Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| DTGNR2525M16-R24 | H (mm): 25 | B (mm): 25 | LF (mm): 150 | WF (mm): 32 | HF (mm): 25 | LH (mm): 32 | Torque (N·m): N | Stock: Yes | ||
| DTGNL2525M16-R24 | H (mm): 25 | B (mm): 25 | LF (mm): 150 | WF (mm): 32 | HF (mm): 25 | LH (mm): 32 | Torque (N·m): N | Stock: Yes | ||
| DTGNR3225P16-R24 | H (mm): 32 | B (mm): 25 | LF (mm): 170 | WF (mm): 32 | HF (mm): 32 | LH (mm): 32 | Torque (N·m): 5.0 | Insert: NC-TNGA1604 | Stock: Yes | ||
| DTGNR3232P16-R24 | H (mm): 32 | B (mm): 32 | LF (mm): 170 | WF (mm): 40 | HF (mm): 32 | LH (mm): 32 | Torque (N·m): 5.0 | Stock: Yes |
Need a different model, or a part not listed here? Send us your parts list →
