Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| CSBNR2525-32 | H (mm): 25 | B (mm): 25 | LF (mm): 160 | WF (mm): 21.5 | HF (mm): 25 | LH (mm): 30 | Insert: SNGN0903 | Stock: Yes | ||
| CSBNR2525-42 | H (mm): 25 | B (mm): 25 | LF (mm): 160 | WF (mm): 21.5 | HF (mm): 25 | LH (mm): 35 | Insert: SNGN1203 | Stock: Yes | ||
| FN11R-44A | H (mm): 25 | B (mm): 25 | LF (mm): 160 | WF (mm): 21.5 | HF (mm): 25 | LH (mm): 33 | Insert: SNGN1204 | Stock: Yes | ||
| FN11L-44A | H (mm): 25 | B (mm): 25 | LF (mm): 160 | WF (mm): 21.5 | HF (mm): 25 | LH (mm): 33 | Insert: SNGN1204 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
