Sumitomo Electric Hardmetal SEC-Wave Radius Mill RSX(F) 20000R(S) Radius Cutter

Sumitomo Electric Hardmetal SEC-Wave Radius Mill RSX(F) 20000R(S) Radius Cutter

Radius (round insert) cutter for die cavity, ramping and helical milling at high efficiency.

Key features

  • Die cavity, ramping and helical milling
  • Round RDET inserts
RSX20080RS Max cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 27 | Keyway width KWW (mm): 12.4 | Keyway depth KDP (mm): 7 | Counterbore depth CBDP (mm): 22 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 4 | Weight (kg): 0.9 | Stock: Yes
RSX20100RS Max cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 50 | Bore dia DCB (mm): 32 | Keyway width KWW (mm): 14.4 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Teeth: 5 | Weight (kg): 1.8 | Stock: Yes
RSX20125RS Max cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 52 | Bolt dia D2 (mm): 29 | Teeth: 6 | Weight (kg): 2.6 | Stock: Yes
RSX20160RS Max cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 90 | Teeth: 7 | Weight (kg): 4.7 | Stock: Yes
RSX20080R Max cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 25.4 | Keyway width KWW (mm): 9.5 | Keyway depth KDP (mm): 6 | Counterbore depth CBDP (mm): 25 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 4 | Weight (kg): 0.9 | Stock: Yes
RSX20100R Max cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 63 | Bore dia DCB (mm): 31.75 | Keyway width KWW (mm): 12.7 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Bolt dia D2 (mm): 27 | Teeth: 5 | Weight (kg): 1.8 | Stock: Yes
RSX20125R Max cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 38.1 | Keyway width KWW (mm): 15.9 | Keyway depth KDP (mm): 10 | Counterbore depth CBDP (mm): 35.5 | Bolt dia D1 (mm): 55 | Bolt dia D2 (mm): 30 | Teeth: 6 | Weight (kg): 2.6 | Stock: Yes
RSX20160R Max cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 50.8 | Keyway width KWW (mm): 19.1 | Keyway depth KDP (mm): 11 | Counterbore depth CBDP (mm): 38 | Bolt dia D1 (mm): 72 | Teeth: 7 | Weight (kg): 4.2 | Stock: Yes
RSXF20080RS Max cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 27 | Keyway width KWW (mm): 12.4 | Keyway depth KDP (mm): 7 | Counterbore depth CBDP (mm): 22 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 5 | Weight (kg): 0.9 | Stock: Yes
RSXF20100RS Max cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 50 | Bore dia DCB (mm): 32 | Keyway width KWW (mm): 14.4 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Teeth: 6 | Weight (kg): 1.8 | Stock: Yes
RSXF20125RS Max cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 52 | Bolt dia D2 (mm): 29 | Teeth: 7 | Weight (kg): 2.6 | Stock: Yes
RSXF20160RS Max cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 90 | Teeth: 9 | Weight (kg): 4.6 | Stock: Yes
RSXF20080R Max cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 25.4 | Keyway width KWW (mm): 9.5 | Keyway depth KDP (mm): 6 | Counterbore depth CBDP (mm): 25 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 5 | Weight (kg): 0.9 | Stock: Yes
RSXF20100R Max cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 63 | Bore dia DCB (mm): 31.75 | Keyway width KWW (mm): 12.7 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Bolt dia D2 (mm): 27 | Teeth: 6 | Weight (kg): 1.8 | Stock: Yes
RSXF20125R Max cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 38.1 | Keyway width KWW (mm): 15.9 | Keyway depth KDP (mm): 10 | Counterbore depth CBDP (mm): 35.5 | Bolt dia D1 (mm): 55 | Bolt dia D2 (mm): 30 | Teeth: 7 | Weight (kg): 2.6 | Stock: Yes
RSXF20160R Max cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 50.8 | Keyway width KWW (mm): 19.1 | Keyway depth KDP (mm): 11 | Counterbore depth CBDP (mm): 38 | Bolt dia D1 (mm): 72 | Teeth: 9 | Weight (kg): 4.1 | Stock: Yes
Milling CuttersSumitomo Electric Hardmetal
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sumitomo Electric Hardmetal SEC-Wave Radius Mill RSX(F) 20000R(S) Radius Cutter

Brand Sumitomo Electric Hardmetal·Milling Cutters

Available part numbers (16)

RSX20080RS, RSX20100RS, RSX20125RS, RSX20160RS, RSX20080R, RSX20100R, RSX20125R, RSX20160R, RSXF20080RS, RSXF20100RS + 6 more — see full table ↓

How to order

Send the Sumitomo Electric Hardmetal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
RSX20080RSMax cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 27 | Keyway width KWW (mm): 12.4 | Keyway depth KDP (mm): 7 | Counterbore depth CBDP (mm): 22 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 4 | Weight (kg): 0.9 | Stock: Yes
RSX20100RSMax cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 50 | Bore dia DCB (mm): 32 | Keyway width KWW (mm): 14.4 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Teeth: 5 | Weight (kg): 1.8 | Stock: Yes
RSX20125RSMax cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 52 | Bolt dia D2 (mm): 29 | Teeth: 6 | Weight (kg): 2.6 | Stock: Yes
RSX20160RSMax cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 90 | Teeth: 7 | Weight (kg): 4.7 | Stock: Yes
RSX20080RMax cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 25.4 | Keyway width KWW (mm): 9.5 | Keyway depth KDP (mm): 6 | Counterbore depth CBDP (mm): 25 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 4 | Weight (kg): 0.9 | Stock: Yes
RSX20100RMax cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 63 | Bore dia DCB (mm): 31.75 | Keyway width KWW (mm): 12.7 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Bolt dia D2 (mm): 27 | Teeth: 5 | Weight (kg): 1.8 | Stock: Yes
RSX20125RMax cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 38.1 | Keyway width KWW (mm): 15.9 | Keyway depth KDP (mm): 10 | Counterbore depth CBDP (mm): 35.5 | Bolt dia D1 (mm): 55 | Bolt dia D2 (mm): 30 | Teeth: 6 | Weight (kg): 2.6 | Stock: Yes
RSX20160RMax cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 50.8 | Keyway width KWW (mm): 19.1 | Keyway depth KDP (mm): 11 | Counterbore depth CBDP (mm): 38 | Bolt dia D1 (mm): 72 | Teeth: 7 | Weight (kg): 4.2 | Stock: Yes
RSXF20080RSMax cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 27 | Keyway width KWW (mm): 12.4 | Keyway depth KDP (mm): 7 | Counterbore depth CBDP (mm): 22 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 5 | Weight (kg): 0.9 | Stock: Yes
RSXF20100RSMax cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 50 | Bore dia DCB (mm): 32 | Keyway width KWW (mm): 14.4 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Teeth: 6 | Weight (kg): 1.8 | Stock: Yes
RSXF20125RSMax cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 52 | Bolt dia D2 (mm): 29 | Teeth: 7 | Weight (kg): 2.6 | Stock: Yes
RSXF20160RSMax cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 40 | Keyway width KWW (mm): 16.4 | Keyway depth KDP (mm): 9 | Counterbore depth CBDP (mm): 29 | Bolt dia D1 (mm): 90 | Teeth: 9 | Weight (kg): 4.6 | Stock: Yes
RSXF20080RMax cutting dia DCX (mm): 80 | Cutting dia DC (mm): 60 | Boss dia DCSFMS (mm): 55 | Height LF (mm): 50 | Bore dia DCB (mm): 25.4 | Keyway width KWW (mm): 9.5 | Keyway depth KDP (mm): 6 | Counterbore depth CBDP (mm): 25 | Bolt dia D1 (mm): 20 | Bolt dia D2 (mm): 14 | Teeth: 5 | Weight (kg): 0.9 | Stock: Yes
RSXF20100RMax cutting dia DCX (mm): 100 | Cutting dia DC (mm): 80 | Boss dia DCSFMS (mm): 70 | Height LF (mm): 63 | Bore dia DCB (mm): 31.75 | Keyway width KWW (mm): 12.7 | Keyway depth KDP (mm): 8 | Counterbore depth CBDP (mm): 32 | Bolt dia D1 (mm): 46 | Bolt dia D2 (mm): 27 | Teeth: 6 | Weight (kg): 1.8 | Stock: Yes
RSXF20125RMax cutting dia DCX (mm): 125 | Cutting dia DC (mm): 105 | Boss dia DCSFMS (mm): 80 | Height LF (mm): 63 | Bore dia DCB (mm): 38.1 | Keyway width KWW (mm): 15.9 | Keyway depth KDP (mm): 10 | Counterbore depth CBDP (mm): 35.5 | Bolt dia D1 (mm): 55 | Bolt dia D2 (mm): 30 | Teeth: 7 | Weight (kg): 2.6 | Stock: Yes
RSXF20160RMax cutting dia DCX (mm): 160 | Cutting dia DC (mm): 140 | Boss dia DCSFMS (mm): 130 | Height LF (mm): 63 | Bore dia DCB (mm): 50.8 | Keyway width KWW (mm): 19.1 | Keyway depth KDP (mm): 11 | Counterbore depth CBDP (mm): 38 | Bolt dia D1 (mm): 72 | Teeth: 9 | Weight (kg): 4.1 | Stock: Yes
