• Sumitomo Electric Hardmetal Aurora Coated 4-Flute Square End Mill ASM4000DL
1 1

Sumitomo Electric Hardmetal Aurora Coated 4-Flute Square End Mill ASM4000DL

Sumitomo Electric Hardmetal Aurora Coated 4-Flute Square End Mill ASM4000DL

Aurora (DLC) coated 4-flute square end mill for non-ferrous metals.

Key features

  • Very smooth Aurora (DLC) coating with low adhesion and good finished surface
  • Low cutting resistance, suited to high-feed cutting and low-rigidity workpieces

Specifications

Flutes 4
Grade DL1000
Workpiece Aluminium alloy, Copper alloy
ASM4020DL DC (mm): 2.0 | APMX (mm): 6.0 | LU (mm): 6.8 | LF (mm): 40 | DMM (mm): 4 | Stock: Yes
ASM4030DL DC (mm): 3.0 | APMX (mm): 10.0 | LU (mm): 12.9 | LF (mm): 45 | DMM (mm): 6 | Stock: Yes
ASM4040DL DC (mm): 4.0 | APMX (mm): 12.0 | LU (mm): 14.7 | LF (mm): 45 | DMM (mm): 6 | Stock: Yes
ASM4050DL DC (mm): 5.0 | APMX (mm): 15.0 | LU (mm): 18.6 | LF (mm): 50 | DMM (mm): 6 | Stock: Yes
ASM4060DL DC (mm): 6.0 | APMX (mm): 15.0 | LF (mm): 50 | DMM (mm): 6 | Stock: Yes
ASM4080DL DC (mm): 8.0 | APMX (mm): 18.0 | LF (mm): 60 | DMM (mm): 8 | Stock: Yes
ASM4100DL DC (mm): 10.0 | APMX (mm): 22.0 | LF (mm): 71 | DMM (mm): 10 | Stock: Yes
ASM4120DL DC (mm): 12.0 | APMX (mm): 25.0 | LF (mm): 75 | DMM (mm): 12 | Stock: Yes
ASM4160DL DC (mm): 16.0 | APMX (mm): 32.0 | LF (mm): 90 | DMM (mm): 16 | Stock: Yes
End MillsSumitomo Electric Hardmetal
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sumitomo Electric Hardmetal Aurora Coated 4-Flute Square End Mill ASM4000DL

Brand Sumitomo Electric Hardmetal·End Mills

Available part numbers (9)

ASM4020DL, ASM4030DL, ASM4040DL, ASM4050DL, ASM4060DL, ASM4080DL, ASM4100DL, ASM4120DL, ASM4160DL

How to order

Send the Sumitomo Electric Hardmetal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ASM4020DLDC (mm): 2.0 | APMX (mm): 6.0 | LU (mm): 6.8 | LF (mm): 40 | DMM (mm): 4 | Stock: Yes
ASM4030DLDC (mm): 3.0 | APMX (mm): 10.0 | LU (mm): 12.9 | LF (mm): 45 | DMM (mm): 6 | Stock: Yes
ASM4040DLDC (mm): 4.0 | APMX (mm): 12.0 | LU (mm): 14.7 | LF (mm): 45 | DMM (mm): 6 | Stock: Yes
ASM4050DLDC (mm): 5.0 | APMX (mm): 15.0 | LU (mm): 18.6 | LF (mm): 50 | DMM (mm): 6 | Stock: Yes
ASM4060DLDC (mm): 6.0 | APMX (mm): 15.0 | LF (mm): 50 | DMM (mm): 6 | Stock: Yes
ASM4080DLDC (mm): 8.0 | APMX (mm): 18.0 | LF (mm): 60 | DMM (mm): 8 | Stock: Yes
ASM4100DLDC (mm): 10.0 | APMX (mm): 22.0 | LF (mm): 71 | DMM (mm): 10 | Stock: Yes
ASM4120DLDC (mm): 12.0 | APMX (mm): 25.0 | LF (mm): 75 | DMM (mm): 12 | Stock: Yes
ASM4160DLDC (mm): 16.0 | APMX (mm): 32.0 | LF (mm): 90 | DMM (mm): 16 | Stock: Yes
