Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| MA16M08L120S | Connection thread CRKS: M8 | Bore dia DCB (mm): 8.5 | Shank dia DMM (mm): 16 | Overall length LF2 (mm): 120 | Length L4 (mm): 10 | Screw depth L5 (mm): 18 | Projection LF (mm): 145 | Stock: Yes | ||
| MA20M10L150S | Connection thread CRKS: M10 | Bore dia DCB (mm): 10.5 | Shank dia DMM (mm): 20 | Overall length LF2 (mm): 150 | Length L4 (mm): 10 | Screw depth L5 (mm): 20 | Projection LF (mm): 180 | Stock: Yes | ||
| MA25M12L200S | Connection thread CRKS: M12 | Bore dia DCB (mm): 12.5 | Shank dia DMM (mm): 25 | Overall length LF2 (mm): 200 | Length L4 (mm): 10 | Screw depth L5 (mm): 22 | Projection LF (mm): 235 | Stock: Yes | ||
| MA32M16L200S | Connection thread CRKS: M16 | Bore dia DCB (mm): 17 | Shank dia DMM (mm): 32 | Overall length LF2 (mm): 200 | Length L4 (mm): 10 | Screw depth L5 (mm): 24 | Projection LF (mm): 240 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
