Sumitomo Electric Hardmetal SEC-Multi Drill SMD Holder, Flat Shank without Flange

Sumitomo Electric Hardmetal SEC-Multi Drill SMD Holder, Flat Shank without Flange

Steel holder body for SEC-Multi Drill SMD exchangeable heads (MTL / MSL / MEL / MFS), internal coolant, straight shank with flat and no flange.

Key features

  • Accepts MTL, MSL, MEL and MFS heads
  • Hole depth 3D, 5D and 8D
  • Straight shank with flat, no flange

Specifications

Coolant Internal
Shank Flat, no flange
SMDH120M Head DC range (mm): 12.0 to <12.5 | L/D: 3 | LU (mm): 42.0 | OAL (mm): 107.2 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 40.0 | OAL with MFS head (mm): 105.2 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH120L Head DC range (mm): 12.0 to <12.5 | L/D: 5 | LU (mm): 67.0 | OAL (mm): 132.2 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 65.0 | OAL with MFS head (mm): 130.2 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH125M Head DC range (mm): 12.5 to <13.0 | L/D: 3 | LU (mm): 44.0 | OAL (mm): 107.3 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 41.0 | OAL with MFS head (mm): 105.1 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH125L Head DC range (mm): 12.5 to <13.0 | L/D: 5 | LU (mm): 69.0 | OAL (mm): 132.3 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 67.0 | OAL with MFS head (mm): 130.1 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH130M Head DC range (mm): 13.0 to <13.5 | L/D: 3 | LU (mm): 45.0 | OAL (mm): 112.4 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 43.0 | OAL with MFS head (mm): 110.2 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH130L Head DC range (mm): 13.0 to <13.5 | L/D: 5 | LU (mm): 72.0 | OAL (mm): 142.4 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 70.0 | OAL with MFS head (mm): 140.2 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH140M Head DC range (mm): 13.5 to 14.5 | L/D: 3 | LU (mm): 51.0 | OAL (mm): 119.0 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 48.0 | OAL with MFS head (mm): 116.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH140L Head DC range (mm): 13.5 to 14.5 | L/D: 5 | LU (mm): 80.0 | OAL (mm): 149.0 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 77.0 | OAL with MFS head (mm): 146.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH140D Head DC range (mm): 13.5 to 14.5 | L/D: 8 | LU (mm): 123.0 | OAL (mm): 194.0 | LS (mm): 48 | DCON (mm): 16 | LU with MFS head (mm): 121.0 | OAL with MFS head (mm): 191.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH150M Head DC range (mm): >14.5 to 15.5 | L/D: 3 | LU (mm): 54.0 | OAL (mm): 129.2 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 51.0 | OAL with MFS head (mm): 126.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH150L Head DC range (mm): >14.5 to 15.5 | L/D: 5 | LU (mm): 85.0 | OAL (mm): 159.2 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 82.0 | OAL with MFS head (mm): 156.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH150D Head DC range (mm): >14.5 to 15.5 | L/D: 8 | LU (mm): 131.0 | OAL (mm): 204.2 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 129.0 | OAL with MFS head (mm): 201.6 | Cap screw: BXD02208IP | Screw torque (N·m): 0.75~1.00 | Wrench: TRDR08IP | Stock: Yes
SMDH160M Head DC range (mm): >15.5 to 16.5 | L/D: 3 | LU (mm): 57.0 | OAL (mm): 134.4 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 54.0 | OAL with MFS head (mm): 131.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH160L Head DC range (mm): >15.5 to 16.5 | L/D: 5 | LU (mm): 90.0 | OAL (mm): 169.4 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 87.0 | OAL with MFS head (mm): 166.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH160D Head DC range (mm): >15.5 to 16.5 | L/D: 8 | LU (mm): 140.0 | OAL (mm): 214.4 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 137.0 | OAL with MFS head (mm): 211.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH170M Head DC range (mm): >16.5 to 17.5 | L/D: 3 | LU (mm): 60.0 | OAL (mm): 139.6 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 57.0 | OAL with MFS head (mm): 136.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH170L Head DC range (mm): >16.5 to 17.5 | L/D: 5 | LU (mm): 95.0 | OAL (mm): 174.6 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 92.0 | OAL with MFS head (mm): 171.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH170D Head DC range (mm): >16.5 to 17.5 | L/D: 8 | LU (mm): 148.0 | OAL (mm): 224.6 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 145.0 | OAL with MFS head (mm): 221.6 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH180M Head DC range (mm): >17.5 to 18.5 | L/D: 3 | LU (mm): 63.0 | OAL (mm): 144.8 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 60.0 | OAL with MFS head (mm): 141.7 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH180L Head DC range (mm): >17.5 to 18.5 | L/D: 5 | LU (mm): 100.0 | OAL (mm): 179.8 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 97.0 | OAL with MFS head (mm): 176.7 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH180D Head DC range (mm): >17.5 to 18.5 | L/D: 8 | LU (mm): 156.0 | OAL (mm): 229.8 | LS (mm): 50 | DCON (mm): 20 | LU with MFS head (mm): 153.0 | OAL with MFS head (mm): 226.7 | Cap screw: BXD02509IP | Screw torque (N·m): 0.93~1.24 | Wrench: TRDR10IP | Stock: Yes
SMDH190M Head DC range (mm): >18.5 to 19.5 | L/D: 3 | LU (mm): 67.0 | OAL (mm): 160.0 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 63.0 | OAL with MFS head (mm): 156.6 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH190L Head DC range (mm): >18.5 to 19.5 | L/D: 5 | LU (mm): 106.0 | OAL (mm): 195.0 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 102.0 | OAL with MFS head (mm): 191.6 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH190D Head DC range (mm): >18.5 to 19.5 | L/D: 8 | LU (mm): 164.0 | OAL (mm): 255.0 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 161.0 | OAL with MFS head (mm): 251.6 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH200M Head DC range (mm): >19.5 to 20.5 | L/D: 3 | LU (mm): 70.0 | OAL (mm): 160.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 66.0 | OAL with MFS head (mm): 156.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH200L Head DC range (mm): >19.5 to 20.5 | L/D: 5 | LU (mm): 111.0 | OAL (mm): 200.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 107.0 | OAL with MFS head (mm): 196.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH200D Head DC range (mm): >19.5 to 20.5 | L/D: 8 | LU (mm): 172.0 | OAL (mm): 265.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 169.0 | OAL with MFS head (mm): 261.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH210M Head DC range (mm): >20.5 to 21.5 | L/D: 3 | LU (mm): 73.0 | OAL (mm): 160.3 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 69.0 | OAL with MFS head (mm): 156.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH210L Head DC range (mm): >20.5 to 21.5 | L/D: 5 | LU (mm): 116.0 | OAL (mm): 200.3 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 112.0 | OAL with MFS head (mm): 196.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH210D Head DC range (mm): >20.5 to 21.5 | L/D: 8 | LU (mm): 180.0 | OAL (mm): 270.3 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 177.0 | OAL with MFS head (mm): 266.7 | Cap screw: BXD03011IP | Screw torque (N·m): 1.83~2.44 | Wrench: TRDR15IP | Stock: Yes
SMDH220M Head DC range (mm): >21.5 to 22.8 | L/D: 3 | LU (mm): 77.0 | OAL (mm): 165.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 73.0 | OAL with MFS head (mm): 161.3 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH220L Head DC range (mm): >21.5 to 22.8 | L/D: 5 | LU (mm): 123.0 | OAL (mm): 205.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 119.0 | OAL with MFS head (mm): 201.3 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH220D Head DC range (mm): >21.5 to 22.8 | L/D: 8 | LU (mm): 191.0 | OAL (mm): 275.1 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 187.0 | OAL with MFS head (mm): 271.3 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH230M Head DC range (mm): >22.8 to 23.8 | L/D: 3 | LU (mm): 80.0 | OAL (mm): 164.7 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 76.0 | OAL with MFS head (mm): 160.7 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH230L Head DC range (mm): >22.8 to 23.8 | L/D: 5 | LU (mm): 128.0 | OAL (mm): 214.7 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 124.0 | OAL with MFS head (mm): 210.7 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH230D Head DC range (mm): >22.8 to 23.8 | L/D: 8 | LU (mm): 199.0 | OAL (mm): 284.7 | LS (mm): 56 | DCON (mm): 25 | LU with MFS head (mm): 195.0 | OAL with MFS head (mm): 280.7 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH240M Head DC range (mm): >23.8 to 24.8 | L/D: 3 | LU (mm): 83.0 | OAL (mm): 174.6 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 79.0 | OAL with MFS head (mm): 170.5 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH240L Head DC range (mm): >23.8 to 24.8 | L/D: 5 | LU (mm): 133.0 | OAL (mm): 224.6 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 129.0 | OAL with MFS head (mm): 220.5 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH240D Head DC range (mm): >23.8 to 24.8 | L/D: 8 | LU (mm): 207.0 | OAL (mm): 299.6 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 203.0 | OAL with MFS head (mm): 295.5 | Cap screw: BXD03512IP | Screw torque (N·m): 2.79~3.72 | Wrench: TRDR15IP | Stock: Yes
SMDH250M Head DC range (mm): >24.8 to 25.8 | L/D: 3 | LU (mm): 87.0 | OAL (mm): 174.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 82.0 | OAL with MFS head (mm): 170.4 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH250L Head DC range (mm): >24.8 to 25.8 | L/D: 5 | LU (mm): 138.0 | OAL (mm): 229.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 134.0 | OAL with MFS head (mm): 225.4 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH250D Head DC range (mm): >24.8 to 25.8 | L/D: 8 | LU (mm): 216.0 | OAL (mm): 304.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 211.0 | OAL with MFS head (mm): 300.4 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH260M Head DC range (mm): >25.8 to 26.8 | L/D: 3 | LU (mm): 90.0 | OAL (mm): 179.7 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 85.0 | OAL with MFS head (mm): 175.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH260L Head DC range (mm): >25.8 to 26.8 | L/D: 5 | LU (mm): 143.0 | OAL (mm): 234.7 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 139.0 | OAL with MFS head (mm): 230.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH260D Head DC range (mm): >25.8 to 26.8 | L/D: 8 | LU (mm): 224.0 | OAL (mm): 314.7 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 219.0 | OAL with MFS head (mm): 310.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH270M Head DC range (mm): >26.8 to 27.8 | L/D: 3 | LU (mm): 93.0 | OAL (mm): 179.9 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 88.0 | OAL with MFS head (mm): 175.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH270L Head DC range (mm): >26.8 to 27.8 | L/D: 5 | LU (mm): 149.0 | OAL (mm): 239.9 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 144.0 | OAL with MFS head (mm): 235.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH270D Head DC range (mm): >26.8 to 27.8 | L/D: 8 | LU (mm): 232.0 | OAL (mm): 324.9 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 227.0 | OAL with MFS head (mm): 320.5 | Cap screw: BXD04014IP | Screw torque (N·m): 4.14~5.52 | Wrench: TRDR20IP | Stock: Yes
SMDH280M Head DC range (mm): >27.8 to 28.8 | L/D: 3 | LU (mm): 96.0 | OAL (mm): 185.1 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 91.0 | OAL with MFS head (mm): 180.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH280L Head DC range (mm): >27.8 to 28.8 | L/D: 5 | LU (mm): 154.0 | OAL (mm): 245.1 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 149.0 | OAL with MFS head (mm): 240.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH280D Head DC range (mm): >27.8 to 28.8 | L/D: 8 | LU (mm): 240.0 | OAL (mm): 330.1 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 235.0 | OAL with MFS head (mm): 325.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH290M Head DC range (mm): >28.8 to 29.8 | L/D: 3 | LU (mm): 99.0 | OAL (mm): 190.3 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 94.0 | OAL with MFS head (mm): 185.4 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH290L Head DC range (mm): >28.8 to 29.8 | L/D: 5 | LU (mm): 159.0 | OAL (mm): 250.3 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 154.0 | OAL with MFS head (mm): 245.4 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH290D Head DC range (mm): >28.8 to 29.8 | L/D: 8 | LU (mm): 248.0 | OAL (mm): 340.3 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 243.0 | OAL with MFS head (mm): 335.4 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH300M Head DC range (mm): >29.8 to 30.8 | L/D: 3 | LU (mm): 103.0 | OAL (mm): 190.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 97.0 | OAL with MFS head (mm): 185.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH300L Head DC range (mm): >29.8 to 30.8 | L/D: 5 | LU (mm): 164.0 | OAL (mm): 260.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 159.0 | OAL with MFS head (mm): 255.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH300D Head DC range (mm): >29.8 to 30.8 | L/D: 8 | LU (mm): 257.0 | OAL (mm): 350.5 | LS (mm): 60 | DCON (mm): 32 | LU with MFS head (mm): 251.0 | OAL with MFS head (mm): 345.6 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH320M Head DC range (mm): >30.8 to 32.0 | L/D: 3 | LU (mm): 106.0 | OAL (mm): 200.7 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH320L Head DC range (mm): >30.8 to 32.0 | L/D: 5 | LU (mm): 170.0 | OAL (mm): 265.8 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH320D Head DC range (mm): >30.8 to 32.0 | L/D: 8 | LU (mm): 266.0 | OAL (mm): 360.8 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH335M Head DC range (mm): >32.0 to 33.5 | L/D: 3 | LU (mm): 111.0 | OAL (mm): 205.9 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH335L Head DC range (mm): >32.0 to 33.5 | L/D: 5 | LU (mm): 178.0 | OAL (mm): 274.1 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH335D Head DC range (mm): >32.0 to 33.5 | L/D: 8 | LU (mm): 279.0 | OAL (mm): 376.1 | LS (mm): 60 | DCON (mm): 32 | Cap screw: BXD04515IP | Screw torque (N·m): 4.98~6.64 | Wrench: TRDR25IP | Stock: Yes
SMDH350M Head DC range (mm): >33.5 to 35.0 | L/D: 3 | LU (mm): 116.0 | OAL (mm): 221.2 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH350L Head DC range (mm): >33.5 to 35.0 | L/D: 5 | LU (mm): 186.0 | OAL (mm): 296.4 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH350D Head DC range (mm): >33.5 to 35.0 | L/D: 8 | LU (mm): 291.0 | OAL (mm): 401.4 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH365M Head DC range (mm): >35.0 to 36.5 | L/D: 3 | LU (mm): 121.0 | OAL (mm): 226.4 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH365L Head DC range (mm): >35.0 to 36.5 | L/D: 5 | LU (mm): 194.0 | OAL (mm): 301.6 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH365D Head DC range (mm): >35.0 to 36.5 | L/D: 8 | LU (mm): 303.0 | OAL (mm): 411.6 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH380M Head DC range (mm): >36.5 to 38.0 | L/D: 3 | LU (mm): 125.0 | OAL (mm): 231.7 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH380L Head DC range (mm): >36.5 to 38.0 | L/D: 5 | LU (mm): 201.0 | OAL (mm): 311.9 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH380D Head DC range (mm): >36.5 to 38.0 | L/D: 8 | LU (mm): 315.0 | OAL (mm): 426.9 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH395M Head DC range (mm): >38.0 to 39.5 | L/D: 3 | LU (mm): 130.0 | OAL (mm): 237.0 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH395L Head DC range (mm): >38.0 to 39.5 | L/D: 5 | LU (mm): 209.0 | OAL (mm): 322.2 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH395D Head DC range (mm): >38.0 to 39.5 | L/D: 8 | LU (mm): 328.0 | OAL (mm): 437.2 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH410M Head DC range (mm): >39.5 to 41.0 | L/D: 3 | LU (mm): 135.0 | OAL (mm): 252.2 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH410L Head DC range (mm): >39.5 to 41.0 | L/D: 5 | LU (mm): 217.0 | OAL (mm): 332.5 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH410D Head DC range (mm): >39.5 to 41.0 | L/D: 8 | LU (mm): 340.0 | OAL (mm): 457.5 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH425M Head DC range (mm): >41.0 to 42.5 | L/D: 3 | LU (mm): 140.0 | OAL (mm): 257.5 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH425L Head DC range (mm): >41.0 to 42.5 | L/D: 5 | LU (mm): 225.0 | OAL (mm): 342.7 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
SMDH425D Head DC range (mm): >41.0 to 42.5 | L/D: 8 | LU (mm): 352.0 | OAL (mm): 467.7 | LS (mm): 70 | DCON (mm): 40 | Cap screw: BX0515 | Screw torque (N·m): 7.2 | Wrench: HD040 | Stock: Yes
