Sumitomo Electric Hardmetal SEC-Sumi Dual Mill DGCF 13000R(S) Milling Cutter

Sumitomo Electric Hardmetal SEC-Sumi Dual Mill DGCF 13000R(S) Milling Cutter

General-purpose indexable face milling cutter using double-sided SNMT/SNET (8 corners) or ONMT/ONET (16 corners) inserts for economical, high-efficiency milling with high surface quality (extra-fine pitch version).

Key features

  • Double-sided inserts with up to 16 usable corners
  • High edge strength for high-efficiency machining
  • Burr-suppressing FG/FL breakers
  • Universal grade ACU2500 for steel, stainless steel and cast iron

Specifications

Insert Not included (sold separately)
Pitch Extra-fine pitch
DGCF13050RS DC (mm): 50 (52.9) | DCX max cutting dia (mm): 64(60.8) | DCSFMS boss dia (mm): 40 | LF length (mm): 40 (38.44) | DCB bore dia (mm): 22 | KWW keyway width (mm): 10.4 | KDP keyway depth (mm): 6.3 | CBDP mounting depth (mm): 20 | D1 (mm): 18 | Teeth: 5 | Weight (kg): 0.3 | Stock: Yes
DGCF13063RS DC (mm): 63 (65.9) | DCX max cutting dia (mm): 77(73.8) | DCSFMS boss dia (mm): 50 | LF length (mm): 40 (38.44) | DCB bore dia (mm): 22 | KWW keyway width (mm): 10.4 | KDP keyway depth (mm): 6.3 | CBDP mounting depth (mm): 20 | D1 (mm): 18 | Teeth: 6 | Weight (kg): 0.5 | Stock: Yes
DGCF13080RS DC (mm): 80 (82.9) | DCX max cutting dia (mm): 94(90.8) | DCSFMS boss dia (mm): 60 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 27 | KWW keyway width (mm): 12.4 | KDP keyway depth (mm): 7 | CBDP mounting depth (mm): 25 | D1 (mm): 20 | Teeth: 8 | Weight (kg): 1.1 | Stock: Yes
DGCF13100RS DC (mm): 100 (102.9) | DCX max cutting dia (mm): 114(110.8) | DCSFMS boss dia (mm): 70 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 32 | KWW keyway width (mm): 14.4 | KDP keyway depth (mm): 8.5 | CBDP mounting depth (mm): 32 | D1 (mm): 46 | Teeth: 10 | Weight (kg): 1.4 | Stock: Yes
DGCF13125RS DC (mm): 125 (127.9) | DCX max cutting dia (mm): 139(135.8) | DCSFMS boss dia (mm): 80 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 40 | KWW keyway width (mm): 16.4 | KDP keyway depth (mm): 9.5 | CBDP mounting depth (mm): 29 | D1 (mm): 52 | Teeth: 12 | Weight (kg): 2.7 | Stock: Yes
DGCF13160RS DC (mm): 160 (162.9) | DCX max cutting dia (mm): 174(170.8) | DCSFMS boss dia (mm): 100 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 40 | KWW keyway width (mm): 16.4 | KDP keyway depth (mm): 9.5 | CBDP mounting depth (mm): 29 | D1 (mm): 88 | Teeth: 14 | Weight (kg): 4.4 | Stock: Yes
DGCF13200RS DC (mm): 200 (202.9) | DCX max cutting dia (mm): 214(210.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 60 | KWW keyway width (mm): 25.7 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 130 | Teeth: 16 | Weight (kg): 6.9 | Stock: Yes
DGCF13250RS DC (mm): 250 (252.9) | DCX max cutting dia (mm): 264(260.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 60 | KWW keyway width (mm): 25.7 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 160 | Teeth: 18 | Weight (kg): 10.4 | Stock: Yes
DGCF13080R DC (mm): 80 (82.9) | DCX max cutting dia (mm): 94(90.8) | DCSFMS boss dia (mm): 60 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 25.4 | KWW keyway width (mm): 9.5 | KDP keyway depth (mm): 6 | CBDP mounting depth (mm): 25 | D1 (mm): 20 | Teeth: 8 | Weight (kg): 1.1 | Stock: Yes
DGCF13100R DC (mm): 100 (102.9) | DCX max cutting dia (mm): 114(110.8) | DCSFMS boss dia (mm): 70 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 31.75 | KWW keyway width (mm): 12.7 | KDP keyway depth (mm): 8 | CBDP mounting depth (mm): 32.5 | D1 (mm): 28 | Teeth: 10 | Weight (kg): 2.1 | Stock: Yes
DGCF13125R DC (mm): 125 (127.9) | DCX max cutting dia (mm): 139(135.8) | DCSFMS boss dia (mm): 80 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 38.1 | KWW keyway width (mm): 15.9 | KDP keyway depth (mm): 10 | CBDP mounting depth (mm): 35.5 | D1 (mm): 55 | Teeth: 12 | Weight (kg): 2.7 | Stock: Yes
DGCF13160R DC (mm): 160 (162.9) | DCX max cutting dia (mm): 174(170.8) | DCSFMS boss dia (mm): 100 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 50.8 | KWW keyway width (mm): 19.1 | KDP keyway depth (mm): 11 | CBDP mounting depth (mm): 38 | D1 (mm): 72 | Teeth: 14 | Weight (kg): 4.4 | Stock: Yes
DGCF13200R DC (mm): 200 (202.9) | DCX max cutting dia (mm): 214(210.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 47.625 | KWW keyway width (mm): 25.4 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 130 | Teeth: 16 | Weight (kg): 6.9 | Stock: Yes
DGCF13250R DC (mm): 250 (252.9) | DCX max cutting dia (mm): 264(260.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 47.625 | KWW keyway width (mm): 25.4 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 150 | Teeth: 18 | Weight (kg): 10.9 | Stock: Yes
Milling CuttersSumitomo Electric Hardmetal
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sumitomo Electric Hardmetal SEC-Sumi Dual Mill DGCF 13000R(S) Milling Cutter

Brand Sumitomo Electric Hardmetal·Milling Cutters

Available part numbers (14)

DGCF13050RS, DGCF13063RS, DGCF13080RS, DGCF13100RS, DGCF13125RS, DGCF13160RS, DGCF13200RS, DGCF13250RS, DGCF13080R, DGCF13100R + 4 more — see full table ↓

How to order

Send the Sumitomo Electric Hardmetal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DGCF13050RSDC (mm): 50 (52.9) | DCX max cutting dia (mm): 64(60.8) | DCSFMS boss dia (mm): 40 | LF length (mm): 40 (38.44) | DCB bore dia (mm): 22 | KWW keyway width (mm): 10.4 | KDP keyway depth (mm): 6.3 | CBDP mounting depth (mm): 20 | D1 (mm): 18 | Teeth: 5 | Weight (kg): 0.3 | Stock: Yes
DGCF13063RSDC (mm): 63 (65.9) | DCX max cutting dia (mm): 77(73.8) | DCSFMS boss dia (mm): 50 | LF length (mm): 40 (38.44) | DCB bore dia (mm): 22 | KWW keyway width (mm): 10.4 | KDP keyway depth (mm): 6.3 | CBDP mounting depth (mm): 20 | D1 (mm): 18 | Teeth: 6 | Weight (kg): 0.5 | Stock: Yes
DGCF13080RSDC (mm): 80 (82.9) | DCX max cutting dia (mm): 94(90.8) | DCSFMS boss dia (mm): 60 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 27 | KWW keyway width (mm): 12.4 | KDP keyway depth (mm): 7 | CBDP mounting depth (mm): 25 | D1 (mm): 20 | Teeth: 8 | Weight (kg): 1.1 | Stock: Yes
DGCF13100RSDC (mm): 100 (102.9) | DCX max cutting dia (mm): 114(110.8) | DCSFMS boss dia (mm): 70 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 32 | KWW keyway width (mm): 14.4 | KDP keyway depth (mm): 8.5 | CBDP mounting depth (mm): 32 | D1 (mm): 46 | Teeth: 10 | Weight (kg): 1.4 | Stock: Yes
DGCF13125RSDC (mm): 125 (127.9) | DCX max cutting dia (mm): 139(135.8) | DCSFMS boss dia (mm): 80 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 40 | KWW keyway width (mm): 16.4 | KDP keyway depth (mm): 9.5 | CBDP mounting depth (mm): 29 | D1 (mm): 52 | Teeth: 12 | Weight (kg): 2.7 | Stock: Yes
DGCF13160RSDC (mm): 160 (162.9) | DCX max cutting dia (mm): 174(170.8) | DCSFMS boss dia (mm): 100 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 40 | KWW keyway width (mm): 16.4 | KDP keyway depth (mm): 9.5 | CBDP mounting depth (mm): 29 | D1 (mm): 88 | Teeth: 14 | Weight (kg): 4.4 | Stock: Yes
DGCF13200RSDC (mm): 200 (202.9) | DCX max cutting dia (mm): 214(210.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 60 | KWW keyway width (mm): 25.7 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 130 | Teeth: 16 | Weight (kg): 6.9 | Stock: Yes
DGCF13250RSDC (mm): 250 (252.9) | DCX max cutting dia (mm): 264(260.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 60 | KWW keyway width (mm): 25.7 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 160 | Teeth: 18 | Weight (kg): 10.4 | Stock: Yes
DGCF13080RDC (mm): 80 (82.9) | DCX max cutting dia (mm): 94(90.8) | DCSFMS boss dia (mm): 60 | LF length (mm): 50 (48.44) | DCB bore dia (mm): 25.4 | KWW keyway width (mm): 9.5 | KDP keyway depth (mm): 6 | CBDP mounting depth (mm): 25 | D1 (mm): 20 | Teeth: 8 | Weight (kg): 1.1 | Stock: Yes
DGCF13100RDC (mm): 100 (102.9) | DCX max cutting dia (mm): 114(110.8) | DCSFMS boss dia (mm): 70 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 31.75 | KWW keyway width (mm): 12.7 | KDP keyway depth (mm): 8 | CBDP mounting depth (mm): 32.5 | D1 (mm): 28 | Teeth: 10 | Weight (kg): 2.1 | Stock: Yes
DGCF13125RDC (mm): 125 (127.9) | DCX max cutting dia (mm): 139(135.8) | DCSFMS boss dia (mm): 80 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 38.1 | KWW keyway width (mm): 15.9 | KDP keyway depth (mm): 10 | CBDP mounting depth (mm): 35.5 | D1 (mm): 55 | Teeth: 12 | Weight (kg): 2.7 | Stock: Yes
DGCF13160RDC (mm): 160 (162.9) | DCX max cutting dia (mm): 174(170.8) | DCSFMS boss dia (mm): 100 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 50.8 | KWW keyway width (mm): 19.1 | KDP keyway depth (mm): 11 | CBDP mounting depth (mm): 38 | D1 (mm): 72 | Teeth: 14 | Weight (kg): 4.4 | Stock: Yes
DGCF13200RDC (mm): 200 (202.9) | DCX max cutting dia (mm): 214(210.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 47.625 | KWW keyway width (mm): 25.4 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 130 | Teeth: 16 | Weight (kg): 6.9 | Stock: Yes
DGCF13250RDC (mm): 250 (252.9) | DCX max cutting dia (mm): 264(260.8) | DCSFMS boss dia (mm): 130 | LF length (mm): 63 (61.44) | DCB bore dia (mm): 47.625 | KWW keyway width (mm): 25.4 | KDP keyway depth (mm): 14 | CBDP mounting depth (mm): 35 | D1 (mm): 150 | Teeth: 18 | Weight (kg): 10.9 | Stock: Yes
