    SPG SID250 Digital Speed Indicator (100-240 V AC)

    SPG SID250 Digital Speed Indicator (100-240 V AC)

    The SPG SID250 is a 4-digit panel indicator that displays motor speed or gearhead output shaft speed directly for SPG speed control units, SR/SS controllers and X-TOR BLDC drives.

    Key features

    • Displays motor rpm or gearhead output speed using a settable reduction ratio and multiplier
    • 116 reduction ratio settings plus multiplication magnification in 0.005 steps
    • Conveyor speed conversion possible
    • Accepts 12, 15, 24 or 30 pulses per revolution inputs (tacho-generator or open collector)
    • Free-voltage input 100-240 V AC; adaptor available for panel installation

    Specifications

    Rated voltage Single-phase 100-240 V AC, 50/60 Hz
    Operating voltage range 85-264 V AC, 50/60 Hz
    Current consumption 0.1 A
    Display 4-digit
    Ambient temperature 0 to 40 C
    Weight 200 g
    Insulation resistance 100 MOhm or more at 500 V DC
    Dielectric strength 1500 V AC 50/60 Hz, 1 min
    Certification Not certified product
    Source SPG Standard AC Geared Motor catalog, p. 363-366
    SID250 Display: 4-digit | Pulse input: 12/15/24/30 pulses per rev | Applicable: UNIT / SR / SS / X-TOR series
    Digital Speed IndicatorsSPG
    1 product code available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    SPG SID250 Digital Speed Indicator (100-240 V AC)

    Brand SPG·Digital Speed Indicators

    Available part numbers (1)

    SID250

    How to order

    Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

    RFQ List 0 →
    View full details
    Product codes & specifications
    0 selected
    RFQ List (0)
    Product codeSpec
    SID250Display: 4-digit | Pulse input: 12/15/24/30 pulses per rev | Applicable: UNIT / SR / SS / X-TOR series
