC0604Y-100 Tube size: 6 x 4 mm | Color: Yellow (Y) | Length: 100 m roll
TUZC0604G-20 Tube size: 6 x 4 mm | Color: Green (G) | Length: 20 m roll
TUZC0604G-100 Tube size: 6 x 4 mm | Color: Green (G) | Length: 100 m roll
TUZC0604N-20 Tube size: 6 x 4 mm | Color: Translucent (natural) (N) | Length: 20 m roll
TUZC0604N-100 Tube size: 6 x 4 mm | Color: Translucent (natural) (N) | Length: 100 m roll
TUZC0805B-20 Tube size: 8 x 5 mm | Color: Black (B) | Length: 20 m roll
TUZC0805B-100 Tube size: 8 x 5 mm | Color: Black (B) | Length: 100 m roll
TUZC0805W-20 Tube size: 8 x 5 mm | Color: White (W) | Length: 20 m roll
TUZC0805W-100 Tube size: 8 x 5 mm | Color: White (W) | Length: 100 m roll
TUZC0805R-20 Tube size: 8 x 5 mm | Color: Red (translucent) (R) | Length: 20 m roll
TUZC0805R-100 Tube size: 8 x 5 mm | Color: Red (translucent) (R) | Length: 100 m roll
TUZC0805BU-20 Tube size: 8 x 5 mm | Color: Blue (translucent) (BU) | Length: 20 m roll
TUZC0805BU-100 Tube size: 8 x 5 mm | Color: Blue (translucent) (BU) | Length: 100 m roll
TUZC0805Y-20 Tube size: 8 x 5 mm | Color: Yellow (Y) | Length: 20 m roll
TUZC0805Y-100 Tube size: 8 x 5 mm | Color: Yellow (Y) | Length: 100 m roll
TUZC0805G-20 Tube size: 8 x 5 mm | Color: Green (G) | Length: 20 m roll
TUZC0805G-100 Tube size: 8 x 5 mm | Color: Green (G) | Length: 100 m roll
TUZC0805N-20 Tube size: 8 x 5 mm | Color: Translucent (natural) (N) | Length: 20 m roll
TUZC0805N-100 Tube size: 8 x 5 mm | Color: Translucent (natural) (N) | Length: 100 m roll
TUZC1065B-20 Tube size: 10 x 6.5 mm | Color: Black (B) | Length: 20 m roll
TUZC1065B-100 Tube size: 10 x 6.5 mm | Color: Black (B) | Length: 100 m roll
TUZC1065W-20 Tube size: 10 x 6.5 mm | Color: White (W) | Length: 20 m roll
TUZC1065W-100 Tube size: 10 x 6.5 mm | Color: White (W) | Length: 100 m roll
TUZC1065R-20 Tube size: 10 x 6.5 mm | Color: Red (translucent) (R) | Length: 20 m roll
TUZC1065R-100 Tube size: 10 x 6.5 mm | Color: Red (translucent) (R) | Length: 100 m roll
TUZC1065BU-20 Tube size: 10 x 6.5 mm | Color: Blue (translucent) (BU) | Length: 20 m roll
TUZC1065BU-100 Tube size: 10 x 6.5 mm | Color: Blue (translucent) (BU) | Length: 100 m roll
TUZC1065Y-20 Tube size: 10 x 6.5 mm | Color: Yellow (Y) | Length: 20 m roll
TUZC1065Y-100 Tube size: 10 x 6.5 mm | Color: Yellow (Y) | Length: 100 m roll
TUZC1065G-20 Tube size: 10 x 6.5 mm | Color: Green (G) | Length: 20 m roll
TUZC1065G-100 Tube size: 10 x 6.5 mm | Color: Green (G) | Length: 100 m roll
TUZC1065N-20 Tube size: 10 x 6.5 mm | Color: Translucent (natural) (N) | Length: 20 m roll
TUZC1065N-100 Tube size: 10 x 6.5 mm | Color: Translucent (natural) (N) | Length: 100 m roll
TUZC1208B-20 Tube size: 12 x 8 mm | Color: Black (B) | Length: 20 m roll
TUZC1208B-100 Tube size: 12 x 8 mm | Color: Black (B) | Length: 100 m roll
TUZC1208W-20 Tube size: 12 x 8 mm | Color: White (W) | Length: 20 m roll
TUZC1208W-100 Tube size: 12 x 8 mm | Color: White (W) | Length: 100 m roll
TUZC1208R-20 Tube size: 12 x 8 mm | Color: Red (translucent) (R) | Length: 20 m roll
TUZC1208R-100 Tube size: 12 x 8 mm | Color: Red (translucent) (R) | Length: 100 m roll
TUZC1208BU-20 Tube size: 12 x 8 mm | Color: Blue (translucent) (BU) | Length: 20 m roll
TUZC1208BU-100 Tube size: 12 x 8 mm | Color: Blue (translucent) (BU) | Length: 100 m roll
TUZC1208Y-20 Tube size: 12 x 8 mm | Color: Yellow (Y) | Length: 20 m roll
TUZC1208Y-100 Tube size: 12 x 8 mm | Color: Yellow (Y) | Length: 100 m roll
TUZC1208G-20 Tube size: 12 x 8 mm | Color: Green (G) | Length: 20 m roll
TUZC1208G-100 Tube size: 12 x 8 mm | Color: Green (G) | Length: 100 m roll
TUZC1208N-20 Tube size: 12 x 8 mm | Color: Translucent (natural) (N) | Length: 20 m roll
TUZC1208N-100 Tube size: 12 x 8 mm | Color: Translucent (natural) (N) | Length: 100 m roll
TubingSMC
70 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC TUZC Wear-Resistant Tubing (Clear Type)

Brand SMC·Tubing

Available part numbers (70)

TUZC0425B-20, TUZC0425B-100, TUZC0425W-20, TUZC0425W-100, TUZC0425R-20, TUZC0425R-100, TUZC0425BU-20, TUZC0425BU-100, TUZC0425Y-20, TUZC0425Y-100 + 60 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
