Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| BBT30-M8-50 | Connection thread CRKS: M8 | Bore dia DCB (mm): 8.5 | Body dia BD (mm): 15.9 | Body projection L6 (mm): 72 | Length LBX (mm): 50 | Screw depth L7 (mm): 18 | Projection LF (mm): 97 | Air hole: Yes | Stock: Yes | ||
| BBT30-M10-45 | Connection thread CRKS: M10 | Bore dia DCB (mm): 10.5 | Body dia BD (mm): 19.9 | Body projection L6 (mm): 67 | Length LBX (mm): 45 | Screw depth L7 (mm): 20 | Projection LF (mm): 97 | Air hole: Yes | Stock: Yes | ||
| BBT30-M12-40 | Connection thread CRKS: M12 | Bore dia DCB (mm): 12.5 | Body dia BD (mm): 24.9 | Body projection L6 (mm): 62 | Length LBX (mm): 40 | Screw depth L7 (mm): 22 | Projection LF (mm): 97 | Air hole: Yes | Stock: Yes | ||
| BBT30-M16-35 | Connection thread CRKS: M16 | Bore dia DCB (mm): 17 | Body dia BD (mm): 31.9 | Body projection L6 (mm): 57 | Length LBX (mm): 35 | Screw depth L7 (mm): 24 | Projection LF (mm): 97 | Air hole: Yes | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
